Summary of Contents for AirLive VoIP-111A

  • Page 1 VoIP-111A/VoIP-120A SIP VoIP ATA Adapter User’s Manual...
  • Page 2 OvisLink Corp. has made the best effort to ensure the accuracy of the information in this user’s guide. However, we are not liable for the inaccuracies or errors in this guide. Please use with caution. All information is subject to change without notice All Trademarks are properties of their respective holders. AirLive VOIP-111A/VOIP-120A User’s Manual...

  • Page 3: Ce Mark Warning

    This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. All trademarks and brand names are the property of their respective proprietors. Specifications are subject to change without prior notification. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 4: Table Of Contents

    3.4.1 LAN ....................... 30 3.4.2 DMZ & MAC Clone ................31 3.4.3 Virtual Server ..................31 3.5 SIP ....................33 3.5.1 Service ....................33 3.5.2 Codes ....................36 3.5.3 Advanced ....................37 3.5.4 STUN ....................44 AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 5 3.6.6 Password ....................53 3.6.7 Tone ...................... 55 3.6.8 Default ....................58 3.6.9 Language ....................59 3.7 Save & Reboot ................59 3.7.1 Save & Reboot ..................59 3.8 Logout ..................... 60 3.8.1 Logout ....................60 AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 6: Introduction

    The tech support FAQ are frequently updated with latest information. In addition, you might find new firmware that either increase software functions or provide bug fixes for VOIP-111A/VOIP-120A. You can reach our on-line support center at the following link: http://www.airlive.com/support/support_1.php...

  • Page 7: Features

    Advance SIP VoIP ATA Adapter n Convert your analog phone into IP Phone n 1 FXS + 1 FXO ports support 1 IP-Phone with PSTN backup (For VOIP-111A) n 2 FXS Ports Support 2 IP Phone calls(For VOIP-120A) n 2 Concurrent calls for 3-Way conference n FXS port support Phone setting via voice prompt 1.4 Overview...

  • Page 8: Software

    Two RJ-11 analog telephone jacks interfaces Ÿ You can connect one analog telephone to the terminal adapter and one PSTN line (VOIP-111A). Or, two analog telephone sets at VOIP-120A. LED Indication Ÿ There are three LED indicators on the ATA to show the Power, Register, and Off-Hook status.
  • Page 9 1. Introduction · In-Band DTMF · Out-of Band DTMF · SIP Info · Firmware Upgrade SIP Server · Registrar Server (Five SIP accounts) · TFTP · Outbound Proxy · HTTP AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 10: Keypad Interface From Analog Phone Set Of Ata

    PSTN Line from analog Dial out from Function None phone set directly, you can PSTN Line dial out from PSTN Line. (For model VOIP-111A only) Unlock After you unlock keypad Function keypad #190# None setting, you may start to setting configure ATA from keypad.
  • Page 11 Primary DNS Server field. Setting Check IVR will announce the Info Firmware #128# None version of the firmware Version running on the ATA. Set DHCP The system will change to Setting #111# None client DHCP Client type AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 12 You can set the Handset gain Setting Gain from 0~15 to proper value, default is 6 You can set the Handset Set Handset #132+[00~12 Handset Volume Setting volume to proper value, Volume from 0~12 default is 10 AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 13 Enter IP address using Set Auto numbers on the #136xxx*xxx Configuration telephone Must set auto configuration Setting For FTP *xxx*xxx# keypad. Use method to FTP first Server the * (star) key when entering a decimal point. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 14: Configuring The Sip Voip Ata Adapter

    VOIP-111A/VOIP-120A’s web management and how to get into 3.1 Login Web Management The VOIP-111A/VOIP-120A provides a built-in web server. You can use a Web browser to configure the VOIP-111A/VOIP-120A. For more detail instructions, please refer to the procedures below.

  • Page 15: Default Setting

    After the system has restarted, all the settings can work properly. 3.1.2 System Status When you login to the web page, you can see the VOIP-111A /VOIP-120A current system information like firmware version, WAN, LAN, System, and Register…etc in this page.

  • Page 16: Phone

    Phone Book provides 140 entries. When you pick up the phone and dial a TEL NO, ATA will compare the Phone Number with the phone book name first. If it matched, ATA will follow the phone book name’s number setting to dial. If NOT, the entered number will be dialed out directly. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 17 Dial TEL Number information. Maximum length is 63 digits. For example: 0212345678, 0800024365 or www.dyndns.info. Action provide [Delete] button to clear this record’s data Submit [button] Save data. Reset [button] Reset all data. Delete All [button] Delete all data. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 18: Dial Plan

    0 to 9. Maximum data length is 40 digits. *Note: The first digit can’t be 0 if it is 2 digits number length. Index Index number. There are 8 entries to configure Dial Out immediately. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 19 *Note: Please make sure the PSTN line connect to ATA correctly if you want to enable this function. PSTN feature Default is 0*. This code is to switch the route to PSTN port Code manually. When you dial 0* you will hear dial tone from PSTN line AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 20 When the dialing number is like [003+77xxxx], it matched [Rule] -> [003], so ATA will replace [003] with [Prefix] [006]. The actual dialing number will be [006+77xxxx]. Instruction 3: Drop prefix: Disable, Replace rule: 009, Rule: 12. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 21: Call Services

    Description 2: When ATA registered to SIP Server successfully, press dials code *22 from analog phone set to force ATA switch to PSTN line manually. The Dial Tone was provided from PSTN line instead. 3.2.3 Call Services Call Services provides the Forward, Hotline, DND, Alarm functions. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 22 3. Configuring the SIP VoIP ATA Adapter This figure is for VOIP-111A Field Description Forward Type of Default is Disable. To configure Phone 1 forward type. phone1 Here provides 5 options: Disable Always, Busy, No Answer, Busy or No Answer.
  • Page 23 The default ring time is 1 minute. Alarm Time for Default is 0:0(Hour/Minute). The time format is 24 hours system phone 1 (hh/mm). Each field allows to enter 2 digits number only. Submit Save the configuration. Reset Clear the configuration. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 24 Hotline Number Configure Phone 2 hotline number. You can enter IP address or of phone 2 number or digit string and the maximum length is 63 digits. For instance, IP address: 192.168.1.23 or telephone number: 0800024365. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 25 (hh/mm). Each field allows entering 2 digits number only. Submit Save the configuration. Reset Clear the configuration. Example1: Forward Feature (1) Always (Unconditional Transfer): Step1: Go to [Call Service Setting] page and configure [Forward Type: All, Forward Number: 812345678]. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 26 ATA is on line (Busy). Example 2: Hotline Feature (1) Dial a hotline number: Step1: Go to [Call Service Setting] page and configure [Forward Type: Enable, Hot Line number: 82341234, Delay: 3]. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 27 Step1: Go to [Call Service Setting] page and configure [Alarm Type: Enable, Alarm Time: 21:00]. Step2: ATA’s analog phone set start Ring when 21:00PM arrive daily and it is lasting for default time (i.e. default time is 1 minute). It stops ring immediately when you pickup handset. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 28: General

    Default codec is G.711 u-Law (enable) to support T.38 FAX passes Pass-through through. ATA only uses codec either G.711 u-law or G.711 a-law to codec transmit FAX over T.38 protocol. Submit [button] Save the configuration. Reset [button] Clear the configuration. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 29: Volume

    (0 to 15). Maximum length is 2 digits. Submit [button] Save the configuration. Reset [button] Clear the configuration. 3.3 Network In Network you can check the Network status, WAN, DDNS, VLAN, VPN and NTP Settings. 3.3.1 WAN Provide WAN port configuration. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 30: Ddns

    Save the configuration. Reset [button] Clear the configuration. 3.3.2 DDNS Dynamic DNS provides a residential user's Internet gateway that has a variable, often changing IP address with a well known hostname resolvable through standard DNS queries. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 31 It provides two options: Disable and Enable. *Note: Please make sure your DDNS provider supports this feature when you set it to enable. Submit [button] Save the configuration. Reset [button] Clear the configuration. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 32: Vlan

    Range is 3~4094. This feature is an independent one which do not need to Enable [VLAN Packets] if you want to enable this feature. Data length is 4 digits. User Priority Default is 0 (disable). Define SIP package priority. Range is 0~7. (802.1P) AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 33: Vpn

    Port Number Default PPTP Port is 1723. Provide 2 options: Default, Customer (User defines port) and the range is 1024~65535. Only number and length is 5 digits. Submit [button] Save the configuration. Reset [button] Clear the configuration. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 34: Ntp

    DST Offset Default is +1 Hour. Adjust the Daylight Saving time. Option: -2 hour, -1 hour, +1 hour, +2 hour. DST Start Date Configure the Daylight Saving start time. Option: Day of Month, Week of Month. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 35: Nat

    1~254. IP address format is 3 digits. Lease Time Default is 1:0 (day: hour). Define the DHCP IP lease time. The range is 0:0~ 12:23. Data length is 2 digits. Submit [button] Save the configuration. Reset [button] Clear the configuration. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 36: Dmz & Mac Clone

    Save the configuration. Reset [button] Clear the configuration. * Note: If you want to resume your original MAC address, please use “Restore Default Setting” command at Webpage configuration. 3.4.3 Virtual Server Provide 12 sets of Virtual Server. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 37 Click the delete button to clear the setting. Submit [button] Save the configuration. Reset [button] Clear the configuration. *Note: When you define the Internet & Extranet Ports, please avoid from using ATA default ports. For example: 5060, 9999, 20000. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 38: Sip

    3. Configuring the SIP VoIP ATA Adapter 3.5 SIP Provide Service, Codes, Advanced and STUN functions. 3.5.1 Service Provide 5 register accounts. This figure is for VOIP-111A Field Description Realm No. Default is 1 (The first register account). If you want to switch to 1 account, please dial [1*] then hang up phone.
  • Page 39 Account’s display name which can be numbers or strings. Maximum length: 31 digits. Phone Number Account’s phone number which can only be numbers. Maximum length: 31 digits. Authentication Account’s register ID which can be numbers or strings. Maximum AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 40 63 digits. If special Port Address is needed, please add it behind. For instance, nat.voiptalk.org:5065. Subscribe of Subscribe for MWI function (message waiting indicator). *Note: Your Register SIP Proxy server must support this function. Submit [button] Save the configuration. Reset [button] Clear the configuration. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 41: Codes

    Default is 20 ms which defines G.711 and G.729 RTP payload type. Provide options are: 10, 20, 30, 40, 50, 60, 70, 80, and 90ms. G.723 Default is 30 ms which defines G.723 RTP payload type. Provide AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 42: Advanced

    ID can be modified. (Range : 95~127) Submit [button] Save the configuration. Reset [button] Clear the configuration. 3.5.3 Advanced Provide SIP Expire Time, SIP/RTP Port, QoS, Register SIP Expire Time, Use DNS SRV, DTMF, User=Phone, PRACK Function. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 43 3. Configuring the SIP VoIP ATA Adapter This figure is for VOIP-111A Field Description SIP Expire Time Default is 60. The range is 60~86400 seconds. When it was set tp 0, ATA define expired time according to SIP Server. Data length is 5 digits.
  • Page 44 Option: InBand, RFC2833, SIP Info, RFC2833 + Inband, SIP Info + Inband. RPort Default is Disable. When you set to [Enable], the [Message Header] will include [Rport] information. Voice QoS Default is 40; Define Voice QoS (Diff-Ser) function. Range: 0~63. (Diff-Serv) AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 45 Only Accept Call Default is Disable. Configure to accept incoming call which is From Proxy registered to SIP Proxy server. Reject incoming call when use IP direct calling. Submit [button] Save the configuration. Reset [button] Clear the configuration. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 46 This figure is for VOIP-120A Field Description SIP Expire Time Default is 60. The range is 60~86400 seconds. When it was set tp 0, ATA define expired time according to SIP Server. Data length is 5 digits. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 47 1- Both fields can be same or a range. 2- SIP port was used by two continuous ports. If SIP port was entered at 5060, two ports at 5060 and 5061 were used in reality. 3-All ports are unique and can not be duplicated. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 48 Default is Disable. If ATA was installed behind the NAT, it should Alives Packet keep the channel available so it has to send the keep alives packet to keep this channel. Enable: Use UDP format to send. For instance, UDP Source Port: sip, Destination Port:xxxx. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 49: Stun

    Description STUN Active Default is Disable. Option: Disable, Enable. STUN Server Default is stun.xten.com; Define STUN server IP which can be IP Name address or Domain Name. The format is xxx.xxx.xxx.xxx. Data length is 63 digits. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 50: Management (Advanced Configuration)

    Default port is 3478. Define Router external port number. Number Range: 80~65535. Submit [button] Save the configuration. Reset [button] Clear the configuration. 3.6 Management (Advanced Configuration) Provide Status Log, Auto Config, Auto Update, New Firmware, Advanced, Password, Tones, Default, Language functions. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 51: View Log

    Include time and information. <2010-09-14 10:35> Get Time from SNTP server, Succeed! <2010-09-14 10:35>: event time and date. Get Time from SNTP server, Succeed!: event Get Status Log Save the [Status Log] to file; default file name is Syslog.log. [button] AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 52: Auto Provision

    Default is Disable; When you enable the Scheduling, ATA will follow the [Next Config Time] to check or update configuration data. Option: Disable, Enable. TFTP Server Define TFTP server IP. The format is xxx.xxx.xxx.xxx. Data length is 15 digits. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 53: Auto Update

    Display the next configuration date and time. If the estimated date was expired, ATA will visit assigned server to check the updated information. Submit [button] Save the configuration. Reset [button] Clear the configuration. 3.6.3 Auto Update Provide rom format file upgrade. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 54 Default: Product model. Can be numbers or strings, maximum: 8 Prefix digits. Next Update Showing the next update time. Time *Note: Date calculation starts from next day. Submit [button] Save the configuration. Reset [button] Clear the configuration. *Note: Firmware updated manually at Auto Provision mode. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 55: Firmware

    Please don’t turn off the power. VOIP-111’s firmware are different with VOIP-120A, please only use correct firmware for these models. 3.6.5 Advanced Provide anonymous call, billing signal, encryption, syslog and FXS/FXO parameter function setting. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 56 *Note: Your Register Proxy server must support this function. Management Default is Enable which allows web management access from from WAN WAN port. When it was set to Disable, ATA only allow web access vial LAN port. Option: Disable, Enable AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 57 PPPoE failed. Only numbers are accepted, data range: (5~255) seconds, maximum length is 3 digits. System Log Sending ATA debug messages to System Log Server which can Server be IP Address or Domain Name Address. Format: xxx.xxx.xxx.xxx; Maximum lengthis 63 digits. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 58: Password

    Default is Disable. LAN port bandwidth limitation. Limit Option: Disable, 128, 256, 512, 1024, 2048, 4096, 8192 kbps. Submit [button] Save the configuration. Reset [button] Clear the configuration. 3.6.6 Password There are 3 levels login name and password. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 59 Service, Code, Advanced, Stun; Management: Status Log, Auto Config, Auto Update, New Firmware, Advanced, Password, Tones, Default, Language; Save & Reboot, Logout]. Default user name: airlive, default user password: airlive. New username Enter new username which can be Numbers or strings, maximum length is 32 digits.

  • Page 60: Tone

    Default is 0; The unit is 10ms; Only numerals are acceptable. Data range: 0~ 999, Maximum length: 3 bytes. Off Time 2 Default is 0; The unit is 10ms; Only numerals are acceptable. Data range: 0~ 999, Maximum length: 3 bytes. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 61 Default is 0; The unit is 10ms; Only numerals are acceptable. Data range: 0~ 999, Maximum length: 3 bytes. On Time 3 Default is 0; The unit is 10ms; Only numerals are acceptable. Data range: 0~ 999, Maximum length: 3 bytes. AirLive VoIP-111A/VoIP-120A User’s Manual...
  • Page 62 Default is 0; The unit is 10ms; Only numerals are acceptable. Data range: 0~ 999, Maximum length: 3 bytes. Off Time 3 Default is 0; The unit is 10ms; Only numerals are acceptable. Data range: 0~ 999, Maximum length: 3 bytes. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 63: Default

    Restore whole configuration setting to factory default except Phone Book. Field Description Reset to Factory Restore to default setting and reboot. Setting Export Setting Export the configure file. Restore Setting Restore configuration data which was downloaded via ATA. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 64: Language

    Save configuration and Reboot ATA. 3.7.1 Save & Reboot · Save Change: Save configuration and auto reboot to take effect. · Reboot System: Reboot ATA Field Description Save Save configuration and auto reboot. Reboot Reboot ATA. AirLive VoIP-111A/VoIP-120A User’s Manual...

  • Page 65: Logout

    3. Configuring the SIP VoIP ATA Adapter 3.8 Logout 3.8.1 Logout Logout system and return to login page. Field Description Logout Logout system and return to login page. AirLive VoIP-111A/VoIP-120A User’s Manual...
