  • Page 1 WMM-3000PCM/PCI MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 2: Quick Installation

    Install “Driver & Utility” Configure your MIMO WIRELESS LAN Card with “Zero Configure” or “ AirLive MIMO Wireless Utility” to connect to WIRELESS network. FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two...
  • Page 3 2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. - 2 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 4: Table Of Contents

    Chapter 3 Configure MIMO WIRELESS LAN Card____________ 8 3-1 Install Utility _____________________________________________________________ 8 3-2 Configure MIMO WIRELESS LAN Card with Zero Configure ________________ 10 Chapter 4 Configure with “AirLive MIMO Wireless Utility” for Windows 98/ME/2000/XP _________________________________ 13 4-1 Site Survey Page _______________________________________________________ 13 4-1-1 Add/Edit Profile ______________________________________________________ 14 4-2 Authentication &...
  • Page 5 5-5 Configure connection with WPA2-PSK ___________________________________ 38 5-6 Configure connection with WPA by 802.1x setting _________________________ 41 5-7 Configure connection with WPA2 by 802.1x setting________________________ 50 - 4 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 6: Chapter 1 System Requirements

    Type II CardBus card, and can be installed in a Type II or Type III CardBus slot. 1-2 Software The drivers included with the adapter allow the adapter to be used in Microsoft Windows 98, ME, 2000, and XP. - 5 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 7: Chapter 2 Install Driver For Windows Series

    New Hardware Wizard” window will show up. Select “Cancel” to install the driver from CD-Rom. Step 2: Insert the Product CD-ROM into the CD-ROM drive. Select “Utility” to install Driver and Utility. - 6 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 8 Step 3: After installing the driver, you can check if your device is active in the device management as follows - 7 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 9: Chapter 3 Configure Mimo Wireless Lan Card

    1. After finishing the install process, you can execute the utility as follows 3. You will see the utility icon after you executing program “Wireless Utility” if your MIMO WIRELESS Card is alive - 8 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 10 You will see the frame below. If you want to configure your MIMO Wireless LAN Card with “Wireless Zero Configure” supported by XP, you should choose “Use Zero Configuration as Configuration utility”. - 9 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 11: Configure Mimo Wireless Lan Card With Zero Configure

    WIRELESS LAN Card, shown as below. Choose one suitable server In order to reconfigure you WIRELESS connection, you can deal as follow procedure 1.click left button on the network icon as bellow. - 10 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 12 3. Click WIRELESS Networks to reconfigure the WIRELESS network connection. 4. If you need a key(WEP) to connect the WIRELESS network, you should keyin the key that supported by the WIRELESS network router or access point - 11 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 13 Note: Under the Windows XP, it is recommend to use the “Automatic WIRELESS Network Configuration” to configure your MIMO-G WIRELESS LAN Card. The WIRELESS LAN Utility comes with the WIRELESS LAN Card is not support the Windows XP. - 12 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 14: Windows 98/Me/2000/Xp

    Encryption : what encrypted mechanism does AP used, the encrypted mechanism contain four ways , WEP, AES, TKIP, NOT USE Authentication : What authentication mechanism does AP used. Network Type : What Network Type does the AP belong to. - 13 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 15: Add/Edit Profile

    3. if the connect is success, it will show the SSID of the connected AP rescan and upgrade all the AP’s information in time connect with selected AP Save the selected AP’s information to Profile Add/Edit Profile 4-1-1 System Configuration : as figure bellow - 14 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 16 Profile function is based on the needs to set up the most linkable AP in order to record the system configuration and to set up the authentication security. The function of each session is shown below - 15 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 17: Authentication & Security

    32 length. WEP Key: Only valid when using WEP encryption algorithm. The key must matched AP 　 key. There are several formats to enter the keys. Hexadecimal、40bits：10 Hex characters. Hexadecimal、128bits：32Hex characters. - 16 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 18: 802.1X Setting

    WLAN client and the access point. iii. TTLS: Tunneled Transport Layer Security. This security method provides for certificate-based, mutual authentication of the client and network through an - 17 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 19: Ca Server

    2. Allow intimidate certificates: It must be in the server certificate chain between the server certificate and the server specified in the certificate issuer must be field. 3. Server name: Enter an authentication sever root. - 18 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 20 - 19 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 21: Profile Page

    Indicate connection is successful on currently activated profile. Indicate connection is failed on currently activated profile. 3. Add a new profile. 4. Delete an existing profile. 5. Edit Profile 6. Activate selected profile. - 20 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 22: Link Status Page

    5. Link Quality: Display connection quality based on signal strength and TX/RX packet error rate. 6. Signal Strength: Receive signal strength, user can choose to display as percentage or dBm format 7. Noise Level: Display noise signal strength. - 21 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 23: Statistics Page

    Frames Received With CRC Error: Frames received with CRC error. iii. Frames Dropped Due To Out-of-Resource: Frames dropped due to resource issue. Duplicate Frames Received: Duplicate received frames. To zero the statistic numbers of transmitting and receiving data. - 22 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 24 4. CCX2.0: support Cisco Compatible Extensions function: LEAP turn on CCKM Enable Radio Measurement: can channel measurement every 0~2000 milliseconds. 5. Tx Burst: AirLive’s proprietary frame burst mode. 6. Wireless radio signal control : means to open the wireless radio signal and show simultaneously:...

  • Page 25: About Page

    4-6 About Page About page display the wireless card and driver version information shown as follow figure . Connect to AirLive website: www.airlive.com Display Configuration Utility, Driver, - 24 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 26: Chapter 5 Example

    Chapter 5 Example 5-1 Adding profile in site survey page 1. Select the indented network from site survey list. 2. Click ADD PROFILE. 3. System will pop up Add Profile windows - 25 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 27 4. Change profile Name from PROF1 to FAVORITE. 5. Click OK without changing other value. - 26 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 28 - 27 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 29: Add Profile In Profile Page

    5-2 Add profile in profile page Click ADD in profile page Add Profile page will pop up Change profile name to TEST. - 28 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 30 Pull down SSID and select one intended AP. The AP list is the result of last site survey. Set Power Saving Mode. - 29 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 31 Click Authentication & Security page Click OK. Then we can find the profile name appears in the grid. - 30 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 32 Click ACTIVATE. Activate the profile setting. - 31 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 33: Wep Encryption

    5-3 WEP encryption 1. Select AP with WEP encryption. 2. Click CONNECT or doucle click intended network. 3. Authentication & Security page pop up. - 32 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 34 4. Enter 0123456789 at Key#1 which is same as our intended AP’s setting. 5. Click OK. The result will look like the below figure. - 33 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 35 - 34 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 36: Configure Connection With Wpa-Psk

    5-4 Configure connection with WPA-PSK 1. Select the AP with WPA-PSK authentication mode. 2. Click CONNECT or double click the intended network. 3. Authentication & Security page will pop up. - 35 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 37 4. Authentication Type is WPA-PSK. Select correct encryption (TKIP or AES).Enter WPA Pre-Shared Keysecret as 01234567. 5. Click OK. Be careful, if the WPA Pre-Shared Key entered is not correct, even though the AP - 36 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 38 - 37 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 39: Configure Connection With Wpa2-Psk

    5-5 Configure connection with WPA2-PSK Select the AP with WPA2-PSK authentication mode. Click CONNECT or double click the intended network. Authentication & Security page will pop up. TKIP, AES and Both (TKIP+AES) security are - 38 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 40 Authentication Type is WPA-PSK. Select correct encryption (TKIP or AES). Enter WPA Pre-Shared Keysecret as 12345678. Click OK. Be careful, if the WPA Pre-Shared Key entered is not correct, even though the AP - 39 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 41 - 40 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 42: Configure Connection With Wpa By 802.1X Setting

    5-6 Configure connection with WPA by 802.1x setting Select A.P with WPA authentication mode. Click CONNECT or double click the intended network Authentication & Security page will pop up. TKIP, AES and Both (TKIP+AES) security are - 41 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 43 *If AP setup security to 〝Both 〞(TKIP + AES), system define is AES that security is severely. Click 802.1x setting. 802.1x setting page will pop up. - 42 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 44 Authentication type chooses PEAP, key identity into wpatest2. Protocol chooses EAP-MSCHAP v2 for tunnel authentication, tunnel identity is wpatest2 and tunnel password is test2. Those setting are same as our intended AP’s setting. - 43 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 45 Click OK. The result will look like the below figure. TLS / Smart Card: - 44 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 46 Authentication type chooses TLS / Smart Card, TLS only need identity that is wpatest2 for server authentication. TLS must use client certicate. Click more to choose certicate. iii. Certicate page will pop up; choose a certicate for server authentication. - 45 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 47 Display certicate information in use client certicate page. Click OK. The result will look like the below figure. - 46 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 48 Authentication type chooses TTLS, identity is wpatest2. Protocol chooses CHAP for tunnel authentication, tunnel identity is wpatest2 and tunnel password is test2. Those setting are same as our intended AP’s setting. - 47 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 49 Click OK. The result will look like the below figure. - 48 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 50 MD5: Authentication type chooses MD5, MD5 only need identity and password that are wpatest2 and test2 for server authentication. Click OK. The result will look like the below figure. - 49 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...

  • Page 51: Configure Connection With Wpa2 By 802.1X Setting

    5-7 Configure connection with WPA2 by 802.1x setting Select A.P with WPA2 authentication mode. Click CONNECT or double click the intended network. Authentication & Security page will pop up. TKIP, AES and Both (TKIP+AES) security are - 50 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 52 *If AP setup security to 〝Both 〞(TKIP + AES), system define is AES that security is severely. Click 802.1x setting. 802.1x setting page will pop up. - 51 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 53 Authentication type chooses PEAP, key identity into wpatest2. Protocol chooses EAP-MSCHAP v2 for tunnel authentication, tunnel identity is wpatest2 and tunnel password is test2. Those setting are same as our intended AP’s setting. - 52 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 54 Click OK. The result will look like the below figure. TLS / Smart Card: - 53 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 55 Authentication type chooses TLS / Smart Card, TLS only need identity that is wpatest2 for server authentication. TLS must use client certicate. Click more to choose certicate. iii. Certicate page will pop up; choose a certicate for server authentication. - 54 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 56 Display certicate information in use client certicate page. Click OK. The result will look like the below figure. - 55 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 57 Those setting are same as our intended AP’s setting. Click OK. The result will look like the below figure. - 56 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 58 MD5: Authentication type chooses MD5, MD5 only need identity and password that are wpatest2 and test2 for server authentication. - 57 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
  • Page 59 Click OK. The result will look like the below figure. - 58 - AirLive MIMO-G Wireless LAN Adapter User’s Manual...
