  • Page 1 VoIP-111A / 120A SIP VoIP ATA Adapter User’s Manual AirLive VoIP-111A / 120A User’s Manual...

  • Page 2: Declaration Of Conformity

    5F., NO.6, Lane 130, Min-Chuan Rd., Hsin-Tien City, Taipei County, Taiwan Declare that the product SIP VOIP ATA Adapter VOIP-111A , VOIP-120A is in conformity with In accordance with 89/336 EEC-EMC Directive and 1999/5 EC-R & TTE Directive Clause Description...
  • Page 3 VOIP-111/120A CE Declaration Statement Country Declaration Country Declaration OvisLink Corp. tímto prohlašuje, že tento VOIP- Šiuo OvisLink Corp. deklaruoja, kad šis VOIP- Česky [Czech] 111/120A je ve shodě se základními požadavky a Lietuvių 111/120A atitinka esminius reikalavimus ir kitas dalšími příslušnými ustanoveními směrnice [Lithuanian] 1999/5/EB Direktyvos nuostatas.
  • Page 4 FCC Certifications This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 5: Table Of Contents

    Setup the ATA by using Console (Hyper Terminal)....36 Configure the COM port ...................... 36 ATA Login ..........................37 Using CLI command to configure the ATA ................37 How to make a phone call............43 AirLive VoIP-111A / 120A User’s Manual...

  • Page 6: Introduction

    Introduction This user’s manual is for VoIP-111A (1PSTN+1Phone) / VoIP-120A (2Phone) VoIP terminal adapter (ATA). This user’s manual will explain the IVR instruction, web configuration, and command line configuration for the ATA. Before using the ATA, some setup processes are required to make the ATA work properly.

  • Page 7: Keypad Interface For The Ata

    IVR will announce the current Info DNS Server #125# None setting in the Primary DNS field. Setting Check Firmware IVR will announce the version of the Info #128# None Version firmware running on the ATA. AirLive VoIP-111A / 120A User’s Manual...
  • Page 8 Enter IP address using numbers on Set Auto the telephone keypad. Use the * Must set auto configuration method Setting Configuration #136xxx*xxx*xxx*xxx# (star) key when entering a decimal to FTP first For FTP Server point. AirLive VoIP-111A / 120A User’s Manual...

  • Page 9: Setup The Ata By Web Browser (Lan Connection)

    3.1.1 Please input the username and password into the blank field. The default setting is: 1. For Administrator, the username is: airlive; and the password is: airlive. If you use this account to login, you can configure all the settings.

  • Page 10: System Information For The Ata

    If you want to delete a phone number, you can select the phone number you want to delete then click “Delete Selected” button. If you want to delete all phone numbers, you can click “Delete All” button. AirLive VoIP-111A / 120A User’s Manual...

  • Page 11: Phone Setting

    If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. AirLive VoIP-111A / 120A User’s Manual...
  • Page 12 Also you can base on your location to set the Time Zone, and how long need to synchronize again. When you have finished the setting, please click the Submit button. Figure 4. SNTP Setting AirLive VoIP-111A / 120A User’s Manual...
  • Page 13 If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. AirLive VoIP-111A / 120A User’s Manual...
  • Page 14 Save Change Item on the left side; then click the Save button. The changes you have made will be saved into the system and the system will reboot automatically. Figure 7. Caller ID Setting AirLive VoIP-111A / 120A User’s Manual...
  • Page 15 0. Therefore if Dial Now is set to 0xxxx, the system will not be able to send out this piece of information Auto Dial Time Wait setting time then auto dial number Submit [Button] Save setting value。 Reset [Button] Clean all setting。 AirLive VoIP-111A / 120A User’s Manual...
  • Page 16 ；this rule is not match above dial number rule;dial out number is [534]。 Comment 3：if you input number has 35xx，device search match 35 and after add 2 data should auto add 007；dial out number is[007+35xx]。 AirLive VoIP-111A / 120A User’s Manual...
  • Page 17 Submit button. If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. Figure 10. Flash Time Setting AirLive VoIP-111A / 120A User’s Manual...
  • Page 18 Submit button. If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. Figure 12. T.38 (FAX) Setting AirLive VoIP-111A / 120A User’s Manual...

  • Page 19: Hot Line

    This function supports auto dial for you to set a hot line number. When you set this function the device should not dial any number. Alarm setting Alarm time: setting telephone ring time, when you setting time with current time are match device should produce a ring; this time format is 24 hours. AirLive VoIP-111A / 120A User’s Manual...

  • Page 20: Network

    Network 3.7.1 In Network you can check the Network status, WAN setting,LAN setting,DDNS settings and VLAN Settings. 3.7.2 Network Status: You can check the current Network setting in this page. Figure 13. Network Status AirLive VoIP-111A / 120A User’s Manual...
  • Page 21 If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. Figure 14. Network Settings AirLive VoIP-111A / 120A User’s Manual...
  • Page 22 If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. Figure 15. WAN Settings AirLive VoIP-111A / 120A User’s Manual...
  • Page 23 Submit button. If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. Figure 16. DDNS Setting AirLive VoIP-111A / 120A User’s Manual...
  • Page 24 If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. Figure 17. VLAN Setting AirLive VoIP-111A / 120A User’s Manual...

  • Page 25: Dmz Setting

    DMZ Setting DMZ setting: you can set the DMZ setting in this page. Figure 18. DMZ Setting Virtual Server Setting Figure 19. Virtual Server Setting AirLive VoIP-111A / 120A User’s Manual...

  • Page 26: Sip Settings

    If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. AirLive VoIP-111A / 120A User’s Manual...
  • Page 27 Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. Figure 21. Port Setting AirLive VoIP-111A / 120A User’s Manual...
  • Page 28 Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. Figure 23. Codec ID Setting AirLive VoIP-111A / 120A User’s Manual...
  • Page 29 Other Settings: you can setup the Hold by RFC, Voice/SIP QoS and SIP expire time in this page. To change these settings please following your ISP information. When you have finished the setting, please click the Submit button. The QoS setting is to set the voice AirLive VoIP-111A / 120A User’s Manual...

  • Page 30: Nat Trans

    Submit button. If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. Figure 27. STUN Setting AirLive VoIP-111A / 120A User’s Manual...

  • Page 31: Others

    Enter the relevant password associated with the inputted username to log on to the FTP Server File Path Specify the path to store data, for e.g. /123/ Submit [Button] Saves the configuration Reset [Button] Erases the configuration AirLive VoIP-111A / 120A User’s Manual...
  • Page 32 。 3.12.6 How to produce auto Configuration file. 1 ： First you need to find the MAC address of the device that you want to configured ， for e.g. MAC Address: 00059e812118。 AirLive VoIP-111A / 120A User’s Manual...
  • Page 33 When you have finished the setting, please click the Submit button. If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. AirLive VoIP-111A / 120A User’s Manual...
  • Page 34 Default setting is None (do not activate). Specifies the format of system log messages, four to choose from; None, Call Statistics, Debug Information and Both. Submit [Button] Save setting value. Reset [Button] Clean all setting. AirLive VoIP-111A / 120A User’s Manual...

  • Page 35: Mac Clone Setting

    MAC Addresses through PPPoE. connect LAN port PC MAC Address to device WAN Port,let your PC MAC address with your device are same MAC ； Because some ISP company should lock (PPPoE) MAC Address。 AirLive VoIP-111A / 120A User’s Manual...

  • Page 36: Tone Settings: You Can Configure Your Tone Settings In This Page

    Submit button. If no further changes are needed, please click the Save Change Item on the left side; then click the Save button. The changes you have made will be saved and the system will reboot automatically. Figure 31. System Authority AirLive VoIP-111A / 120A User’s Manual...

  • Page 37: Save Change

    File Location blank. Select the correct file you want to download to the ATA then click the Update button. After finished the update firmware process, the system will Reboot automatically. AirLive VoIP-111A / 120A User’s Manual...
  • Page 38 Restore button, then the TA will restore to default and automatically restart again. The Default Setting will be NAT Mode, WAN port is DHCP Client Mode, LAN port is Fixed IP Mode and the IP Address is 192.168.123.1. Figure 34. Restore Default Setting AirLive VoIP-111A / 120A User’s Manual...

  • Page 39: Reboot

    3.18 Reboot 3.18.1 If you want to restart the ATA, just click the Reboot button, then the ATA will reboot automatically. Figure 35. Reboot System AirLive VoIP-111A / 120A User’s Manual...

  • Page 40: Setup The Ata By Using Console (Hyper Terminal)

    First, open the hyper terminal window, select the connection by the COM port, and then click the “Setting” button. Figure 36. Console Setting-1 Set the COM port’s setting as following setting. Then click OK. Figure 37. Console Setting-2 AirLive VoIP-111A / 120A User’s Manual...

  • Page 41: Ata Login

    Edit phone book reload Reload Factory Setting watchdog WatchDog Function phone Phone Setting weblogo Change Web's logo Show dsp type addport Add Nat Port Mapping Select slic Cid slic read or write slic registers Firmware Version AirLive VoIP-111A / 120A User’s Manual...
  • Page 42 Save system setting reboot function is to restart the system. exit function is to exit the CLI. debugmode function is to enter the debugmode. update function Index Command Description Show 'update' Option Update OSImage(IP filename) AirLive VoIP-111A / 120A User’s Manual...
  • Page 43 Set 'nat -vs' Option -dmz Set 'nat -dmz' Option (null) Show NAT Setting In DMZ item includes Index Command Description Show 'nat -dmz' Option EnableDMZ EnableDMZ Set DMZ IP address (null) Show DMZ Setting AirLive VoIP-111A / 120A User’s Manual...
  • Page 44 -pass Set Login Password (null) Show DDNS Setting -15- sntp function Index Command Description Show 'sntp' Option Enable SNTP Client -off Disable SNTP Client -ip1 Set SNTP Server1 IP -ip2 Set SNTP Server2 IP AirLive VoIP-111A / 120A User’s Manual...
  • Page 45 Index Command Description Show 'phone' Option -autoanswer phone auto answer -vol Volume setting -block Block Incoming call -ring Set Melody Ringer -forward Auto-forward Incall to Phone[0-9] in Book (null) Show Phone Setting AirLive VoIP-111A / 120A User’s Manual...
  • Page 46 Index Command Description Show 'slic' Option -ring Issue Ring signal read slic addr write slic addr read all slic reg (null) Show slic register -29- ver function is to show Firmware Version. AirLive VoIP-111A / 120A User’s Manual...

  • Page 47: How To Make A Phone Call

    C. If B is still on hold and A would like to talk to B again, A can release the hold off B and continue the original conversation. AirLive VoIP-111A / 120A User’s Manual...
