- Page 1 USB-25G User Manual Sep. 3, 2021 Ver. 1.0...
- Page 2 Overview 2.5G Super Speed Data Transfer The AirLive USD-25G is a USB-A to 2.5G Ethernet Adapter, supporting bus-powered, power-saving mode, and Wake-On-LAN functions. This portable design allows you to conveniently carry anywhere, simply connect the adapter to the computer via USB-A port without external power needed.
- Page 3 1.1 Connecting the USB-25G Connect the USB 3.1 connector of the USB-25G to any USB Type A port (1.0, 2.0, 3.0, 3.1). Note that when using a USB 1.0 or USB 2.0 port on your device you will not be able to get the maximum speed of the USB-25G at 2500Mbps.
- Page 4 1.2 USB 3.1 The USB 3.1 connector of the USB-25G has a blue color on the inside this means the connector is USB 3.0/3.1 when your device also has Blue USB connector it means you can run at the Super Speed.
- Page 5 Device Interface 1 x USB 3.1 type A, 1 x RJ-45 100M/1G/2.5Gbps LAN port Standard Support USB3.1/3.0/2.0/1.1 compliant, IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX, IEEE802.3ab 1000BASE-T, IEEE802.3bz 2.5GBASE-T, IEEE802.1p, Flow control (IEEE802.3 Annex31B) Support Operation Win7/Win8.1/Win10/Win11（32/64bit）Linux/MAC System Operating 0°C to +60°C Temperature Storage -20°C to +70°C Temperature...
- Page 6 AirLive Technology Corp. AirLive Technology Corp has made the best effort to ensure the accuracy of the information in this user’s guide. However, we are not liable for the inaccuracies or errors in this guide.
