SMA WINDY BOY 3600TL User Manual
SMA WINDY BOY 3600TL User Manual

SMA WINDY BOY 3600TL User Manual

Wind power inverter

Advertisement

Quick Links

CONTaCT
If you have technical problems, first contact your installer. The following information is required in
order to provide you with the necessary assistance:
• Inverter device type
• Serial number of inverter
• Type of connected small wind turbine system
• Event number or display message of the inverter
• Optional equipment (e.g. communication devices)
SMa Solar Technology aG
Sonnenallee 1
34266 Niestetal, Germany
www.SMA.de/en
SMa Serviceline
Inverters:
+49 561 9522 1499
Communication:
+49 561 9522 2499
Fax:
+49 561 9522 4699
E-Mail:
Serviceline@SMA.de
Installer contact

ExPLaNaTION Of SYMBOLS

Symbols on the Inverter
Operation display.
An error has occurred. Please inform your installer immediately.
Bluetooth ® . Bluetooth communication active.*
Symbols on the Type Plate
Warning: dangerous electrical voltage.
The inverter operates at high voltages. All electrical work
on the inverter must be carried out by qualified personnel
only.
Beware of hot surface.
The inverter can become hot during operation. Avoid contact during operation.
Please observe enclosed documentation.
The inverter must not be disposed of together with the household waste.
For more information on disposal, please see the installation guide included upon
delivery.
CE mark. The inverter complies with the requirements of the applicable EC
guidelines.
RAL quality mark for solar products. The inverter complies with the requirements of
the German Institute for Quality Assurance and Labeling.
Direct current (DC)
Alternating current (AC)
The inverter is protected against penetration by dust particles and water jets from
any angle.
The inverter is transformerless.
* The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use
of these marks by SMA Solar Technology AG is under license.
Wind Power Inverter
WINDY BOY 3600TL / 5000TL
User Manual
WB36TL_50TL-BEN101310 | IMEN-WB36_50TL | Version 1.0
VISUaL INSPECTION, MaINTENaNCE aND CLEaNING
Visual inspection
Check the inverters and the cables for visible external damage. Contact your installer if you find any
damage. Do not perform any repair work yourself.
Maintenance and Cleaning
Have correct operation of the inverter regularly checked by your installer.
GLOSSarY
aC
Abbreviation for "alternating current".
Bluetooth
Bluetooth is a radio technology that allows the inverter and other communication devices to
communicate with each other. Bluetooth communication does not require visual contact between
the devices.
DC
Abbreviation for "direct current".
Electronic Solar Switch (ESS)
The Electronic Solar Switch is part of the inverter's DC switch-disconnector. Electronic Solar Switch
must be securely inserted into the bottom of the inverter and may
only be removed by qualified personnel.
EN
