Configuring ISG as a RADIUS Proxy
Command or Action
Step 5
session-identifier {attribute number | vsa
vendor id type number}
Example:
Router(config-locsvr-proxy-radius)#
session-identifier attribute 1
Step 6
calling-station-id format {mac-address |
msisdn}
Example:
Router(config-locsvr-proxy-radius)#
calling-station-id format msisdn
Step 7
accounting method-list {method-list-name |
default}
Example:
Router(config-locsvr-proxy-radius)# accounting
method-list fwdacct
Step 8
accounting port port-number
Example:
Router(config-locsvr-proxy-radius)# accounting
port 2222
Step 9
authentication port port-number
Example:
Router(config-locsvr-proxy-radius)#
authentication port 1111
Step 10
key [0 | 7] word
Example:
Router(config-locsvr-proxy-radius)# key radpro
Step 11
timer {ip-address | request} seconds
Example:
Router(config-locsvr-proxy-radius)# timer
ip-address 5
Step 12
end
Example:
Router(config-locsvr-proxy-radius)# end
How to Configure ISG as a RADIUS Proxy
Purpose
(Optional) Correlates the RADIUS server requests of a
session and identifies the session in the RADIUS proxy
module.
Specifies the calling-station-id format.
Specifies the server to which accounting packets from
RADIUS clients are forwarded.
Note By default, ISG RADIUS proxy handles accounting
packets locally.
Specifies the port on which the ISG listens for accounting
packets from RADIUS clients.
The default port is 1646.
•
Specifies the port on which the ISG listens for
authentication packets from RADIUS clients.
The default port is 1645.
•
Configures the encryption key to be shared between ISG
and RADIUS clients.
0 specifies that an unencrypted key will follow.
•
7 specifies a hidden key will follow.
•
Specifies the amount of time ISG waits for the specified
event before terminating the session.
• —Specifies the amount of time ISG waits
ip-address
for an IP address to be assigned to the session.
—Specifies the amount of time ISG waits to
•
request
receive an Access-Request from a client device.
Exits the current configuration mode and returns to
privileged EXEC mode.
