North Star M2681781B Owner's Manual

3-point sprayer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instructions for Assembly, Testing, Operation, Servicing, and Storage
NorthStar 3-Point Sprayer: Category 1 tractor implement for outdoor use
READ and UNDERSTAND the Owner's Manual completely before using this sprayer.
Assemble, test, and use only in accordance with the Owner's Manual instructions.
READ and FOLLOW chemical label instructions. Pesticides are hazardous chemicals.
KNOW emergency procedures BEFORE handling chemicals. Sprayer leaks, bodily chemical
contact, poisoning, and spills require immediate response.
AVOID inhaling, ingesting, or coming into contact with any chemicals.
WEAR personal protective gear when filling, using, cleaning, and servicing the sprayer.
KEEP sprayer and spray materials away from children and pets. Pesticides are especially toxic
to them.
EXERCISE CAUTION in vehicle handling when towing/hauling a filled sprayer to avoid loss
of control or sprayer overturning.
DO NOT TURN ON POWER to sprayer until ready to spray in order to avoid unintentional
spray release.
Improper use of the sprayer or handling of chemicals could result in serious injury or illness
to the operator or nearby persons/animals, or could cause damage to the environment.
** This sprayer is recommended for use in spraying non-flammable liquids such as pesticides, water for plants/trees
or dust control, ice control chemicals, or water-based non-flammable sealants or stains for outdoor wood surfaces.
However, WE RECOMMEND THAT THE SPRAYER NOT BE USED FOR OTHER PURPOSES ONCE IT HAS
BEEN USED FOR SPRAYING PESTICIDES. Any chemical will leave some residual in the tank liner or sprayer
components, even after the sprayer has been properly cleaned. These residual chemicals can have unexpected
effects on future uses. For example, spraying water or other liquids that are contaminated with residual pesticide
may result in unforeseen hazards to plant or animal life.
Any Questions, Comments, Problems, or Parts Orders
Call NorthStar Product Support 1-800-270-0810
Owner's Manual
with agricultural pesticides and other liquids**
M2681781B
MODEL NUMBER: 2681781
SERIAL NUMBER: _________________
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M2681781B and is the answer not in the manual?

Questions and answers

Related Manuals for North Star M2681781B

Summary of Contents for North Star M2681781B

  • Page 1 M2681781B MODEL NUMBER: 2681781 SERIAL NUMBER: _________________ Owner's Manual Instructions for Assembly, Testing, Operation, Servicing, and Storage NorthStar 3-Point Sprayer: Category 1 tractor implement for outdoor use with agricultural pesticides and other liquids** WARNING READ and UNDERSTAND the Owner's Manual completely before using this sprayer.
