- Page 1 DC E1000 Digital Camera User Manual Welcome...
- Page 2 Further, BenQ Corporation reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of this company to notify any person of such revision or changes.
-
Page 3: Table Of Contents
Table of Contents .............. 1 1. Touring Your Camera ..........1 1.1 Checking the package contents ............1 1.2 Camera components ............1 1.2.1 Front view ............. 2 1.2.2 Rear view ............. 2 1.2.3 LED indicators ..........3 2. Preparing Your Camera for Use ............ - Page 4 ..........15 3.7 Other recording functions ..........15 3.7.1 Setting the quality ..........15 3.7.2 Setting the metering ........15 3.7.3 Setting the white balance ........... 16 3.7.4 Setting the ISO ..........16 3.7.5 Setting the Exposure ..........16 3.7.6 Setting the AEB ..........
-
Page 5: Touring Your Camera
• All electronic accessories (such as USB, AV cable, adapter, charger, and battery) are designed to work with this BenQ Digital Camera only. Do not use them with other Digital Camera to avoid possible damage. Camera components 1.2.1 Front view... -
Page 6: Rear View
1.2.2 Rear view LCD monitor Zoom-out or thumbnail Zoom-in PLAY mode Menu Navigator -- four-way control and OK MODE button Delete / PASM (Av/Tv/M) mode Tripod mount 10. PC (USB) / AV Out terminal 11. Battery/SD memory card cover 12. Strap eyelet 1.2.3 LED indicators Indicator State... -
Page 7: Preparing Your Camera For Use
Preparing Your Camera for Use Installing the batteries We highly recommend that you use only the specified rechargeable lithium-ion battery for your camera. Make sure that the power of the camera is off before inserting or removing the battery. To insert the battery: 1. -
Page 8: Charging The Battery
Charging the battery The battery charge status affects the performance of the camera. To maximize the performance and life of the battery, it is recommended that you fully charge the battery using the specified charger set (charger and AC power adapter), and then fully discharge it through the normal use at least one time. - Page 9 • Be sure to format the SD memory card with this camera before the initial use. • To prevent valuable data from being accidentally erased from an SD memory card, you can slide the write-protect tab (on the side of the SD memory card) to “LOCK”.
-
Page 10: Using The Camera
Using the Camera Navigator You can use the Navigator with four-way control and one button to access numerous controls of your camera. or Play (video playback only) Focus mode or left Down Flash mode or right LCD monitor information (REC mode) 9999 9999 -1.0... -
Page 11: Getting Started
Getting started 3.3.1 Turning the power on / off • Press the [ ] button until the digital camera turns on. Or, you can press the [ button when the camera is off to turn on the camera. • To turn the power off, press the [ ] button again. -
Page 12: Using The Flash
3.3.5 Using the flash The flash is not only for taking pictures when there is insufficient light, but also when the subject is in shade or in backlight conditions. Pressing the flash button cycles your camera through the various flash modes. The flash will not activate when continuous shooting or movie recording. -
Page 13: Using The Zoom Function
Icon Drive mode Description Burst Keep pressing the shutter button fully to take a continuous shooting. Release the shutter button to stop shooting. Note that the LCD is temporarily turned off during shooting to save power. Timer Burst Press and release the shutter. After a 2-second countdown, the camera will start taking a continuous shooting. -
Page 14: Menu Options
Menu options 3.4.1 Changing the mode You can record images and voices in the REC mode. And using the PLAY mode to replay, delete, or edit images on the LCD monitor. 3.4.1.1 Switching between REC mode and PLAY mode • In REC mode, press the PLAY button to switch to the PLAY mode. -
Page 15: Using The Menus
Icon Mode Description Food Higher saturation makes food more appetizing. Candle Light Makes a picture look warm, and thus captures the mood under candle light source. Flash is always off. Party Captures the party atmosphere usually under indoor light source. Text Enhances the black &... -
Page 16: Rec Menu List (Movie)
Menu item Available settings Metering White Balance 1200 1600 Exposure -2.0 EV ~ +2.0 EV Drive Mode Off / Off / On Highlight Off / Sharpness Effect Normal/ B&W / Sepia / Negative / Red / Green / Blue Date Stamp Off / Date / Date &... -
Page 17: Setup Menu List
3.4.3.1 Setup menu list Menu item Functions Sounds [Shutter] Sets the shutter sound on and off. [Start-up] Sets a type of the start-up sound. [Beep] Sets the operation sound on and off. [Volume] Adjusts the volume of the shutter sound, start- up sound, beep and playback sound. -
Page 18: Recording Movie Clips
Menu item Functions [Computer] Sets the USB mode to connect the camera with a printer or computer. [Printer] Start-up Image Sets a recorded image as the start-up image. Format To erase all data stored in the memory card if you are using a card, or all data stored in the internal memory if there is no card inserted. -
Page 19: Other Recording Functions
Other recording functions 3.7.1 Setting the quality Compression Purpose Super Fine Shoot higher quality images. Fine Shoot normal quality images. Normal Shoot for more images. 3.7.2 Setting the metering There are 3 different light metering options available on your camera. Icon Mode Description... -
Page 20: Setting The Iso
Icon Mode Description For more accurate adjustment or when the light source cannot be (Custom) specified. When this option is highlighted, press the shutter button to enter the mode. Then, point the camera at [Custom WB] something white (for example, white paper) as the reference white color. -
Page 21: Setting The Date Stamp
Icon Description Blue The image becomes bluish. 3.7.10 Setting the date stamp The Date Stamp function can be used to add a date to your pictures as you take them. 3.7.11 Setting Stabilizer Located beside the Shutter button, the Stabilizer uses a higher ISO value to avoid image blur caused by hand shake and/or subject movement. -
Page 22: Playback
Playback 3.8.1 Playing back images 1. Turn the power on, and set the camera to the PLAY mode. • The latest recorded image appears on the LCD monitor. • If there are no images stored, a message [No image] appears. 2. -
Page 23: Playing A Slide Show
3.8.5 Playing a slide show 1. Turn the power on, and set the camera to the PLAY mode. 2. Enter the slide show. • Press the button and use the [ ] / [ ] to select Slide Show and press [ MENU or the button. -
Page 24: Setting The Dpof For Printing
• Press the button toggles the on and off. Repeat this step until all images that you want to delete are displayed with an icon 5. Delete images. • Press the button, then select and press the button. All selected images MENU [Yes] will be deleted. -
Page 25: Pc Dependent Features
PC Dependent Features Bundled software The camera is supplied with the following software. To install the software, refer to the information supplied with respective CDs. ArcSoft Combines photo editing with creative enhancement and sharing PhotoImpression 5 tools that maximize your digital media experience. ArcSoft Creates multimedia presentations by combining photos and video VideoImpression 2... -
Page 26: Step 1: Connect The Digital Camera To Your Computer
4.2.1 Step 1: Connect the digital camera to your computer 1. Connect the supplied USB cable to the computer USB port and turn on the camera. 2. The LCD screen turns off when the connection to the computer has been successfully completed. -
Page 27: Troubleshooting
Troubleshooting Refer to the symptoms and solutions listed below before shipping your camera for service. If the problem persists, contact your local reseller or service center. Symptom Cause Solution The camera cannot be There is no battery or the battery is Insert the battery correctly. - Page 28 Symptom Cause Solution I cannot download The free space on the hard disk of Ensure that the hard disk has enough images. your computer is insufficient. space for running Windows and that the drive for loading image files has free space equal to or greater than the memory card in the camera.
-
Page 29: Specifications
Specifications Image Sensor 1/1.8-inch CCD Effective Pixels: 10.0 Mega pixels LCD Display 3.0” LTPS TFT LCD (230K dots) Lens Focal Length: f = 7.4 (W)~ 22.2 (T) (35 mm film equivalent: 35.1 ~ 105.3 f-number: f/2.8 (W) ~ f/5.1 (T) Focusing TTL Auto Focus Range: Macro: 10 cm, Normal: 50 cm ~ infinity... -
Page 30: Service Information
Service Information Technical Support For free driver updates, product information and news releases, visit the following web site: http://www.BenQ.com Service Information...
