IS4225 ScanGlove
Laser Bar Code Scanner
Installation and User's Guide

Advertisement

loading

  Related Manuals for Honeywell IS4225 ScanGlove

  Summary of Contents for Honeywell IS4225 ScanGlove

  • Page 1 ® IS4225 ScanGlove Laser Bar Code Scanner Installation and User’s Guide...
  • Page 2 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.
  • Page 3: Table Of Contents

    ABLE OF ONTENTS Introduction......................1 Scanner and Accessories..................1 Scanner Installation ....................2 Scanner Configuration to the Host System............3 Parts of the Scanner..................... 4 Visual Indicators ....................5 Audible Indicators ....................6 Labels........................7 Maintenance......................8 Depth of Field ....................... 9 Object Detection Device ..................
  • Page 5: Introduction

    NTRODUCTION ® The IS4225 ScanGlove is a fully automatic single-line laser barcode scanner. The ScanGlove is designed to be used as a “hands-free” wearable scanner or a stationary desktop scanner. Every ScanGlove is equipped with an object detection technology that allows the scanner to read bar codes automatically as the operator presents the bar code to the scanner.
  • Page 6: Scanner Installation

    CANNER NSTALLATION Turn off power to the host system. Connect the communication cable to the proper port on the host device. Turn on power to the host system. When the IS4225 first receives power, the red LED will flash, the green LED will flash, and then the scanner will beep once.
  • Page 7: Scanner Configuration To The Host System

    CANNER ONFIGURATION TO THE YSTEM The IS4225 is shipped from the factory pre-configured to a set of default parameters. It may be necessary to change the default parameters to match the host system’s requirements or to enable additional scanner functions. For a list of possible parameter settings, refer to the Default Settings section of this guide.
  • Page 8: Parts Of The Scanner

    ARTS OF THE CANNER Figure 1. Scanner Parts Item Description Green LED  When a bar code is read successfully, the green LED will flash. Red LED  When the red LED is illuminated, the laser is on.  Red Output Window (Laser Aperture) Object Detection Device If a specified time has elapsed without any scanning, the unit will ...
  • Page 9: Visual Indicators

    ISUAL NDICATORS There is a red and a green LED located on the top of the scanner. When the scanner is on, the flashing or constant, illumination of the LEDs indicates the status of the current scan and the scanner. No Red LED Illumination of the LEDs will not occur if the scanner has remained dormant for a specified time and the scanner is...
  • Page 10: Audible Indicators

    UDIBLE NDICATORS The scanner provides sounds to signal certain conditions. To change the volume (four settings are available) or turn the beeper off, refer to Scanner Operation: Beeper Options in the MetroSelect Single-Line Configuration Guide ( 02544). One Beep When the scanner first receives power, the red LED will flash, followed by the green LED, and then the scanner will beep once.
  • Page 11: Labels

    ABELS Each IS4225 has a serial number label and a laser class label on the bottom of the unit. These labels provide important information like; date and location of manufacture, model number, serial number, caution statements and laser class. There is also text molded into the top of the case near the window that says, “AVOID EXPOSURE - laser light emitted from this aperture”.
  • Page 12: Maintenance

    AINTENANCE Smudges and dirt on the unit’s window can interfere with the unit’s performance. If the window requires cleaning, use only a mild glass cleaner containing no ammonia. When cleaning the window, spray the cleaner onto a lint free, non- abrasive cleaning cloth then gently wipe the window clean.
  • Page 13: Depth Of Field

    EPTH OF IELD Minimum Bar Code Element Width Standard 10.4 Figure 3. Depth of Field Specifications are subject to change without notice.
  • Page 14: Object Detection Device

    BJECT ETECTION EVICE An object detection device located behind the window initiates the scanning process. The device is active as long as power is applied to the unit. When the device detects an object, the green LED will flash. When the laser decodes a bar code, the scanner transmits the data to the host system and emits a beep to show that decoding is complete.
  • Page 15 BJECT ETECTION EVICE Figure 4. Object Detection Field Please note certain ambient light conditions may interfere with the object detection mechanism, resulting in false activation of the scanner. To mitigate the problem, please try one of the following suggestions: Avoid mounting the scanner directly facing the ambient light source. Avoid mounting the scanner facing a light-colored or reflective surface.
  • Page 16: Specifications

    PECIFICATIONS IS4225 S PECIFICATIONS PERATIONAL Light Source: 650 nm ± 10nm VLD Depth of Field: 25 mm to 203 mm (1" to 8") for .33 mm (13 mil) bar code Width of Scan Field: 70 mm (2.8”) @ 25mm (1.0”); 280 mm (11”) @ 200 mm (8”) Scan Speed: 52 scans lines per second Scan Pattern:...
  • Page 17: Default Settings

    EFAULT ETTINGS Many functions of the scanner can be "configured", that is enabled or disabled. The scanner is shipped from the factory configured to a set of default conditions. All factory default parameters have an asterisk ( * ) in the default column of the charts on the following pages .
  • Page 18 EFAULT ETTINGS Light Keyboard Parameter Default RS232 Wedge  No Two Second Timeout   Razzberry Tone on Timeout   No Tone on Timeout   Three Beeps on Timeout     Beep Before Transmit   ...
  • Page 19 EFAULT ETTINGS Light Keyboard Parameter Default RS232 Wedge    Prefix ID for UPC/EAN       Suffix ID for UPC/EAN    Bars High   Spaces High   Transmit as Scanned  ...
  • Page 20 EFAULT ETTINGS Light Keyboard Parameter Default RS232 Wedge     Set Minimum Character Length         Set Character Lock Length         Transmit UPC-A Number Sys ...
  • Page 21 EFAULT ETTINGS Light Keyboard Parameter Default RS232 Wedge     Matrix 2 of 5 Check Digit         Hong Kong Matrix 2 of 5         MSI-Plessy Test of Check Digit ...
  • Page 22 EFAULT ETTINGS Light Keyboard Parameter Default RS232 Wedge Retransmit of Same Code    1st Configurable Prefix ID    2nd Configurable Prefix ID    1st Configurable Suffix ID    2nd Configurable Suffix ID ...
  • Page 23: Troubleshooting Guide

    ROUBLESHOOTING UIDE The following guide is for reference purposes only. Contact a customer service representative to preserve the limited warranty terms on page 24. YMPTOMS OSSIBLE AUSE OLUTION Make sure the cable is plugged No Power is being No LEDs, beep and there into the host.
  • Page 24: Regulatory Compliance

    EGULATORY OMPLIANCE Safety ITE Equipment IEC 60950-1, EN 60950-1 Laser Laser Class 2: IEC 60825-1:1993+A1:1997+A2:2001 EN 60825-1:1994+A2:2001+A1:2002 Caution Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser light exposure. Under no circumstances should the customer attempt to service the laser scanner.
  • Page 25: Class A Devices

    EGULATORY OMPLIANCE Emissions FCC Part 15, ICES-003, CISPR 22, EN 55022 Immunity CISPR 24, EN 55024 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Class A Devices The following is applicable when the scanner cable is greater in length than 3 meters (9.8 feet) when fully extended: Les instructions ci-dessous s’appliquent aux cables de scanner dépassant 3 métres...
  • Page 26: Class B Devices

    EGULATORY OMPLIANCE Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Class B Devices The following is applicable when the scanner cable is less than 3 meters (9.8 feet) in length when fully extended: Les instructions ci-dessous s’appliquent aux cables de scanner ne dépassant pas 3 métres (9.8 pieds) de long en extension maximale: Folgendes trifft zu, wenn das Scannerkabel kürzer als 3 Meter ist:...
  • Page 27: Patents

    ATENTS For patent information, please refer to www.honeywellaidc.com/patents.
  • Page 28: Limited Warranty

    IMITED ARRANTY Honeywell International Inc. ("HII") warrants its products and optional accessories to be free from defects in materials and workmanship and to conform to HII’s published specifications applicable to the products purchased at the time of shipment. This warranty does not cover any HII product which is (i) improperly installed or used;...
  • Page 29: Index

    NDEX application ........1 immunity........21 audible........5–6 indicators......5–6, 12 autodiscriminates......12 input voltage........ 12 installation ........1 interfaces ........1 bar code ....4, 5–6, 8, 10, 19 beep ......5–6, 12, 13, 19 keyboard wedge..1, 12, 13–18 cable........1, 4, 12 caution........7, 20 labels..........
  • Page 30 NDEX razzberry tone ......6, 13 temperature......... 12 red LED .........4, 5–6 termination ........12 repair ...........24 test ..........16 RMA ..........24 test code ........19 roll, pitch, yaw......12 tones ........6, 12 RS232 ......12, 13–18 troubleshooting ......19 USB ........13–18 safety........20, 22 scan field ......
  • Page 31: Customer Support

    UPPORT Technical Assistance If you need assistance installing or troubleshooting your device, please call your distributor or the nearest technical support office: North America/Canada Telephone: (800) 782-4263 E-mail: hsmnasupport@honeywell.com Latin America Telephone: (803) 835-8000 Telephone: (800) 782-4263 E-mail: hsmlasupport@honeywell.com Brazil...
  • Page 32: Product Service And Repair

    USTOMER UPPORT Product Service and Repair Honeywell International Inc. provides service for all its products through service centers throughout the world. To obtain warranty or non-warranty service, contact the appropriate location below to obtain a Return Material Authorization number (RMA #) before returning the product.
  • Page 36 Honeywell Scanning & Mobility 9680 Old Bailes Road Fort Mill, SC 29707 www.honeywellaidc.com 00-02258 Rev E May 2010...
