  • Page 1 ™ IS3480 QuantumE Scan Engine User’s Guide...
  • Page 2 Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.

  • Page 3: Table Of Contents

    Cable Removal ....................4 Caution and Serial Number Labels ..............5 Mounting Specifications ................... 5 Installation RS232, RS232 TTL, Light Pen or Laser Emulation .......... 6 RS485 ......................7 Keyboard Wedge ....................8 Stand-Alone Keyboard ..................9 Low Speed USB (Integrated) ................10 Notes for Laser Emulation ................
  • Page 4 Troubleshooting Guide ..................26 Design Specifications ..................29 Applications and Protocols ................. 31 Configuration Modes ..................32 Upgrading the Firmware ..................33 Default Settings - Communication Parameters ........... 34 Scanner and Cable Terminations ............... 39 Regulatory Compliance Safety ......................44 EMC ....................... 45 Limited Warranty ....................

  • Page 5: Introduction Product Overview

    QuantumE™ is a miniature, omni-directional scanning engine with optional single-line scanning capability. The self-contained device is fully enclosed eliminating the need for an external window or custom enclosure. It is designed for use in OEM equipment such as price lookup systems and kiosks.

  • Page 6: Scanner And Accessories

    MVC cable series and the host connections available. MVC** Voltage Converter Cable ±12VDC to +5.2VDC Other items may be ordered for the specific protocol being used. To order additional items, contact the dealer, distributor or customer service See page 52 for contact...

  • Page 7: Maintenance

    ARTS Part No. Description 36-01822x-3 Rubber Utility Seal Other items may be ordered for the specific protocol being used. To order additional items, contact the dealer, distributor or customer service See page 52 for contact information. Maintenance Smudges and dirt on the unit's window can interfere with the unit's performance.

  • Page 8: Scanner Components

    Bend an ordinary paperclip into the shape shown. Insert the paperclip (or other small metallic pin) into the ‘pinhole’. There will be a faint ‘click’ when the cable lock is released. Pull gently on the strain-relief of the Figure 1b.

  • Page 9: Caution And Serial Number Labels

    Figure 2. Caution To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements for SELV (Safety Extra Low Voltage) according to EN/IEC 60950-1. To maintain compliance with standard CSA C22.2 No. 60950-1/UL 60950-1 and norm EN/IEC 60950-1, the power source should meet applicable performance requirements for a limited power source.

  • Page 10: Installation

    Connect AC power to the transformer. Turn on the host device. When the scanner first receives power, the blue LED will turn on; the scanner will simultaneously beep once and flash the white LED. Plugging the scanner into the serial port of the PC does not guarantee that scanned information will appear at the PC.

  • Page 11: Rs485

    Turn on the host device. Figure 5. When the scanner first receives power, the blue LED will turn on; the scanner will simultaneously beep once and flash the white LED. Plugging the scanner into the serial port of the PC does not guarantee that scanned information will appear at the PC.

  • Page 12: Keyboard Wedge

    Connect AC power to the transformer. Turn on the host device. When the scanner first receives power, the blue LED will turn on; the scanner will simultaneously beep once and flash the white LED. Powering the IS3480 directly from the host device can sometimes cause interference with the operation of the scanner or the computer.

  • Page 13: Stand-Alone Keyboard

    Figure 7. Turn on the host device. When the scanner first receives power, the blue LED will turn on; the scanner will simultaneously beep once and flash the white LED. Powering the IS3480 directly from the host device can sometimes cause interference with the operation of the scanner or the computer.

  • Page 14: Low Speed Usb (Integrated)

    Guide ( 00-02407). MLPN When the scanner first receives power, the blue LED will turn on; the scanner will simultaneously beep once and flash the white LED. Plugging the scanner into the USB port of the PC does not guarantee that scanned information will appear at the PC.

  • Page 15: Notes For Laser Emulation

    IS3480-104 Only The IS3480-104 leaves the factory with the Laser Emulation Mode enabled. If the Recall Defaults bar code is scanned while reconfiguring the scanner, the laser emulation mode will no longer be enabled. Scan the following bar code to re-enable the laser emulation interface.

  • Page 16: Scanner Operation

    Configurable Button Functions below. The scanner returns to the primary scan pattern mode after a double click of the button or if the unit has not scanned a bar code for the duration of a pre-configured time limit.
  • Page 17 LICK ODE WITH NABLED For illustration purposes the unit’s primary scan pattern has been set to all scan lines (omnidirectional reading) and the secondary pattern has been set to single-line (menu reading) with a 10 second button click timeout configured.
  • Page 18 LICK ODE WITH ISABLED For illustration purposes the unit’s primary scan pattern has been set to all scan lines (omnidirectional reading) and the secondary pattern has been set to single-line (menu reading) with a 10 second button click timeout configured.
  • Page 19 UTTON ODE WITH NABLED For illustration purposes the unit’s primary scan pattern has been set to all scan lines (omnidirectional reading) and the secondary pattern has been set to single-line (menu reading) with a 10 second button click timeout configured.
  • Page 20 UTTON ODE WITH ISABLED For illustration purposes the unit’s primary scan pattern has been set to all scan lines (omnidirectional reading) and the secondary pattern has been set to single-line (menu reading) with a 10 second button click timeout configured.

  • Page 21: Sweet Spot Mode

    PERATION Sweet Spot Mode The sweet spot mode is used to determine where the maximum read rate area or “sweet spot” is located for a specific bar code type. When activated this mode provides visual and audible feedback indicating how the scanner is scanning.

  • Page 22: Audible Indicators

    When the IS3480 is in operation, it can provide audible feedback. These sounds indicate the status of the scanner. Eight settings are available for the tone of the beep (normal, six alternate tones and no tone). For instruction on how to change the tone of the beeper, refer to the MetroSelect Configuration Guide (00-02407).

  • Page 23: Visual

    CANNER PERATION Visual Indicators There are four LEDs located on the top of the IS3480. When the scanner is on, the flashing or constant illumination of the LEDs indicates the status of the current scan and the scanner. No LEDs The LEDs will not be illuminated if the scanner is not receiving power from the host or transformer.

  • Page 24: Failure

    Continuous Razzberry Tone with Both LEDs Off If, upon power up, the scanner emits a continuous razzberry tone, then the scanner has an electronic failure. Return the unit to an authorized service center for repair.

  • Page 25: Depth Of Field Specifications

    CANNER PERATION Depth of Field Specifications* Normal Scan Zone Specifications are based on a 0.33 mm (13 mil) bar code. Figure 9. Normal Depth of Field * All specifications are subject to change without notice.

  • Page 26: Reduced Scan Zone

    CANNER PERATION Depth of Field Specifications* Reduced Scan Zone Specifications are based on a 0.33 mm (13 mil) bar code. Figure 10. Reduced Depth of Field * All specifications are subject to change without notice.

  • Page 27: Depth Of Field By Bar Code Element Width

    CANNER PERATION Depth of Field by Bar Code Element Width* Normal Scan Zone INIMUM LEMENT IDTH mils Figure 11. Normal Scan Zone by Bar Code Element Width * All specifications are subject to change without notice.

  • Page 28: Reduced Scan Zone

    CANNER PERATION Depth of Field by Bar Code Element Width* Reduced Scan Zone INIMUM LEMENT IDTH mils Figure 12. Reduced Scan Zone by Bar Code Element Width * All specifications are subject to change without notice.

  • Page 29: Ir Activation Range

    Any movement detected by the IR in the activation area will cause the scanner to exit power save mode. The laser will automatically turn back on preparing the scanner for bar code recognition, decoding and transmission.

  • Page 30: Troubleshooting Guide

    ROUBLESHOOTING UIDE The following guide is for reference purposes only. Contact a Honeywell representative to preserve the limited warranty terms on page 47. Symptoms Possible Cause(s) Solution All Interfaces Check the transformer, outlet The unit has no No power is being and power strip.
  • Page 31 ROUBLESHOOTING UIDE Symptoms Possible Cause(s) Solution All Interfaces The unit scans If the scanner is setup to support The scanner is a bar code, but ACK/NAK, RTS/CTS, configured to support locks up after XON/XOFF or D/E, verify that some form of host...
  • Page 32 Make sure that the proper PC type (ie. AT or PS2) is selected. The unit scans The unit may not be Verify correct country code and but the data is configured correctly.

  • Page 33: Design Specifications

    /Serial Emulation), Laser Emulation, RS232 TTL Print Contrast: 35% minimum reflectance difference Up to 80 data characters No. Characters Read: Maximum number will vary based on symbology and density. Beeper Operation: 7 tones or no beep Blue = laser on, ready to scan Indicators (LED):...
  • Page 34 275 mA typical at 5VDC Standby Current: 200 mA typical at 5VDC DC Transformers: Class II; 5.2VDC @ 1A For regulatory compliance information, see pages 44 – 46. Environmental Operating Temperature: -20°C to 40°C (-4°F to 104°F) Storage Temperature: -40°C to 60°C (-40°F to 140°F)

  • Page 35: Applications And Protocols

    PPLICATIONS AND ROTOCOLS The model number on each scanner includes the scanner number and factory default communications protocol. ERSION CANNER OMMUNICATION ROTOCOL DENTIFIER RS485  and Full RS232C RS232 Low Speed USB, Keyboard Emulation or Serial Emulation Full RS232C/Light Pen Emulation...

  • Page 36: Configuration Modes

    The IS3480 Series scanner has three modes of configuration. • Bar Codes The IS3480 can be configured by scanning the bar codes included in the Single-Line Configuration Guide or the Supplemental Configuration Guide. The manuals are available for download at www.honeywellaidc.com.

  • Page 37: Upgrading The Firmware

    To upgrade the firmware in the IS3480: Plug the scanner into a serial communication port on the host system. Start the MetroSet2 software. Click on the plus sign (+) next to POS Scanners to expand the supported scanner list. Choose the Quantum E/T from the list.
  • Page 38 The scanner is shipped from the factory configured to a set of default conditions. The default parameter of the scanner has an asterisk ( * ) in the charts on the following pages. If an asterisk is not in the default column then the default setting is Off or Disabled.
  • Page 39    ID “01” GS1 DataBar Limited       Check Digit   Bars High as Code 39         Spaces High as Code 39    ...

  • Page 40: Default Settings - Communication Parameters

         Expand UPC-E           Convert UPC-A to EAN-13       Transmit Lead Zero on         ...
  • Page 41          Carriage Return       Line Feed - disabled by          default in KBW    Tab Prefix ...
  • Page 42          Five Digit Redundancy       100 msec to Find Supplement       Programmable in       100msec steps (MAX 800 msec) as code ...

  • Page 43: Scanner And Cable Terminations

    CANNER AND ABLE ERMINATIONS Scanner Pinout Connections The IS3480 scanner interfaces terminate to a 10-pin modular socket. The serial number label indicates the interface enabled when the scanner is shipped from the factory. Figure 14. IS3480-47 Keyboard Wedge IS3480-41 and Stand-Alone Keyboard...
  • Page 44 RS232 Transmit Output RS232 Receive Input RTS Output (TTL RS232) / Flip Sense CTS Input (TTL RS232) / Trigger Emulation Output DTR Input (TTL RS232) / Scan Enable Receive (TTL RS232) / Good Read Transmit (TTL RS232) / Scan Data...
  • Page 45 Aux +5V: Power out. Can supply up to 100mA @ 5V. Good Read: Open-collector output. Low-going 20mA output for duration of 32 ms at a baud rate of 9600. Represents a successful bar code read. Can be used to drive an external LED. Requires an external current limiting resistor of 182 ohms.
  • Page 46 CANNER AND ABLE ERMINATIONS Cable Connector Configurations (Host End) “Standard” PowerLink Cable 53-53000x-3 coiled or 59-59000x-3 straight Function Shield Ground RS232 Transmit Output RS232 Receive Input DTR Input/Light Pen Source Power/Signal Ground Light Pen Data CTS Input 9-Pin D-Type Connector...
  • Page 47 PC Clock No Connect Honeywell will supply an adapter cable with a 5-pin DIN male connector on one end and a 6-pin mini DIN female connector on the other. According to the termination required, connect the appropriate end of the adapter cable to the PowerLink cable, leaving the necessary termination exposed for connecting to the keyboard and the keyboard port on the PC.

  • Page 48: Regulatory Compliance

    Never attempt to look at the laser beam, even if the scanner appears to be nonfunctional. Never open the scanner in an attempt to look into the device. Doing so could result in hazardous laser light exposure. The use of optical instruments with the laser equipment will increase eye hazard.

  • Page 49: Emc

    Folgendes trifft zu, wenn das Scannerkabel länger als 3 Meter ist: This equipment has been tested and found to comply with limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 50: Class B Devices

    If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...

  • Page 51: Limited Warranty

    HII without a Return Materials Authorization, which may be obtained by contacting HII. In the event that the product is returned to HII or its authorized service center within the Warranty Period and HII determines to its satisfaction...
  • Page 52 All provisions of this Limited Warranty are separate and severable, which means that if any provision is held invalid and unenforceable, such determination shall not affect the validity of enforceability of the other provisions hereof. Use of any peripherals not provided by the manufacturer may result in damage not covered by this warranty.

  • Page 53: Patents

    ATENTS For patent information, please refer to www.honeywellaidc.com/patents.

  • Page 54: Indicators Audible

    Audible Indicator .. 12, 18–20, 26–28 Modes........20 Firmware ........33 Flash ROM ......1, 33 Bar Code ..18–20, 26–28, 29, 32 Bar Width ........29 Beep ....18, 19, 20, 26–28 Host ........26–28 Blue LED ....18–20, 26–28 Button ......
  • Page 55 Button ........17 Omnidirectional ....12–17 Primary ......12–17 Primary ......12–17 Secondary ......12–17 Secondary ......12–17 Sweet Spot Mode ....17, 38 Single-Line ......12–17 Motor Speed ........ 29 Scan Speed ........ 29 Mounting Specifications ....5 SELV ........6–10 Single-Line ......

  • Page 56: Customer Support

    USTOMER UPPORT Technical Assistance If you need assistance installing or troubleshooting your device, please call your distributor or the nearest technical support office: North America/Canada Telephone: (800) 782-4263 E-mail: hsmnasupport@honeywell.com Latin America Telephone: (803) 835-8000 Telephone: (800) 782-4263 E-mail: hsmlasupport@honeywell.com...

  • Page 57: Product Service And Repair

    USTOMER UPPORT Product Service and Repair Honeywell International Inc. provides service for all its products through service centers throughout the world. To obtain warranty or non-warranty service, contact the appropriate location below to obtain a Return Material Authorization number (RMA #) before returning the product.
  • Page 58 USTOMER UPPORT Online Product Service and Repair Assistance You can also access product service and repair assistance online at www.honeywellaidc.com.
