Homeowner's Installation and Operating Manual

If this heater is not properly installed, operated, and maintained, a house fire may result.

For safety, follow all installation, operation and maintenance directions. Contact local

building officials about restrictions and installation inspection requirements in your

area.

DO NOT DISCARD THIS MANUAL: Retain for future use

SAFETY NOTICE

Convection

Heater

Models: 2460CE

2461CE

2462CE

For use in Europe

30003847 3/10 Rev. 3

Table of Contents

Need help?

Do you have a question about the 2460CE and is the answer not in the manual?

Questions and answers

Summary of Contents for DutchWest 2460CE

Page 1 Convection Heater Models: 2460CE 2461CE 2462CE For use in Europe Homeowner’s Installation and Operating Manual SAFETY NOTICE If this heater is not properly installed, operated, and maintained, a house fire may result. For safety, follow all installation, operation and maintenance directions. Contact local building officials about restrictions and installation inspection requirements in your area.
Page 2: Table Of Contents
Dutchwest ® The Dutchwest models covered in this Owner’s Guide have been tested to current stan- dards. The test standards utilized were UL 1482 for the United States and EN13240:2001 + A2:2004 for Europe. Dutchwest models are not listed for mobile home installations.
Page 3: Specifications
467 mm (18¹⁄₄”) Dutchwest 375 mm (14³⁄₄”) 380 mm (14⁵⁄₈”) 430 mm (17”) 683 mm (6³⁄₄”) specs 690 mm (7”) 763 mm (30¹⁄₈”) 754 mm (9³⁄₄”) 760 mm (30”) 840 mm (33”) 6/27/00 djt Fig. 1 Dutchwest Convection Heater specifications. 30003847...
Page 4: Installation
Tile Lined Chimney Types Masonry Chimney Your Dutchwest Convection Heater must be connected to a sound masonry chimney that meets local codes, a relined masonry chimney that meets local codes, or to ST41 an approved prefabricated metal chimney. Whatever Fig.
Page 5 Dutchwest ® Prefabricated Chimneys d) Cast iron fluepipes complying with BS 41: 1973 (1998). These should be an internal diameter of 150 mm (6”) Flue Pipes with a spigot and socket joint should be and be of the twin wall insulated construction that has fitted with the socket facing upwards, to contain con- been approved for solid fuel use (e.g.
Page 6 Dutchwest ® 2. Secure each joint between sections of chimney con- Double-Wall Connector nector, including telescoping joints, with at least three Information on assembling and installing double-wall sheet metal screws. connectors is provided by the manufacturer of the 3. Secure the chimney connector to the chimney. In- double-wall pipe.
Page 7 Dutchwest ® Securing the Connector Thimble Sleeve to a Masonry Chimney Flue The Dutchwest Convection heaters may be connected Elbow Thimble to either a freestanding masonry chimney or a masonry fireplace chimney. Keep Sleeve Freestanding Installations End Flush with Flue...
Page 8 Appliance cover must be mount- ed on non-combustible Doors Doors spacers at least 5 mm (1”) clear of the wall. Your Dutchwest Hearth Surface Free of Com- dealer or your local At least bustible Material building inspector can 150 mm...
Page 9 Hearth rugs do not satisfy the requirements for floor Floor Protection for Fireplace Installations protection. You may install your Dutchwest Convection Heater in REMINDER- FIREPLACE INSERT INSTALLATIONS an existing fireplace as a fireplace insert with no legs,* WITHOUT LEGS ARE PERMISSIBLE ONLY IF THE or with the standard legs attached.
Page 10 ® Minimum side clearance from combustible walls Clearances 610 mm (24”) for Model 2460CE and 700 mm (27Z\x”) As with any solid fuel heating stove, extremely high for Models 2461CE, 2462CE measured from the surface temperatures can occur, particularly in the side edge of the stove top.
Page 11 Dutchwest ® at least at least at least 3 x D 3 x D 1.5 x D at least 1.5 x D Fluepipe at least 1.5 x D at least 1.5 x D Air space of at least 1 mm...
Page 12: Assembly
If the installation includes an optional rear heat shield, If any parts are missing or damaged, immediately notify attach it before you begin installing the chimney con- your Dutchwest dealer for replacements. Do not install nector. your stove without having all necessary parts or by us- ing damaged parts.
Page 13: Operation
Operation Heater Controls and Features Air Controls The Dutchwest Convection Heater has two air controls that regulate the amount of air drawn into the stove. Generally, more air entering the stove allows the fire to burn hotter and faster, while less air decreases heat output while prolonging the overall burn time.
Page 14 Dutchwest ® Damper Function Burn Only High-Quality Fuel The Damper is operated by moving the handle on Your heater is designed to burn natural wood only. Do the upper left side of the stove. (Fig. 19) It has two not burn other fuels. Never burn pressure-treated wood, positions: OPEN, to start the fire and load fuel, and painted or stained wood, or glossy newsprint.
Page 15 Dutchwest ® Use the Air Control Settings Primary Air Catalyst Air that Work Best for You No single combination of control settings will fit every situation. Each installation will differ depending on the 1/ turn open quality of the fuel, the amount of heat desired, and how long you wish the fire to burn.
Page 16 If this is the case, roll up a couple pieces of newspaper, place them on top of the Your Dutchwest Convection Heater accepts wood from kindling and toward the back of the stove, light them, both the front and side.
Page 17 Dutchwest ® Further suggestions... Safe Ash Handling * If the charcoal bed is relatively thick and your fuel is Ash may contain hot coals and must be treated with well-seasoned, it is possible to add fresh fuel (smaller extreme care. Ashes should be placed outdoors in a pieces first), close the door and damper, and reset the metal container with a tight-fitting lid.
Page 18: Maintenance
An occasional dusting with a dry rag will keep the ST439 gently, but firmly. painted cast iron of your Dutchwest Convection Heater looking new. dutchwest If the paint needs retouching, allow the stove to cool completely. Wire-brush areas needing to be painted.
Page 19 Adjust the gasket in any areas Lock Nut where an inadequate seal is evident. All rope-type gasketing used in the Dutchwest Con- Damper Rod vection Heater is made of fiberglass. The gasketing is 11 mm (7/16”) diameter for front and side doors and Anchor Bolt the ash door and 10 mm (3/8”) for the top plate.
Page 20 If you are unable to inspect and/or clean the chimney more likely to result from cooler-burning fires, weekly system yourself, contact your local Dutchwest dealer or cleaning may be necessary. hire a qualified chimney sweep in your area to do the At the very least, inspect the chimney connector and job.
Page 21 Replace damaged sections of haust is not routed through the combustor. Be careful prefabricated chimney. Your local Dutchwest dealer not to confuse smoke with steam from wet wood. Unlike or a chimney sweep can help determine when re- smoke, steam disappears very quickly in air.
Page 22 If a problem persists, contact your Dutchwest dealer for further advice about your particular situation. 30003847...
Page 23: Catalytic Combustor
To avoid this situation, it is important have the ability to act at a molecular level to change not to burn anything in your Dutchwest Convection these requirements. In the secondary combustion Heater that is a source of these contaminants. Particu-...
Page 24 Dutchwest ® Draft Management Your stove is only one part of a system that includes the Indoor/ Outdoor Location chimney, the operator, the fuel, and the home. The other parts of the system will affect how well the stove works.
Page 25 Dutchwest ® they ignite. With this ignition, you may hear a muffled pop- Single Venting ping sound and see a bit of smoke forced out of the stove. Your stove requires a dedicated flue. Do not connect the This condition is most likely to occur in the Spring or Fall stove to a flue used by any other appliance.
Page 26 Dutchwest ® MHSC reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. Dutchwest Convection Heater Models 2460CE, 2461CE, 2462CE Item/Description 2460CE 2461CE 2462CE 1135 Bottom 7000958 7000978 7000979...
Page 27 Dutchwest Convection Heater Dutchwest ® Models 2460CE, 2461CE, 2462CE (continued) Item/Description 2460CE 2461CE 2462CE Inner Top 700111 7001119 (See Item #61) Inner Top Ass’y (Inner Top, Web, Gasket, Tabs & Bolts) 0000003 0000004 0000016 Inner Top Ass’y (Inner Top, Web, All Hardware, Baffle,...
Page 28 Dutchwest ® 30003847...
Page 29 Dutchwest ® 30003847...
Page 30 Dutchwest ® 30003847...
Page 31: Warranty
If a defect is noted within the warranty period, the customer should con- Any replacement catalyst will be warranted under the terms of the tact a Dutchwest Authorized Dealer or MHSC if the purchase was direct catalyst warranty for the remaining term of the original warranty. The...
Page 32 MHSC 149 Cleveland Drive • Paris, Kentucky 40361 www.mhsc.com...
