DutchWest 2477 Installation And Operating Manual

Non-catalytic convection heater
Hide thumbs Also See for 2477:
Table of Contents

Advertisement

Quick Links

See also: Homeowner's Installation and Operating Manual , Service Manual
Homeowner's Installation and Operating Manual
If this heater is not properly installed, operated, and maintained, a house fire may result.
For safety, follow all installation, operation and maintenance directions. Contact local
building officials about restrictions and installation inspection requirements in your
area.
DO NOT DISCARD THIS MANUAL: Retain for future use
SAFETY NOTICE
2278
Dutchwest
noncat
cover
5/04
R
Non-Catalytic
Convection
Heater
Model 2477
30002314 5/12 Rev. 22
