Equipment Data

EQUIPMENT DATA for water-to-water heat pumps for heating
1 TYPE AND COMMERCIAL DESCRIPTION
MODEL
2
2.1 Enclosure type acc. to EN 60 529
2.2 Installation site
PERFORMANCE DATA
3
3.1 Operating temperature limits:
Heating water supply
Cold water (heat source)
3.2
Heating water temperature spread at W10 / W35
3.3 Heating capacity / coeff.of perform.
3.4 Sound power level
3.5 Heating water flow rate at internal pressure difference
3.6 Cold water flow rate at internal pressure difference
(heat source)
3.7 Refrigerant; total charge weight
4 DIMENSIONS, CONNECTIONS AND WEIGHT
4.1 Equipment dimensions without connections
4.2 Equipment connections for heating system
4.3 Equipment connections for heat source
4.4 Weight of transport unit(s) incl. packaging
5 ELECTRICAL CONNECTION
5.1 Nominal voltage; fusing
5.2 Nominal power consumption
5.3 Starting current with soft starter
5.4 Nominal current W10 W35 / cos ϕ
6 COMPLIES WITH EUROPEAN SAFETY REGULATIONS
7 OTHER DESIGN CHARACTERISTICS
7.1 Water inside equipment protected against freezing 2)
7.2 Performance settings
7.3 Controller internal / external
1) These data characterize the size and performance capability of the system. For economic and
energetic reasons, the balance point and control need to be taken into consideration as well.
Abbreviations have the following meaning, e.g. W10 / W55: heat source temperature 10 °C
and heating water supply temperature 55 °C.
2) The heating system circulating pump and the controller of the heat pump must be ready for operation at all times.
3) See EC Declaration of Conformity
4) Please keep in mind that more space is required for pipe connection, operation and maintenance.
Subject to technical modifications
°C
°C
K
at W7 / W55 kW / ---
1)
at W10 / W50 kW / ---
1)
at W10 / W35 kW / ---
1)
dB(A)
m³/h / Pa
m³/h / Pa
type / kg
H x W x L mm
4)
inch
inch
kg
V / A
W10 W35 kW
1)
A
A / ---
2)
APPENDIX: 11.2 EQUIPMENT DATA
..9CS ..14CS
IP 20 IP 20
indoor indoor
max. 55 max. 55
+7 to +25 +7 to +25
9,5 8,8
6,9 / 2,5 12,2 / 2,5
7,7 / 3,2 13,4 / 3,6
8,3 / 5,1 13,6 / 5,2
53 55
0,75 / 7000 1,3 / 7000
2,0 / 6200 3,3 / 19000
R407C / 1,7 R407C / 1,6
1380 x 600 x 500 1380 x 600 x 500 1380 x 600 x 500 1380 x 600 x 500
G 1" int/ext G 1" int/ext
G 1¼" int/ext G 1¼" int/ext
147 151
400 / 16 400 / 16
1,62 2,64
30 (without SS) 26
2,9 / 0,8 4,8 / 0,8
3) 3)
yes yes
1 1
internal internal
Edition: 24.03.2004
11
..22CS ..27CS
IP 20 IP20
indoor indoor
max. 55 max. 55
+7 to +25 +7 to +25
9,6 9,4
19,0 / 3,2 24,6 / 3,2
20,8 / 3,8 26,4 / 3,8
21,5 / 5,5 26,4 / 5,1
58 59
2,0 / 8000 2,4 / 12500
5,0 / 20000 7,0 / 16000
R407C / 3,2 R407C / 4,5
G1¼'' int/G1''ext G 1¼'' i / G 1'' a
G 1½" int/ext G 1½" int/ext
173 221
400 / 20 400 / 20
3,93 5,15
27 29
7,0 / 0,8 9,4 / 0,8
3) 3)
yes yes
1 1
internal internal
