- Page 1 ® Electronic, Communication, and Music System Selection and Installation Guide • Voice/Music Intercoms • Voice Intercoms • Music Distribution Systems Nu T one Building Solutions for Today’s Lifestyles...
-
Page 2: Table Of Contents
IK-15 & IK-25 Door Com ........22-23... -
Page 3: Choosing Your Nutone System
Audio Input Plate Select your NuTone systems and controls Typically, the master unit is installed in the kitchen. NuTone recommends a speaker in each of the following rooms: living room, media room, family room, each bedroom, dining room, each outside door, garage, basement, patio/deck, kitchen (when master is not installed in kitchen) and master bath (which allows you to step out of the shower and easily answer the door). -
Page 4: Features Chart
NuTone System Features Not all units have the same features. To find out more about each unit’s features, locate the corresponding description on the following pages. COLOR MODEL BISCUIT: — IM-4406L IM-3303L — — BLACK: — IM-4406BL — — —... -
Page 5: Features Explained
The IM-3204 has Radio they may have moved from one room to another. Intercom, Off and Monitor. Monitor, intercom, With a NuTone “all call” intercom you’ll immedi- and music control features for the IMA-516 and ately be able to communicate with the individual. - Page 6 Model IM-4406 has a you’ll want to use the cable already in the wall. In built-in CD Player. most cases, a current NuTone 3-wire system can replace an older 3-wire system, 4-wire replace 4- Electronic Tuning wire, etc. You may also be able to replace a differ- Allows for easy, accurate tuning of your favorite ent brand intercom with a NuTone system.
- Page 7 Most NuTone electronic chime models can be con- be humming or no sound at all. NuTone’s self diag- nected to the master unit to allow chime sound to nostic circuitry allows the installer to easily check be heard over the room speakers.
-
Page 8: Options
Connect your existing music and TV audio compo- for a third door. nents to a NuTone system. Allows you to follow the action of a sports event when you leave your home theater room by broadcasting the audio throughout your home. -
Page 9: Wiring Your System
Use of “generic” cable can result in humming, interference and feedback in the installed system. After the house is finished, it will be time consuming and expensive to correct problems caused by use of the wrong cable. NuTone will not warranty systems where NuTone intercom cable is not used. -
Page 10: Locating Your Master, Speakers And Other Accessories
Locating Your Components Where to Install Master Where to Install Music Speaker Volume Controls Determine location of master with the following con- siderations: Select music speaker volume control location with the following considerations: • Choose master location with regard to residents’... - Page 11 Where To Install Speakers Typically, the master unit is installed in the kitchen. NuTone recommends a speaker in each of the following rooms: Living Room Media Room Family Room Bedrooms Dining Room Outside Doors Garage Basement Patio/Deck Laundry Kitchen (not if master...
-
Page 24: Dimensions For Rough-Ins And Trim
