- Page 1 ViewSonic ® Cine5000 DLP Projector - User Guide - Guide de l’utilisateur - Bedienungsanleitung - Guía del usuario - Guida dell’utente - Guia do usuário - Användarhandbok - Käyttöopas - Pyководство пользователя - 使用手冊 - 使用手冊 Model No. : VS11481...
-
Page 2: Compliance Information
The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment as unsorted municipal waste, but use the return and collection systems according to local law. ViewSonic Cine5000... -
Page 3: Important Safety Instructions
ViewSonic Cine5000... -
Page 4: Copyright Information
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries. ViewSonic, the three birds’ logo, OnView, ViewMatch, and ViewMeter are registered trademarks of ViewSonic Corporation. VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC are trademarks of VESA. -
Page 5: Table Of Contents
TABLE OF CONTENTS 1. Product Overview Features Package Contents Main Unit Control Panel Rear Terminals 2. Installation Turning on/off the projector 2-1-1 Starting up the projector 2-1-2 Shutting down the projector 2-1-3 LED Indication Status Adjusting the Projector Image 2-2-1 Adjusting the Projected Height 2-2-2 Adjusting the Zoom and Focus... -
Page 6: Product Overview
PRODUCT OVERVIEW 1-1.FEATURES 1-2.PACKAGE CONTENTS 250 W P-VIP lamp. Life 2000hrs at Boost Projector x 1 Power Cord (US/EU) mode, 3000hrs in Eco mode (200W). High efficiency cooling system with low system acoustic noise level. Lamp is easily replaceable by user. Manual zoom and focus lens with a 1:1.2 zoom ratio and 100% lens offset. -
Page 7: Main Unit
PRODUCT OVERVIEW 1-3.MAIN UNIT IR Receiver (Front) Projection Lens Hot Air Exhaust DRAWING 1 I/O Connection Panel IR Receiver (Back) AC Power Inlet Power Switch DRAWING 2 Elevator Button DRAWING 3 Focus Ring Zoom Ring Control Panel DRAWING 4 Elevator Feet Ceiling Mount Screw Holes Adjustable Foot DRAWING 5... -
Page 8: Control Panel
PRODUCT OVERVIEW 1-4.CONTROL PANEL 1-5.REAR TERMINALS Menu Source Aspect Vol+ Keystone Vol- Power Boost Thermal DRAWING 7 DRAWING 6 Menu Kensington Lock Source Composite Video Input Vol+ Audio Input (R / L) Vol- Component Video Input Boost Mode Indicator Trigger for Screen Relay (12V) Boost Audio Output Thermal Indicator... -
Page 9: Installation
INSTALLATION 2-1.TURNING ON/OFF THE PROJECTOR 2-1-3.LED INDICATION STATUS 2-1-1.STARTING UP THE PROJECTOR Condition Power Thermal Normal/Boost Note Ensure that the supplied power cord is securely connected at the AC inlet of the Indicator Indicator Indicator projector (Drawing 8) and power outlet. 1. -
Page 10: Adjusting The Projector Image
INSTALLATION 2-2.ADJUSTING THE PROJECTED 2-2-2.ADJUSTING THE ZOOM and FOCUS IMAGE Rotate the Zoom ring to adjust the image size. Rotate the Focus ring to focus the image. The projector will 2-2-1.ADJUSTING THE PROJECTED focus at distances from 1.5m (60in. / 5 ft.) to 10m (394 in. / 32.9 ft.). The optimum distance is from 1.5 m to 5 HEIGHT m (197 in. -
Page 11: Control Panel And Remote Control
CONTROL PANEL AND REMOTE CONTROL 3-1.CONTROL PANEL AND REMOTE 3-1-2.USING THE REMOTE CONTROL ECO: ECO mode for saving lamp life. CONTROL Power: Turns On / Off the projector. Keystone V+: Adjust image distortion in Control functions through the Control Panel and Vertical direction. -
Page 12: On-Screen Display Menu
CONTROL PANEL AND REMOTE CONTROL 3-2.ON-SCREEN DISPLAY MENU Image Display System Language Audio Movie: This mode is good for movie pictures. 3-2-1.HOW TO OPERATE User: This mode allows you to adjust details of Brightness Contrast Press the "Menu" button on the Remote image. - Page 13 CONTROL PANEL AND REMOTE CONTROL Factory Reset: Resets projector's parameters to button to select Red, Green, or Blue adjustment. the default settings. Red, Green, Blue: Increases or decreases the Over Scan: Select your desired mode video or PC value to find the desired color temperature. to do the over scan.
-
Page 14: Appendices
APPENDICES 4-1.TROUBLE SHOOTING Make sure the Audio setup menu or Ensure that the lamp cover is securely speaker setup menu in DVD player's attached and flush with the bottom of the unit. No images appears OSD is set properly. The unit will not operate with the cover Check the power cable connection at the incorrectly installed. -
Page 15: Cleaning The Projector
4-2-2.CLEANING THE PROJECTOR To reset the lamp timer Press the Menu button on control panel or Cleaning the cabinet Remote Control. Turn off projector and unplug the power cord Go into the system menu and move the from the projector before cleaning the outer cursor to the lamp reset item. -
Page 16: Specifications
APPENDICES 4-3.SPECIFICATION Color system NTSC / PAL / SECAM / NTSC4.43 Computer Compatibility SXGA (Compression) / XGA / SVGA / VGA / Mac Screen Size (Diagonal) 33"-255" Throw Distance 1.5m DMD Panel Single 0.65" DMD Number of Pixels 983,040(1280x768) Projection Lens F2.4, Zoom Ratio: 1.2:1 Projection Lamp 250 W / 2000 Hours (Boost Mode), 200 W / 3000 Hours (Eco Mode) -
Page 17: Customer Support
Note : You will need the product serial number. T=Telephone Country/ Web Site E-mail Region F=Fax T= 800 688 6688 United States www.viewsonic.com/support/ service.us@viewsonic.com F= 909 468 1202 Canada www.viewsonic.com/support T= 866 463 4775 service.ca@viewsonic.com United www.viewsoniceurope.com/uk T= 0207 949 0307 service.eu@viewsoniceurope.com... -
Page 18: Limited Warranty
ViewSonic warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will at its sole option repair or replace the product with a like product.
