Agent Desktop / Laptop – New or Replacement Installation Instructions Version 2/12/2009
4. Remove the three (3) screws from the panel on the bottom, right, of the docking station as shown:
Remove these screws
5. Insert the security cable key into the cable lock and align the T-bar on the cable head with the two round
projections on each side of the T-bar, so these align with the slot in the docking station. Insert the Kensington security
cable as shown and then re-attach the cover. You will have to remove the filler piece to re-attach the security cable
cover.
Insert security cable
6. Place the Docking Station (with the attached Kensington cable) on the desk.
a. Connect the power cord to the docking station.
b. Plug the network cable into the Ethernet port in the back of the docking station.
c. Plug in the external keyboard and mouse into the docking station. The mouse uses one of the USB ports on
the back of the docking station.
** Connect only the monitor, keyboard, mouse, and Ethernet cables, at this time. **
**Prior to powering on, make sure all peripheral devices are disconnected. **
Contains CONFIDENTIAL information which may not be used without express written authorization.
Cover removed
Remove filler piece
T S
HIS ECTION IS COMPLETE
Agent Desktop / Laptop Installation Instructions
FOR INTERNAL STATE FARM USE ONLY
Proper alignment to install
Re-attach cover
- 12 -
