Summary of Contents for Teac LET5596FHD
-
Page 1: User Manual
LET5596FHD LED TV USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ www.teac.com.au Trademark of TEAC Corporation JAPAN... - Page 2 support@teac.com.au...
- Page 3 Authorised Service Centre for repair. In this event, proof of purchase is required to support a warranty claim. After the repair, the product will be available for collection by or return to the purchaser at a fee upon request. TEAC in- home service can be made available at a fee upon request.
-
Page 4: Table Of Contents
Contents Safety Precautions Power Supply..............................1 Installation................................. 2 Use and Maintenance............................3 Important Safety Instructions ..........................4-5 User Guidance Information Wall Mounting Information ..........................6 Fixing the stand ............................... 7 Accessories/Names of each part(Front View) ....................8 Names of each part(Back View) ........................ -
Page 5: Power Supply
Power Supply DO NOT plug several devices DO NOT touch the power DO NOT use a damaged Insert the power plug fully into into the same outlet. plug with wet hands. power cord or plug or a the outlet. loose outlet. loose or improperly the outlet to overheat and start inserted power plug... -
Page 6: Installation
Installation DO NOT place the unit on an unstable DO NOT place containers with DO NOT place the unit where DO NOT use or store flammable surface, such as a sloped table, or any liquids such as vases, drink cans, it is exposed to rain, excessive or combustible materials near stand with a contact area smaller than... -
Page 7: Use And Maintenance
Use and Maintenance Although the LED screen is made with high-precision technology and 99.99% or more of the pixels are effective, black dots may appear or bright points of light (red, blue, or green) may appear constantly on the LED screen. This is a property of the LED screen and is not a malfunction. -
Page 8: Important Safety Instructions
Important Safety Instructions power socket. Do not bend the power cord excessively. P revent the cord from being walked on or pinched by weights placed on it. - Page 9 TEAC service personnel for assistance. Servicing of this unit should be conducted by qualified and certified TEAC service personnel. The manufacturer will not be held responsible for any damage caused by any modifications done on the product without authorisation from the manufacturer’s...
-
Page 10: Wall Mounting Information
Wall Mounting Information Stand and wall-mounted (optional) Your LED TV is able to accommodate wall mounting with the use of a wall mount bracket (not supplied with LED TV, please contact your local hardware store) and the mounting hole screw size (MB6X25mm) on the back of the unit. We recommend removing the TV stand prior to mounting the TV on the wall. -
Page 12: Accessories/Names Of Each Part(Front View)
Accessories Quick Start Guide Contact Card Mini YPbPr Cable 2 x AAA Battery User’s Guide Remote Control Names of each part Front View (keep clear of osbtacles) (INPUT): Display the input source menu. (MENU): Display/exit the OSD menu. (CH+/-): Scan through channels. (VOL+/-): Adjust the volume. - Page 13 Names of each part SWITCH AC POWER IN Coax Video L-i n R-in HDMI1 HDMI2 : Connect to AC power supply. AC POWER IN SWITCH: Turn on/off the power supply. HDMI1/2 : Connect to the HDMI output of external devices like DVD players with a HDMI cable. COAX : Digital output to AV receiver.
-
Page 14: Remote Control
Remote Control The remote control uses Infra-red technology. Point it towards the front of the TV. The remote control may not work correctly if it is out of range, angle or if obstacles are in the way of the Infra-red signal. NOTE: If the remote control signals become weak, replace the batteries with new AAA batteries. -
Page 15: Remote Control
Remote Control Buttons for USB operation: (REC): Press to start recording the program in DTV mode. : Load/eject DVD disc.(Only used in HDMI CEC function) : Stop program. : Previous chapter. : Next chapter. : Play/Pause program. : Fast reverse. : Fast forward. -
Page 16: Basic Operation
Basic Operation The following section conveys the unit’s general operation, such as, switching the unit on, selecting the input source, and using the automated channel search command. Switching the unit on The following steps are a guide to switch the unit on: 1. -
Page 17: Dtv Setting
Basic Operation Using the On Screen Display Menu The On Screen Display (OSD) menu acts as the Main Menu and aids the user in browsing through the different options/properties available on the television unit. Press the MENU button on the remote control to access the OSD menu as shown below: Main menu DTV Setting ICTURE... - Page 18 OSD Menu 1. DTV setting Description DVR menu Media Browser Press OK to enter the DVR List for playback of media files (All, Recording, Media, Photo) that havebeen recorded or from a connected media server. Alternatively, use the MEDIA button on ther remote control.
- Page 19 Format the USB CAUTION : Formatting will delete all files on the hard disk! Please backup any files you wish to keep before formatting. TEAC cannot take responsibility for lost data. NOTE: For more about setting up a HDD for recording, please see the “Recording Operation”...
- Page 20 OSD Menu TUNING Menu Press OK to enter Installation Menu. Auto Channel Search Select Auto Search and press OK, the unit will start to scan all available channels. Manual Channel Search Select DTV Manual Search and press OK, frequencies frequency for channel search Parent lock menu Parental Menu New Password...
- Page 21 OSD Menu EPG Menu Press OK to enter the EPG. For more about using the EPG, see page...
-
Page 22: Picture Menu
OSD Menu 2. PICTURE menu Description Picture Mode: Choose from Standard, Dynamic, User and Mild. Note: Contrast, Brightness, Color and sharpness are only available and can be adjusted in the User mode option in the Picture Mode Settings. Contrast: Controls the difference between the brightest and darkest regions of the picture. Brightness: Controls the overall brightness of the picture. -
Page 23: Sound Menu
OSD Menu 3. SOUND menu Description Sound Mode: Allows you to select among: Standard, Music, Movie, Sports and User. Treble(Can be adjusted when the sound mode is User): Controls the relative intensity of higher pitched sounds. Bass (Can be adjusted when the sound mode is set to User): Controls the relative intensity of lower pitched sounds. -
Page 24: Time Menu
OSD Menu 4. TIME menu Description Clock: Use the buttons to select the position, and use the buttons to set the time. Off Time: Press OK button to enter the submenu, you could set the time when the TV set will be turned off automatically, you could also set the frequency. -
Page 25: Option Menu
OSD Menu 5. OPTION menu Description OSD Duration: Allows you to select the time for the OSD display on the screen. Blue Screen: Changes the background colour when there is no input between clear and a blue background. HDMI CEC: Turn on/off HDMI CEC function. This option is only available in HDMI Input Mode. Auto Standby: Enable both the TV and a compativle HDMI device to turn standby and turn on together. -
Page 26: Electronic Program Guide
Electronic Program Guide Access the EPG by pressing [EPG] in DTV source. Channel/Program Navigation Scheduling Recording/Reminders Setting Timer Reminders Setting Timer Recordings... - Page 27 Electronic Program Guide Setting Series Recordings Series recording allows you to record every episode in the series of the program you have selected with a single button press: In the EPG, select the program for which you wish to record the whole series, then press the [RED] button on the remote.The message “Series recording is successfully set!”...
-
Page 28: Recording Operation
Recording Operation Before recording, please select the storage destination (External HDD) of the recorded program in the DVR menu (please refer to page 10 – DVR Setting menu). The unit supports External HDDs or USB flash devices in FAT, FAT32, EXT2, EXT3 formats. We recommend using an external HDD up to 2TB with a separate power supply. - Page 29 Recording Operation Time Shift in Live TV Mode. Time Shift supports a temporary program recording of up to 2 hours. Simultaneous Recording and Push/Pull Pull Recording 02 Recording 01 Pull Live TV Recorded TV (Simultaneous) The Twin Tuner TV can record and perform Recorded Video time, for up to three actions for certain...
-
Page 30: Media Operation
Media Operation Media Player 1. Open the Media Browser by pressing [MEDIA] in DTV Input Mode. 2. Press [OK] to preview the media file in the preview screen, press [OK] again to view the file in full screen. square icon. Media Browser Controls Press the [RED] button to operation the media file on the USB devices(Select All/Unselect All/Reverse SelectRename). - Page 31 Media Operation Editing Recorded Programs In this mode you can remove sections of the recorded program, so that during playback, these sections will be skipped and playback will continue past the removed section. 1. Open the record list by pressing [REC.list] in DTV source. program by pressing [OK] .
-
Page 32: Network
NETWORK In the Network menu you can listen to Internet radio stations and access media files from your PC. Connect to the Internet by Ethernet cable (recommended) or Wi-Fi. WiFi Connection (Optional) 1. Press [MENU] in DTV source. 2. Select DTV Setting Network WiFi setting. -
Page 33: Network
NETWORK please try similar related apps. Listen to Internet Radio Stations 1. Press [MENU] in DTV source. 2. Select DTV Setting Network Internet Radio and press [OK]. 3. Unit will scan for Internet radio stations automatically. 4. Once autoscan is complete, a list of genres will be displayed on the left hand side of the screen. -
Page 34: Network
NETWORK Network Neighbourhood (Sharing Data with Networked PCs or Media Server) The Network Neighbourhood feature allows you to access and play media files that you have stored on your PC via the TV such as video files, MP3 files and photos. Regardless of the operating system on your PC, the first step required is to create a folder on the PC’s local hard drive. -
Page 35: Network
NETWORK 3. Open “Control Panel” and turn on the guest account 4. Open “Control Panel” and double-click “Administrative Tools”. 5. Double-click “Local Security Policy”. -
Page 36: Network
NETWORK 6. In the left menu tree, double-click “User Rights Assignment” 7. Double-click “Deny access to this computer from the network”. 8. Select “Guest” account and click “Remove”. 9. Click the “Apply” button to save the changes made. 10. Now you can add “Network Neighbourhood” on the TV Please enter the correct IP address and folder name. -
Page 37: Network
NETWORK How to access media on a Windows 7 PC 1. Right click the “Media” folder, and select “Properties”. 2. Switch to the “Sharing” tab and click “Share”. 3. Select an appropriate item, then click “Share” and “Done”... -
Page 38: Network
NETWORK 4. Select “Security” page and “Edit”. 5. Select “Add”. 6. Input “guest” to the box and select “Check Names” ”Apply”. -
Page 39: Network
NETWORK... -
Page 40: Network
NETWORK 10. Select “Local Users and Groups” ”Users” ”Guest” 11. Unselect “Account is disabled”, click Apply, then click OK. - Page 41 NETWORK 12. Double-click “Local Security Policy”. 13. In the left menu tree, double-click “User Rights Assignment”. 14. Double-click “Deny access to this computer from the network”...
- Page 42 NETWORK 15. Select “Guest” account and click the “Remove” button, then click Apply and OK.
-
Page 43: Network
NETWORK 16. Now you can add “Network Neighbourhood” from the TV. Please enter the correct IP address and folder name. Enter the username and password of the computer you wish to connect to. 17. If connection is successful, you can access the media files under this sharing folder by pressing the MEDIA button on the remote control. -
Page 44: Network
NETWORK Once you have set up the Media folder on your PC, follow the instructions below to connect the receiver to your PC over your network. To set up Network Neighbourhood on the receiver: 1. Press [MENU] in DTV source. 3. -
Page 45: Troubleshooting
Troubleshooting Do not use other functions that are not mentioned in this user manual. If a problem occurs with your LED TV, please take the following steps first. If you still have the problem, turn the power off and contact your dealer or an authorized service center. Action Problem Is the power plugged in? Insert the power plug. -
Page 46: Specifications
Specifications Panel Size LED Panel Max. Resolution Input Connector VIDEO YPbPr AUDIO (L/R) PC/AUDIO HDMI 2 The HDMI support 1.3, the HDCP support 1.1) Output Connector HEADPHONE COAX 100-240V ~ 50/60Hz Power Source 180W Power Consumption Standby Power Consumption < 1W Frequency range 48.25 - 863.25 MHz Speaker output power... - Page 47 Specifications Supporte d Form ats: MOVIE The max bitrate is 6Mbps. The max resolution is 720x576 pixels. (AVI) Mono colour, 16-colour, 256-colour, 16-bit, 24-bit, 32-bit. The max PHOTO resolution is 3000x3000 pixels; min resolution is 100x100 pixels. Sample rate: 8K – 48K, Bitrate: 32K-320K MUSIC Special no te: 1.
- Page 48 TEAC CUSTOMER SUPPORT HOTLINE (TCS) 1300 553 315 Between Monday to Friday – AEST 8:30AM to 6PM...
