Page 1: User Manual
LEV3992FHD LED TV USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ www.teac.com.au Trademark of TEAC Corporation JAPAN... - Page 2 Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service. If you require Warranty Service, please contact the TEAC Customer Support Hotline at 1300 553 315 for assistance. Please ensure that you have the model number, serial number and purchase receipt ready when you call.
- Page 3 Authorised Service Centre for repair. In this event, proof of purchase is required to support a warranty claim. After the repair, the product will be available for collection by or return to the purchaser at a fee upon request. TEAC in- home service can be made available at a fee upon request.
-
Page 4: Table Of Contents
Contents Safety Precautions Power Supply..............................1 Installation................................. 2 Use and Maintenance............................3 Important Safety Instructions ..........................4-5 User Guidance Information Wall Mounting Information ..........................6 Fixing the stand ............................... 7 Accessories/Names of each part(Front View) ....................8 Names of each part(Back View) ........................ -
Page 5: Power Supply
Power Supply DO NOT plug several devices DO NOT touch the power DO NOT use a damaged Insert the power plug fully into into the same outlet. plug with wet hands. power cord or plug or a the outlet. loose outlet. loose or improperly the outlet to overheat and start inserted power plug... -
Page 6: Installation
Installation DO NOT place the unit on an unstable DO NOT place containers with DO NOT place the unit where DO NOT use or store flammable surface, such as a sloped table, or any liquids such as vases, drink cans, it is exposed to rain, excessive or combustible materials near stand with a contact area smaller than... -
Page 7: Use And Maintenance
Use and Maintenance Although the LED screen is made with high-precision technology and 99.99% or more of the pixels are effective, black dots may appear or bright points of light (red, blue, or green) may appear constantly on the LED screen. This is a property of the LED screen and is not a malfunction. -
Page 8: Important Safety Instructions
Important Safety Instructions power socket. Do not bend the power cord excessively. P revent the cord from being walked on or pinched by weights placed on it. - Page 9 TEAC service personnel for assistance. Servicing of this unit should be conducted by qualified and certified TEAC service personnel. The manufacturer will not be held responsible for any damage caused by any modifications done on the product without authorisation from the manufacturer’s...
-
Page 10: Wall Mounting Information
Wall Mounting Information Stand and wall-mounted (optional) Your LED TV is able to accommodate wall mounting with the use of a wall mount bracket (not supplied with LED TV, please contact your local hardware store) and the mounting hole screw size (M5X12mm) on the back of the unit. We recommend removing the TV stand prior to mounting the TV on the wall. -
Page 11: Fixing The Stand
Fixing the stand 1. The parts needed for installing the stand (supplied) Before installing the stand, please check that you have all of the parts and that there is no visible damage. If a part is missing or appears damaged, please contact customer service. TV set Stand Screws(supplied) -
Page 12: Accessories/Names Of Each Part(Front View)
Accessories Quick Start Guide Contact Card 2 x AAA Battery User’s Guide Remote Control Names of each part Front View DVD: Insert a 12cm DVD/ CD with the label side facing towards the back. INPUT MENU VOL- VOL+ PLAY EJECT POWER (INPUT): Display the input source menu. - Page 13 Names of each part SWITCH AC POWER IN Video R-in L-in AC POWER IN Connect to AC power supply. SWITCH: Turn on/off the power supply. VIDEO: Connect to video output terminal of external devices. R/L in: Connect to the audio output terminal of external devices.(shared with YPbPr) YPbPr: Connect to the YPbPr video output sockets of external devices.
-
Page 14: Remote Control
Remote Control (POWER) : Turn the TV on/back to Standby mode. DTV/USB INPUT AUDIO MUTE DTV/USB: Switch to DTV/USB. INPUT : Display the input source menu. PICTURE SOUND SLEEP ASPECT AUDIO : Select different audio languages, subject to availability from broadcaster. MUTE: Press to mute the sound, press again or press VOL+ to unmute. -
Page 15: Remote Control
Remote Control AUDIO MUTE DTV/USB INPUT PICTURE SOUND SLEEP ASPECT Buttons for USB/DVD operation: (REC) : Press to start recording the program in DTV mode. : Load/eject DVD disc. : Stop program. : Previous chapter. : Next chapter. : Play/Pause program. : Fast reverse. -
Page 16: Basic Operation
Basic Operation The following section conveys the unit’s general operation, such as, switching the unit on, selecting the input source, and using the automated channel search command. Switching the unit on The following steps are a guide to switch the unit on: 1. - Page 17 Basic Operation Using the On Screen Display Menu The On Screen Display (OSD) menu acts as the Main Menu and aids the user in browsing through the different options/properties available on the television unit. Press the MENU button on the remote control to access the OSD menu as shown below: Main menu PICTURE SOUND...
-
Page 18: Osd Menu
OSD Menu 1. PICTURE menu Picture display settings can be altered as desired. The following options are adjustable: Picture Picture Picture Mode Standard Saturation Brightness Contrast Color Temp Standard Sharpness Saturation Green Blue Color Temp Standard Aspect Ratio Full Advanced Settings Move OK: Select MENU: Return... -
Page 19: Sound Menu
OSD Menu 2. SOUND menu General sound settings can be adjusted according to personal preference with the following options: Sound Sound Standard Sound Mode Treble Treble Bass Bass Balance Balance Surround Sound Surround Sound EQ Setting EQ Setting SPDIF SPDIF Stereo Sound Type Move... -
Page 20: Channel Menu
OSD Menu 3. CHANNEL Menu This menu selection contains scanning preferences (either automatic or manual tuning), Channel, Auto Scan, Manual Scan, Channel Edit, Signal Information. Settings can be altered for individual channels. NOTE: Some menus are available only in DTV Mode while recording is not in progress. - Page 21 OSD Menu Digital Manual Scan Press the OK button to enter the Digital Manual Scan menu. Digital Manual Scan Select a DTV channel, and press OK to start Digital Scan CH36 searching. Start Frequency 585.50 MHz Frequency: Press buttons to select Frequency: Strength Auto or enter digital numbers.
- Page 22 OSD Menu Delete: RED button. A confirmation message will pop up. Select the channel to delete and press the Choose “Yes” to confirm the deletion, or “No” to cancel. Select the channel to be moved and press the BLUE button. Use the CH+/- buttons to Move: change the channel position.
-
Page 23: Lock Menu
OSD Menu 4. LOCK menu This option allows parents to block channels and programs using a password. NOTE: The default password is 0000. If you have forgotten your current password, the master password is 8899. Please take note of this. Lock System Enter Password _ _ _ _... -
Page 24: Setup Menu
OSD Menu 5. Setup menu The option settings allows alterations to the language and regional settings. Setup Time Settings OSD Language English Audio Languages Subtitle Teletext Blue Screen HDMI CEC Control DVR Settings Move MENU: Return EXIT: Exit Description Time Settings: Clock: Use the buttons to select the position, and the... - Page 25 OSD Menu OSD Language: Select the language option for the OSD menu. Audio Languages: (can be selected in DTV mode): Allows you to select first and second audio language. Subtitle: (can be selected in DTV mode) : Allows you to select first and second subtitle language. Teletext: Adjust Teletext settings.
-
Page 26: Multimedia Operation
Multimedia Operation USB Usage Precautions Never turn the unit off or disconnect a USB Storage Device (Flash Drive) when it is being accessed. Doing so could damage the TV and the connected USB storage device. Do not use a device that has a maximum current consumption of 100 mA or more. Do not use a device that has security functions or other special functions. - Page 27 Multimedia Operation Basic Operation 1). Press the INPUT button on the remote control to display the input source menu and select USB with the buttons. Press the OK button to enter the Multimedia menu as shown below. SOURCE SOURCE: Exit 2).
- Page 28 Multimedia Operation To access photo, audio, video, or text files from an external drive, first choose USB Input, then select the type of media to be played to enter the folder/file navigation screen. 1. Photo To display photos, select files from the folder and press PLAY to view in full screen. The image should appear on screen as illustrated below.
- Page 29 Multimedia Operation to select the option on the table, and press OK to change. Press to search for music, and press OK to select. Press Press the EXIT button and select Back to return to the previous menu. Quick Menu: Press D.MENU to enter Quick Menu. Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None.
- Page 30 Multimedia Operation 4. Display Text To play text files (most files with the extension .txt), select a file from the folder and press PLAY. ZOOM IN ZOOM OUT Previous / Next D.MENU to select options on the toolbar, and press OK to change. Press Press 0~9 to select specific pages.
- Page 31 Multimedia Operation Supported Formats: MOVIE The max bitrate is 6Mbps. The max resolution is 720x576 pixels. (AVI) Mono colour, 16-colour, 256-colour, 16-bit, 24-bit, 32-bit. The max PHOTO resolution is 3000x3000 pixels; min resolution is 100x100 pixels. Sample rate: 8K – 48K, Bitrate: 32K-320K MUSIC Special note: 1.
-
Page 32: Recording Operation
Recording Operation Digital Video Recording (DVR) settings (In DTV Mode only) The DVR function allows this unit to record live digital TV (DTV) programs, allowing for viewing on demand at any time. This function supports DTV program recording, Time shift and playback as described below. - Page 33 Recording Operation Recorded list Red button: Delete One program. Green button: Delete All programs. Yellow button: Replay the program. Blue button: Zoom In/Out between full screen view and preview mode. After the recording has been done, the stored programs can be viewed through a Recorded List by pressing the 'LIST' button on the remote control.
- Page 34 Ensure that no valuable information is currently stored in the hard disk, as the formatting process means that ALL DATA will be ERASED from the memory drive connected to the USB/HDD port. TEAC does not take responsibility for lost data.
-
Page 35: Schedule List
Recording Operation Schedule List Red button: Delete One scheduled program. Green button: Delete All scheduled programs. Scheduled Recording is a function which allows the user to record future programs without physically being present to initiate the recording. A schedule setup is made to mark recording dates and times of the broadcasted programs stated on the Electronic Program Guide (EPG). - Page 36 Recording Operation Electronic Program Guide (EPG) Press the EPG button to display the OSD menu as below: Details information of selected program. Program list for the current channel. Press direction buttons to navigate the lists. Once the program of choice has been highlighted, press the REC button on the remote control. This will bring you to Record Mode, where you can set the start and end time of the recording.
-
Page 37: Dvd Operation
DVD Operation Preparation 1. Connect the unit to the power supply and press the POWER button to switch the unit on. 2. Press the INPUT button on the remote control to select DVD mode and press OK to select DVD mode. -
Page 38: Selecting Tracks
DVD Operation Title Play 1. DVD disc dependant only, according to DVD manufacturer specifications. 2. During DVD playback, press Title button to display the DVD title content and main menu. 3. Press the /\ / \/ buttons to highlight the title you would like to choose and press OK; you can also opt to press the numeric buttons. - Page 39 DVD Operation Multispeed Fast Motion Play Compatible with DVD, SVCD, VCD, CD, HD-CD, WMA, Digital Audio discs. 1. Press the Multispeed Fast Forward button on the remote during play to search through a disc. Multispeed Fast Forward has four speeds: x2, x4, x8, x16, x32 With each consecutive press of the button, the search speed increases.
- Page 40 DVD Operation Display Features This feature aids the user in viewing options readily available, and is compatible with the following disc types: DVD, SVCD, VCD, CD, HD-CD, WMA, Digital Audio discs. This display is available while the files on the disc are being played. DVD Display feature When the DISPLAY button is pressed repeatedly while a DVD is being played, the response will show as follows.
- Page 41 DVD Operation Using the Search Feature Compatible with DVD, SVCD, VCD, CD, HD-CD discs. Press the GOTO button on the remote control to bring up the search Display Feature menu. Press the Arrow buttons to highlight the Title/ Chapter/ Track Number/ Time Elapsed options. Use the Numeric buttons to enter the Title/ Chapter/ Track number or Time you would like to III.
- Page 42 DVD Operation Press the Power button on the TV or the remote control, then press the INPUT button to select DVD mode. If there is no disc in the DVD player the screen will show "NO DISC". Insert a disc with the label facing the correct direction according to the picture next to the disc slot. Do not touch the disc’s reflective surface.
- Page 43 DVD Operation Enable Screen saver will prevent image burn and screen damage. The Last Memory function can memorize where disc playback was stopped, and resume from there when the same disc is inserted again.This function can memorize up to 4 discs, and is dependent on the disc content. Select "On" to enable the function, and "Off"...
- Page 44 DVD Operation the "Speaker Setup" option, then press OK Select to downmix multichannel audio soundtracks to LT/RT channel output. Select to downmix multichannel audio soundtracks to stereo output.
- Page 45 DVD Operation Volume Select to downmix multichannel audio soundtracks to stereo output. Choose a preferred language track to be played if it is available on the disc. If it is not available, the default language will be played.
- Page 46 DVD Operation Choose a preferred subtitle language to be used if it is available on the disc. If it is not available, the default language will be used. Choose a preferred menu language to be used if it is available on the disc. If it is not available, the default language will be used.
- Page 47 DVD Operation disc rating...
- Page 48 DVD Operation Reset the DVD settings to the original factory settings by choosing RESET and pressing the OK button.
-
Page 49: Troubleshooting
Troubleshooting Do not use other functions that are not mentioned in this user manual. If a problem occurs with your LED TV, please take the following steps first. If you still have the problem, turn the power off and contact your dealer or an authorized service center. Action Problem Is the power plugged in? Insert the power plug. -
Page 50: Specifications
Specifications Panel Size LED Panel Max. Resolution Input Connector VIDEO YPbPr AUDIO (L/R) PC/AUDIO HDMI 3 The HDMI support 1.3, the HDCP support 1.1) Output Connector HEADPHONE COAX 100-240V ~ 50/60Hz Power Source Power Consumption Standby Power Consumption < 0.5W TV receive system PAL BG/DK/I SECAM BG/DK Frequency range... - Page 51 Specifications Supported Formats: MOVIE The max bitrate is 6Mbps. The max resolution is 720x576 pixels. (AVI) Mono colour, 16-colour, 256-colour, 16-bit, 24-bit, 32-bit. The max PHOTO resolution is 3000x3000 pixels; min resolution is 100x100 pixels. Sample rate: 8K – 48K, Bitrate: 32K-320K MUSIC Special note: 1.
- Page 52 TEAC CUSTOMER SUPPORT HOTLINE (TCS) 1300 553 315 Between Monday to Friday – AEST 8 AM to 6PM...
