Summary of Contents for Teac LE23A86FHD
-
Page 1: User Manual
LE23A86FHD LED TV USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ www.teac.com.au Trademark of TEAC Corporation JAPAN... - Page 2 Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service. If you require Warranty Service, please contact the TEAC Customer Support Hotline at 1300 553 315 for assistance. Please ensure that you have the model number, serial number and purchase receipt ready when you call.
- Page 3 Authorised Service Centre for repair. In this event, proof of purchase is required to support a warranty claim. After the repair, the product will be available for collection by or return to the purchaser at a fee upon request. TEAC in- home service can be made available at a fee upon request.
-
Page 4: Table Of Contents
Contents Safety Precautions Power Supply..............................1 Installation................................. 2 Use and Maintenance............................3 Important Safety Instructions ..........................4-5 User Guidance Information Fixing the Stand ............................... 6 Wall Mounting Information ..........................7 .. -
Page 5: Power Supply
Power Supply DO NOT plug several devices DO NOT touch the power DO NOT use a damaged Insert the power plug fully into into the same outlet. plug with wet hands. power cord or plug or a the outlet. loose outlet. loose or improperly the outlet to overheat and start inserted power plug... -
Page 6: Installation
Installation DO NOT place the unit on an unstable DO NOT place containers with DO NOT place the unit where DO NOT use or store flammable surface, such as a sloped table, or any liquids such as vases, drink cans, it is exposed to rain, excessive or combustible materials near stand with a contact area smaller than... -
Page 7: Use And Maintenance
Use and Maintenance Although the LED screen is made with high-precision technology and 99.99% or more of the pixels are effective, black dots may appear or bright points of light (red, blue, or green) may appear constantly on the LED screen. This is a property of the LED screen and is not a malfunction. -
Page 8: Important Safety Instructions
Important Safety Instructions power socket. Do not bend the power cord excessively. P r event the cord from being walked on or pinched by weights placed on it. -
Page 9: Important Safety Instructions
TEAC service personnel for assistance. Servicing of this unit should be conducted by qualified and certified TEAC service personnel. The manufacturer will not be held responsible for any damage caused by any modifications done on the product without authorisation from the manufacturer’s... -
Page 11: Wall Mounting Information
Wall Mounting Information Wall Mounting (optional) Your LED TV is able to accommodate wall mounting with the use of a wall mount bracket (not supplied, please contact your local hardware store) and the mounting hole screw size (M4X10mm) on the back of the unit. If the TV stand is already installed, remove it prior to wall mounting. -
Page 12: A C C E S S R O E I S N / A M E S F O E A C H P A T R F ( O R T N V E I W . )
Accessories Quick Start Guide Contact Card 2 x AAA Batteries User’s Guide Remote Control AC power adaptor * Accessories included may look different from the illustrations shown. Names of each part Front View LED Indicator Remote Control Sensor (keep clear of obstacles) INPUT: Display the input source menu. -
Page 13: Names Of Each Part(Back View)
Names of each part Back View POWER COAX VIDEO L-i n R-in Headphone POWER: Connect to the power adaptor. Headphone: Connect to your headphones or other audio equipment. PC-IN: Connect to the audio output terminal on the PC. VGA: For PC video input. Connect to the VGA/RGB plug on the PC. VIDEO: Connect to video output terminal of external devices. -
Page 14: Remote Control
Remote Control (POWER) : Turn the TV on/back to Standby mode. DTV/USB INPUT AUDIO MUTE DTV/USB: Switch to DTV/USB. INPUT : Display the input source menu. PICTURE SOUND SLEEP ASPECT AUDIO : Select different audio languages, subject to availability from broadcaster. MUTE: Press to mute the sound, press again or press VOL+ to unmute. -
Page 15: Remote Control
Remote Control AUDIO MUTE DTV/USB INPUT PICTURE SOUND SLEEP ASPECT Buttons for USB operation: (REC): Press to start record the program in DTV mode. : No function. : Stop program. : Previous chapter. : Next chapter. : Play/Pause program. : Fast reverse. : Fast forward. -
Page 16: Basic Operation
Basic Operation The following section conveys the unit’s general operation, such as switching the unit on, selecting the input source, and using the automated channel search command. Switching the unit on 1. Connect the television unit to the antenna wall socket using a coax television cable plug. 2. - Page 17 Basic Operation Using the On Screen Display Menu The On Screen Display (OSD) menu acts as the Main Menu and aids the user in browsing through the different options/properties available on the television unit. Press the MENU button on the remote control to access the OSD menu as shown below: Main menu: Picture Sound Channel Feature Setup Submenu The Picture submenu is...
-
Page 18: Osd Menu
OSD Menu 1. Picture menu Description Picture Mode: Select your desired picture mode. (Dynamic, Standard, Mild, User) Brightness: Adjust image brightness. Contrast: Adjust image contrast. Sharpness: Adjust image sharpness (not available in VGA/PC mode). Colour: Adjust image colour saturation. Tint: Control the tint (available in NTSC mode only). Colour Temperature: Select a preferred color temperature mode. -
Page 19: Sound Menu
OSD Menu 2. Sound menu Description Sound Mode: Select your desired sound mode. (Standard, Movie, Music, Speech, User) Bass: Adjust the level of the lower pitched tones. Treble: Adjust the level of the higher pitched tones. Balance: Adjust the audio output between left and right speakers. Surround: Turn on/off the surround sound function. -
Page 20: Channel Menu
OSD Menu 3. Channel menu (In ATV/DTV mode) Description Channel Management: Enter the Channel management menu to edit the channels. DELETE: Press the RED button to mark the channels you want to delete. You will be prompted to confirm when you exit this menu. LOCK: (Reminder - To activate channel locks, “Lock Enable”... - Page 21 OSD Menu Country : Select the country. NOTE: If Channel Locks has been enabled (Feature>Lock submenus), first enter the current password (default: 0000) to enter the Auto and Manual Search menus. Auto Search Select the desired search mode, and then press the OK button to start Auto Channel Search. Note: 1.
-
Page 22: Feature Menu
OSD Menu 4. Feature menu Description Lock: This menu allows you to lock certain features of the television so that they can not be used or viewed. For example, setting a program rating lock for children, locking specific channels, and preventing unauthorised channel deletion or channel retuning. - Page 23 OSD Menu Language: Choose a desired language for the OSD menus. Clock: Adjust the clock (by default the time is synced automatically from the DTV signal) Sleep Timer: Set the sleep timer so the television automatically switches off after a set amount of time.
-
Page 24: Setup Menu
OSD Menu 5. SETUP menu Description OSD Timer: Lets you adjust the amount of time the On Screen Menu stays on the screen before disappearing. PC Setup: Change the PC Settings in PC mode. Auto Adjust: Adjust the parameter of the screen automatically. H/V-Position: Adjust the horizontal/vertical position of the screen. -
Page 25: Multimedia Operation
Multimedia Operation Basic Operation 1). Press the INPUT button on the remote control to display the input source menu, select Media source with the buttons, and press the OK button to enter the Multimedia menu as shown below. YPBPR HDMI Media 2). - Page 26 Multimedia Operation 1. Photo Run a photo slideshow from USB. Press the buttons to select the options on the toolbar, and OK to confirm. NOTE: Press OK to display and use the control bar after it has disappeared. Play/Pause the photo playing. Stop and exit the full screen slideshow.
- Page 27 Multimedia Operation 3. Movie Play compatible movie files from USB. Press the buttons to select the options on the toolbar, and OK to confirm. NOTE: Press OK to display and use the control bar after it has disappeared. Play/Pause the movie. Stop and exit the full screen playback.
-
Page 28: Recording Operation
Format: Press the RED button to format the selected USB device. CAUTION: Formatting will wipe all data from the USB device. Please back up existing data before formatting. TEAC is not responsible for lost data. USB flash drives, or an external hard disk using its own power supply is recommended for recording and playback. - Page 29 Recording Operation Recorder: Turn on/off recording. (If it is off, the scheduled item is set as a Reminder.) Type: Select the type of content. (DTV, Radio) Channel: Select the channel. Start Date: Set the start date. Start Time: Set the start time. End Date: Set the end date.
- Page 30 Recording Operation Recording Press REC on the remote control to start recording immediately in DTV mode. NOTE: a. A compatible USB memory device must be connected to the TV. b. Ensure that the USB device has enough speed and data space. Press the STOP button to exit the recording mode.
-
Page 31: Troubleshooting
Troubleshooting Do not use other functions that are not mentioned in this user manual. If a problem occurs with your LED TV, please take the following steps first. If you still have the problem, turn the power off and contact your dealer or an authorized service center. Action Problem Is the power plugged in? Insert the power plug. -
Page 32: Specifications
Specifications LED Panel Panel Size Max. Resolution VIDEO Input Connector YPbPr AUDIO (L/R) PC/AUDIO HDMI 1 The HDMI support 1.3, the HDCP support 1.1) Output Connector HEADPHONE COAX Power Source Power Consumption Standby Power Consumption < 0.5W TV receive system PAL BG/DK/I SECAM BG/DK Frequency range 48.25 - 863.25 MHz... -
Page 33: Specifications
Specifications Supported Formats: MOVIE The max bitrate is 6Mbps. The max resolution is 720x576 pixels. (AVI) Mono colour, 16-colour, 256-colour, 16-bit, 24-bit, 32-bit. The max PHOTO resolution is 3000x3000 pixels; min resolution is 100x100 pixels. Sample rate: 8K – 48K, Bitrate: 32K-320K MUSIC Special note: 1. - Page 36 TEAC CUSTOMER SUPPORT HOTLINE (TCS) 1300 553 315 Between Monday to Friday – AEST 8:30AM to 6PM...
