- Page 1 HP F1381A Port Replicator for the HP OmniBook 3000 User’s Guide For other Service and User Manuals, go to www.ManualDepot.com...
- Page 2 Notice This manual and any examples contained herein are provided “as is” and are subject to change without notice. Hewlett-Packard Company makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard Co.
- Page 3 Agreement. Product Recovery CD -ROM. If your computer was shipped with a product recovery CD-ROM: (i) The product recovery CD-ROM and/or support utility software may only be used for restoring the hard disk drive of the HP computer with which...
- Page 4 the product recovery CD-ROM was originally provided. (ii) The use of any operating system software by Microsoft contained in any such product recovery CD-ROM shall be governed by the Microsoft End User License Agreement (EULA). Transfer of Rights in Software. Customer may transfer rights in the software to a third party only as part of the transfer of all rights and only if Customer obtains the prior agreement of the third party to be bound by the terms of this License Agreement.
-
Page 5: Table Of Contents
Contents 1. Using the Port Replicator ... 1-7 Understanding the Basics ... 1-9 To dock the OmniBook ...1-10 To undock the OmniBook ...1-12 To reset the OmniBook ...1-12 To attach a security cable ...1-13 Making Connections ...1-14 To connect an external keyboard ...1-15 To enable an external Fn key ...1-15 To connect a PS/2 mouse ...1-16 To switch back to the internal TouchPad...1-16... -
Page 7: Using The Port Replicator
Using the Port Replicator... - Page 8 Using the Port Replicator Congratulations! With the OmniBook port replicator, you can significantly increase the convenience of your OmniBook for desktop use. By making one connection— plugging your OmniBook into the port replicator—you can get easy access to these types of devices: Printer or other parallel device.
-
Page 9: Understanding The Basics
Understanding the Basics Docking the OmniBook to the port replicator is just like simultaneously adding several devices to the OmniBook. Docking does not cause Windows 95 to create a new hardware profile. Similarly, undocking does not create an undocked profile. This section shows you how to get your port replicator and OmniBook up and running quickly, including how to Dock the OmniBook. -
Page 10: To Dock The Omnibook
To dock the OmniBook C A U T I O N Use only an HP F1377A ac adapter (the type shipped with the OmniBook) not use an ac adapter from another product. Using an improper adapter could damage the OmniBook and will make your warranty invalid. - Page 11 3. Place the OmniBook on the port replicator platform, with the back of the computer facing the port replicator's docking connector. 4. Position your fingers on the platform grips as shown below. Use your thumbs to push the computer firmly toward the port replicator until the OmniBook slides into place.
-
Page 12: To Undock The Omnibook
Using the Port Replicator Understanding the Basics To undock the OmniBook 1. Raise the release lever at the top of the port replicator. 2. After removing the OmniBook, push the release lever back into place. To reset the OmniBook You can reset the OmniBook without undocking. Press the reset button on the port replicator. -
Page 13: To Attach A Security Cable
To attach a security cable Your port replicator has a built-in security port that allows you to secure the port replicator with a cable. Be sure to use a second Kensington lock to secure the OmniBook. Kensington MicroSaver lock systems work with these ports and are available at many computer stores. -
Page 14: Making Connections
Using the Port Replicator Making Connections Making Connections When making connections, notice that the orientation of the ports on the port replicator are the reverse of the OmniBook. Turn the connector cables over when switching from the OmniBook to the port replicator. This section describes how to connect devices to the port replicator, including the following: External keyboard. -
Page 15: To Connect An External Keyboard
To connect an external keyboard You can use both the built-in OmniBook keyboard and external keyboard while docked. 1. Attach the keyboard cable to the keyboard port. 2. Dock the OmniBook in the port replicator. Keyboard port To enable an external Fn key If you are using a port replicator with an external keyboard, substitute the keystrokes CTRL+ALT for Fn. -
Page 16: To Connect A Ps/2 Mouse
Using the Port Replicator Making Connections To connect a PS/2 mouse The OmniBook has a PS/2 mouse driver installed. When you dock, the OmniBook automatically detects and sets up the mouse. 1. Attach the mouse cable to the mouse port. 2. -
Page 17: To Connect A Serial Mouse
To connect a serial mouse 1. Attach the serial mouse cable to the serial port. 2. Dock the OmniBook in the port replicator. To switch back to 3. Using the TouchPad, click Start, Settings, Control Panel, Mouse, General. the TouchPad, see page 1-16. -
Page 18: To Connect A Universal Serial Bus (Usb) Device
Using the Port Replicator Making Connections To connect a Universal Serial Bus (USB) device Universal Serial Bus (USB) provides a bi-directional serial interface for adding peripheral devices such as game controllers, serial and parallel ports, and scanners on a single bus. The OmniBook's port replicator provides two USB ports. 1. -
Page 19: To Use The Monitor Stand With An External Display
To use the monitor stand with an external display The optional monitor stand (HP F1369A), can support a weight of 69 kg (151.8 lb.). When setting up the monitor stand, be sure that the wide edge faces forward, as shown below. -
Page 20: To Connect A Parallel Device
Using the Port Replicator Making Connections To connect a parallel device Use standard parallel cables and adapters available at computer dealers and electronic supply stores to connect parallel devices. 1. Attach the parallel cable to the parallel port. 2. Dock the OmniBook PC in the port replicator. 3. -
Page 21: To Connect Your Audio Equipment
To connect your audio equipment The port replicator provides the following audio ports: Amplified speaker-out connector for headphones or speakers. 1. Attach the audio cable to the corresponding audio port. 2. Dock the OmniBook in the port replicator. You can press Fn+F7 to mute the sound. -
Page 23: Troubleshooting
Troubleshooting 1-23... -
Page 24: Troubleshooting
The HP Web site provides information about HP mobile-computing products. You can download new software and drivers, get detailed setup instructions, or view a list of frequently asked questions and answers. The HP Web site address is http://www.hp.com/go/omnibook . Technical Support If you’d like to talk to a trained HP representative, you can call Technical... -
Page 25: Solving Problems
Solving Problems If you have a problem using the port replicator, find the symptom that matches your situation. Try the suggestions one at a time. If you need to replace a lost or damaged power cord For the replacement part number for the ac adapter power cord, contact the number in the Support and Service booklet. -
Page 27: Specifications And Regulatory Information
Specifications and Regulatory Information 1-27... -
Page 28: Specifications And Regulatory Information
Specifications and Regulatory Information Your OmniBook port replicator is designed to provide trouble-free operation. The following suggestions can help you while working with your OmniBook: If you have problems, see the problem-solving suggestions and references listed in chapter 2. If you think your port replicator might need repair service, see the warranty and service information in the Support and Service booklet. -
Page 29: Specifications
Specifications Ports 240-pin docking connector. Parallel DB25 (EPP/ECP). Serial DB9 (115,200-bps). VGA port, D-sub 15-pin female connector. 6-pin external keyboard connector. 6-pin external PS/2 mouse connector. Three audio jacks for Speaker-out, Line-in, and MIC-in. 2-pin ac jack for ac adapter. MIDI port: D-sub, 15-pin female for MIDI in/out. -
Page 30: Regulatory Information
Hewlett-Packard could void the authority to operate the port replicator in these regions. This port replicator is for use only with the I.T.E. (Information Technology Equipment) notebook computer, model HP OmniBook 3000. U.S.A. The port replicator generates and uses radio frequency energy and may interfere with radio and television reception. -
Page 31: Canada
Specifications and Regulatory Information Regulatory Information Canada This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the radio interference regulations of the Canadian Department of Communications. Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de Classe B prescrites dans le règlement sur le brouillage radioélectrique édicté... -
Page 32: Declaration Of Conformity
Hewlett-Packard Co. Mobile Computing Division 1000 NE Circle Blvd. Corvallis, OR 97330 declares that the following product Product name: HP F1381A port replicator Options: conforms to the following product specifications Safety: IEC 950:1991+A1,A2 / EN 60950 (1992)+A1,A2 EMC: CISPR 22:1993 / EN 55022 (1994): Class B [1]... - Page 33 + F5, 1-19 serial device, 1-17 + F7, 1-25 serial mouse, 1-17 + up arrow, 1-25 USB device, 1-18 Fn key (external), 1-15 contacting HP, 1-28 help, 1-24 Declaration of HP First, 1-24 Conformity, 1-32 joystick, 1-20 Kensington lock, 1-13...
