- Page 1 Wrist Blood Pressure Monitor Model R6 • Instruction Manual • Mode d’emploi • Gebrauchsanweisung • Manuale di istruzioni • Manual de instrucciones • Gebruiksaanwijzing IM-HEM-6000-E-01-08/08 1638173-4D...
-
Page 2: Table Of Contents
Contents Before using the unit Introduction .............3 Important Safety Information ......4 1. Overview............6 2. Preparation..........8 2.1 Installing/Replacing the Batteries ..8 2.2 Setting the Date and Time ....10 Operating instructions 3. Using the Monitor........12 3.1 Applying the Wrist Cuff .......12 3.2 Taking a Reading........14 3.3 Using the Memory Function....17 4. -
Page 3: Introduction
The small, pre-formed wrist cuff is very convenient and easy to apply. With the push of a button the OMRON Wrist Blood Pressure Monitor measures your blood pressure and pulse and displays the reading on a clear digital panel. -
Page 4: Important Safety Information
Important Safety Information Consult your doctor during pregnancy, arrhythmia and arteriosclerosis. People with poor peripheral circulation may find that results for measurements taken at the wrist vary from those taken on the upper arm. Please read this section carefully before using the unit. - Page 5 Important Safety Information • Do not use a mobile phone, or other devices that emit electromagnetic fields, near the unit. This may result in incorrect operation of the unit. • Do not operate unit in a moving vehicle (car, airplane). (Battery Usage) •...
-
Page 6: Overview
1. Overview Main Unit A. Display C. Wrist cuff B. Battery compartment D. MEM (Memory) button E. O/I START button SET button... -
Page 7: Package Contents
1.Overview Display G. Systolic blood pressure M. Heartbeat display H. Diastolic blood pressure (Flashes when the monitor Battery low display is at the correct position) Deflation display N. Memory value display K. Right wrist measurement (Displayed when viewing display values stored in memory) Position sensor alarm O. -
Page 8: Preparation
2. Preparation Installing/Replacing the Batteries Remove the battery cover by pulling it off in the direction of the arrow. Insert two “AAA” alkaline (LR03) batteries in the battery compart- ment. Make sure their polarity (+/–) is aligned with the polarity (+/–) as indicated in the battery compart- ment. - Page 9 2.Preparation Battery Life & Replacement If the battery low symbol ( ) appears on the display, replace both batteries at the same time. - When the battery low symbol ( ) starts to blink, you will still be able to use the unit for a short while. You should replace the batteries with new ones ahead of time.
-
Page 10: Setting The Date And Time
2.Preparation Setting the Date and Time Your blood pressure monitor automatically stores up to 90 measure- ment values in its memory and calculates an average value based on the last three measurements. If the correct date and time has not been set, the measurement values will not be stored in memory. - Page 11 2.Preparation Repeat steps 2 and 3 to set the month and day. Repeat steps 2 and 3 to set the hour and minutes for the time. Note: The monitor will automatically turn itself off after you press the SET button to confirm the minute setting.
-
Page 12: Using The Monitor
The blood pressure can differ between your right and left wrist and therefore also the measured blood pressure values can be different. Omron recommends to always use the same wrist for a measurement. If the values between the two wrists differ substantially, please check with your doctor which wrist to use for your measurement. - Page 13 3.Using the Monitor Hold the bottom part of the wrist cuff and wrap it around the wrist while pulling so that it fits comfortably. Make sure that the wrist cuff does not cover the protruding part of the wrist bone (ulna) on the outside of the wrist. Unless the wrist cuff is wrapped securely around the wrist, it may not be possible to take correct measurements.
-
Page 14: Taking A Reading
3.Using the Monitor Taking a Reading Sit comfortably, hold your arm across your chest and relax. Press the O/I START button. Hold your arm across your chest so that your fingers are touching the opposite shoulder bone. Wrist too low Wrist too high Correct position Adjust the height of your wrist until the position sensor alarm... - Page 15 3.Using the Monitor After the monitor has detected your blood pres- sure and pulse rate, the cuff automatically deflates and your blood pressure and pulse rate are displayed. Note: The time and date of the measurement are Alternating display displayed alternately. Press the O/I START button to turn off the monitor.
- Page 16 3.Using the Monitor What is Irregular Heartbeat? An irregular heart- Normal Heartbeat beat is a heartbeat rhythm that varies by Pulse more than 25% from the average heart- Blood pressure beat rhythm detected Irregular Heartbeat while the unit is mea- Short Long suring the systolic and...
-
Page 17: Using The Memory Function
3.Using the Monitor Using the Memory Function This monitor has a memory capable of storing 90 sets of readings. Every time you complete the measurement, the monitor automati- cally stores blood pressure and pulse rate. The monitor also displays an average reading based on the measurements from the three most recent readings. - Page 18 3.Using the Monitor Press the SET button, while the average reading is displayed, to view readings from the oldest reading stored in memory. Press the SET button repeatedly to cycle through the readings. To Delete All Values in Memory You cannot delete the stored readings partially, all reading in the monitor will be deleted.
-
Page 19: How To Modify The Settings
4. How to Modify the Settings You can modify the options for the various settings of your monitor. This is done by pressing the SET button to select a setting, then pressing the MEM button to select the options for that setting. After selecting a setting, press the O/I START button to confirm the setting and turn the power off. -
Page 20: Setting The Position Sensor Alarm
4.How to Modify the Settings Setting the Position Sensor Alarm Press the SET button until the posi- tion sensor alarm display ( appears on the display. The default settings is “On1”, and this emits a series of two short blips if your wrist is too far away from the measuring position, and beeps slowly when you wrist is in the cor-... -
Page 21: Quick Reference Guide
You may require more rest time between readings depending on your individual physiological characteristics. • Only use the R6 to measure your own blood pressure since the results of measurements are stored in memory. • Always wrap the wrist cuff around your wrist before starting to take a measurement. -
Page 22: Handling Errors And Problems
6. Handling Errors and Problems Symptom Cause Correction Batteries are empty. Replace with new batteries. No display appears when the O/I START button is Insert the batteries Batteries were pressed. with the correct [+] inserted incorrectly. [-] polarity. Are you holding the Measure while in wrist cuff at heart the correct posture. - Page 23 Reading” on p. 14. If this result can be error continues to appear, considered reli- consult your doctor. able. Consult your OMRON An E mark is displayed. retail outlet or distributor. Replace the batteries with The battery alkaline two new “AAA”...
-
Page 24: Storage And Maintenance
It is generally recommended to have the monitor inspected every two years to ensure correct functioning and accuracy. Please con- sult your authorised OMRON dealer or the OMRON Customer Ser- vice at the address given on the packaging or attached literature. -
Page 25: Technical Data
8. Technical Data Name OMRON Wrist Blood Pressure Monitor Model OMRON R6 (HEM-6000-E) Display LCD Digital Display Measurement Oscillometric method Pressure: 0 to 299 mmHg/ Measurement Range Pulse: 40 to 180 beats/min Memory 90 Measurements with date and time Pressure: Within ±3 mmHg Accuracy Pulse rate: Within ±5% of reading... - Page 26 8.Technical Data • This OMRON product is produced under the strict quality system of OMRON Healthcare Co. Ltd., Japan. The Core component for OMRON blood pressure monitors, which is the Pressure Sensor, is produced in Japan. • Disposal of this product and used batteries should be carried out in accordance with the national regulations for the disposal of electronic products.
-
Page 27: Correct Disposal Of This Product
This medical device manufactured by OMRON Healthcare conforms to this EN60601-1-2:2001 standard for both immunity and emissions. Nevertheless, special precautions need to be observed: Do not use mobile (cellular) telephones and other devices, which generate strong electrical or electromagnetic fields, near the medical device. -
Page 28: Some Useful Information About Blood Pressure
9. Some Useful Information about Blood Pressure What is Blood Pressure? Blood pressure is a measure of the force of blood flowing against the walls of the arteries. Arterial blood pressure is constantly changing during the course of the heart's cycle. The highest pressure in the cycle is called the Systolic Blood Pres- sure;... - Page 29 9.Some Useful Information about Blood Pressure Upper curve: systolic blood pressure Lower curve: diastolic blood pressure Time of day Example: fluctuation within a day (male, 35 years old) Classification of Blood Pressure by the World Heath Organization The World Health Organization (WHO) and the International Society of Hypertension (ISH) developed the Blood Pressure Classification shown in this figure.
- Page 30 OMRON HEALTHCARE CO., LTD. 24, Yamanouchi Yamanoshita-cho, Manufacturer Ukyo-ku, Kyoto, 615-0084, Japan OMRON HEALTHCARE EUROPE B.V. Kruisweg 577, representative 2132 NA Hoofddorp, The Netherlands www.omron-healthcare.com OMRON DALIAN CO., LTD. Production Economic & Technical Development Zone facility Dalian 116600, China OMRON HEALTHCARE UK LTD.
