- Page 1 Guide de d’emarrage et Guide d’installation Guía de inicio rápido y Manual de instalación NX404 DVD MULTIMEDIA STATION WITH BUILT-IN NAVIGATION & 6.2” TOUCH PANEL CONTROL Station multimédia DVD avec navigation intégrée et commande par écran tactile de 6.2 pouces...
-
Page 2: Clarion Product Registration Information
Register at www.clarion.com - it’s easy to keep your Clarion product up to date. à l’intention des autres utilisateurs, il faut choisir le type d’antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l’intensité... -
Page 3: Table Of Contents
Contents 14. START USING Clarion MOBILE MAP ........23 INSTALLATION ................27 1. PRECAUTIONS ................3 1. Before Starting ................27 INFORMATION FOR USERS: ............4 2. Package Contents ..............27 2.OPERATIONAL PANEL ..............6 3. General Cautions ..............27 Functions of Buttons ..............6 4. Cautions on Installation ............27 3. -
Page 4: Precautions
Using a fuse with a different specification may causes a fire. • Keep the amount of time spent viewing the screen while driving to a • For the installation of this unit or a change in the installation, ask strict minimum. your authorized dealer or a nearest Clarion service center for safety. • The navigation system does not provide, nor represent in any way Professional skills and experiences are required to do so. information on: traffic and highway regulations; technical aspects • This navigation system should not be used to replace your own... -
Page 5: Information For Users
7-8239-1014-00-01 切边务必整齐,不得歪斜。 player, do not use the player for about one hour. The condensation 吕崇垚 20140102 NX404 will disappear naturally allowing normal operation. 2.Driving on extremely bumpy roads which cause severe vibration may cause the sound to skip. 3.This unit uses a precision mechanism. Even... - Page 6 ® the Bluetooth SIG, Inc. And any use of such marks by Clarion Co.,Ltd. is under license. Other trademarks and trade names are those of their respective owners. • Pandora. the Pandora logo. and the Pandora trade dress are trademarks or registered trademarks of Pandora Media.
-
Page 7: Operational Panel
• Press this button to display main menu; press again to return current source. • Press and hold this button for 2 seconds to turn off the monitor. Press any place of the screen to turn on the monitor again. NX404... -
Page 8: Turning The Power On
• Press [MENU] button on the PANEL to show main source menu. • Change page by dragging left or right or touching other buttons. • Touch the icons on the screen to enter corresponding work mode, such as Disc mode, Tuner mode, Telephone mode, etc. NX404... -
Page 9: Main Menu
Flicking to right or left it will switch to next or previous page of main menu. Moving the menu position 1. Touch any quadrate icon on main menu more than 2 seconds, the icon will float on main menu. 2. Scrolling the floating icon to any position you want. NX404... -
Page 10: Dvd Video Player Operations
On DVD discs containing two or more titles, you can select from the title menu for playback. 1. Showing the DVD Video menu, touch [ ] button during playback. * Depending on the disc, the title menu may not be called. NX404... -
Page 11: Cd Player Operations
10 - Shortcut button 11 - Repeat button 12 - Audio button 13 - Subtitle button 1 - Option button 2 - Elapsed playing time indicator 3 - Rotation effect 4 - Page turning button 5 - System time NX404... -
Page 12: Usb Audio Operations
• The number on the folder symbol is the number of files and folders number in current folder. • Touch the title of current folder, play list will show files and folders in upper folder. 1. Option button 2. Play/Pause button 3. Previous Track /Fast Backward button 4. Next Track/Fast Forward button NX404... -
Page 13: Usb Video Operations
2 - Play/Pause button 3 - Next Track/Fast Forward button 4 - Elapsed playing time indicator/Seek bar 5 - Menu list 6 - Repeat button 7 - System time 8 - Bluetooth status indicator 9 - Playback information 10 - Shortcut button NX404... -
Page 14: Ipod/Iphone Operations
4 - Previous Track /Fast Backward button 5 - Play/Pause button 6 - Next Track/Fast Forward button 7 - ID3 information 8 - Next Page[ ] / Previous Page[ ] button 9 - Category list 10 - System time 4 - Back to father folder NX404... -
Page 15: Ipod Video Id3 Mode Screen
7 - Category list 8 - Next Page[ ] / Previous Page[ ] button 9 - System time 10 - Bluetooth status indicator 11 - Playback status indicator 12 - Art work 13 - Shortcut button 14 - Progress bar NX404... -
Page 16: Pandora Operations
Touch this button Thumbs-down current track and play next track. 5 - Play/Pause button Use to control playback and pause. (1). Touch the button during playback. Playback pauses. (2). To resume playback touch the key again. 6 - Next track button 7 - Thumbs-up 8 - System time NX404... -
Page 17: Selecting The Bluetooth Audio Mode
• This system will not operate or may operate improperly with some Bluetooth audio players. • For detailed information on the playable Bluetooth audio players, see our home page: www.clarion.com Selecting the Bluetooth Audio Mode 1. Touch the [Bluetooth Audio] key to select the Bluetooth Audio mode. -
Page 18: Registering Your Bluetooth Audio Player (Pairing)
When the pairing operation completes, the registered Bluetooth audio player is set as the current device, after selecting the favorite icon, the display return to the device list screen. Touch [ ] button, the display will return to the Bluetooth audio mode screen. NX404... -
Page 19: Selecting The Bluetooth Audio Player
The corresponding cellular phone is set as current telephone. 4. Touch the [ ] button to return to the previous screen. Controlling the Bluetooth Audio Player Note: • Occasionally, depending on the environment, playback sounds may be fragmented, NX404... -
Page 20: Select The Bt Phone Mode
OFF. [ ] and signal level indicator are displayed at the top of the screen. Note: The “auto-connect” is effective to the cellular-phone of last connecting. Setting Automatic Answer If a call comes in, answer automatically after 5 seconds. NX404... -
Page 21: Registering Your Cellular Phone (Pairing)
• The input level of the microphone can be affected by its surroundings. Adjust the level if the person on the other end of the telephone has a reception problem. 3. Touch the [ ] button to display the Inquiring Device screen. NX404... -
Page 22: Select The Cellular Phone
3. Touch the desired Device button you wish to use. Touch [ ] button to select it as your active device. The corresponding cellular phone is set as the current telephone. • If the power of the cellular phone is not turned on, turn it on. NX404... -
Page 23: Tuner Operations
] button again to stay in that station. 12. Shortcut button DX/Local Setting 13. Option button The DX / Local setting changes the tuner sensitivity in order to separate closely spaced stations. This feature is useful in areas that have many radio stations in close proximity. NX404... -
Page 24: Start Using Clarion Mobile Map
19. Select destination. Quick menu When Clarion Mobile Map is started the first time, you need to do the following: 20. The Quick menu is a selection of controls and functions that are frequently 1. Select the written language of the application interface. Later you can change it needed during navigation. - Page 25 NX404...
- Page 26 • Confirm the battery voltage of the vehicle to be installed. This unit is designed only for vehicles with DC 12V power supply. • Disconnect the negative terminal of the battery before connecting wires, otherwise an electric shock, injury by short circuit may occur. NX404...
- Page 27 • When wiring the connecting cables in a vehicle with an airbag system, never feed the cables through a place where it may affect the operation of the airbag. An airbag not operating correctly in an emergency may cause increased injury. NX404...
-
Page 28: Installation
1. Do not open the case. There are no user- serviceable parts inside. If you drop anything into 3. Be sure to disconnect the battery “-” the unit during installation, consult your dealer or an authorized Clarion service center. terminal before starting. This is to prevent 2. -
Page 29: Installing The Main Unit
In some cases the center panel may require modification. (Trimming, filing, etc.) For TOYOTA vehicle For NISSAN vehicle • Removing the Main Unit Figure 4 When the main unit is to be removed, disassemble it in the reverse of the order in “INSTALLING THE MAIN UNIT”. NX404... -
Page 30: Wire Connections
• In the optional devices, the RCA cables and the Connector cables are separately-sold items. • When connect the HDMI cable, be sure to fix with the HDMI cable holder and Machine screw(M2 x 4). Main Unit NX404 8- Hexagonal screws (M5x8) HDMI cable holder Mounting bracket Center Panel... -
Page 31: Installing The Gps Antenna
• Wire the GPS antenna cord. Fuse (15A FUSE) Fasten the cord using the cord holders. Cord holder Fuse holder Figure 7 Double-sided tape • Stick the double-sided tape to the bottom face of the GPS antenna. Bottom face of the GPS antenna NX404... - Page 32 Blue Auto antenna Brown Phone interrupt Grass- green Parking brake cord Purple Whit Reverse gear cord Note: *1: Connecting the PHONE INTERRUPT terminal The phone interrupt will mute the audio if the lead receives a negative or ground signal. NX404...
- Page 33 Clarion Co., Ltd. All Rights Reserved. Copyright © 2013: Clarion Co., Ltd. Printed in China / Imprimé en Chine / Impreso en China 2013/12...
