  • Page 1 Bulletin 539-A HumidiClean ™ Series HC- 6100/6300/6500/6700 Humidifiers Installation, Operation and Maintenance Instructions Table of Contents Page Warning Labels Description of Model Number Installation 6-12 Display Menu 13-16 Start-Up Procedure and Operation 16-17 Maintenance 18-22 Troubleshooting 22-27 Typical Wiring Schematic 28-37 Repair Parts 36-42...

  • Page 2: Installation

    The Armstrong HumidiClean humidifier converts ordinary tap water or purified water to steam for distribution to raise the relative humidity level. To allow HumidiClean to function to its full capability, be certain to install in accordance with Armstrong recommendations. DANGER: ELECTRICAL SHOCK HAZARD HIGH VOLTAGES EXIST INSIDE THE HUMIDIFIER TO PROTECT YOURSELF AND OTHERS FROM ACCIDENTAL SHOCKS: Keep the humidifier locked during normal operation and store the key in a safe location away from the humidifier.
  • Page 3 Warning: Do not operate the supplied humidifier in combustible or explosive surroundings. Warning: Do not operate the supplied humidifier if there is any damage to the cabinet or any components in humidifier are damaged. Warning: The main switch should be a connection breaker which has over current and leakage current protecting functions per code EN60947-3 or EN60947-2 if point gap required by EN60947-3 can be fulfilled.

  • Page 4: Installation

    • This disconnecting switch should have leakage current protecting function. The max leakage current should be less than 30mA • The disconnecting switch should have a breaking capacity sufficient to interrupt the largest normal running current of loads. The breaking capacity required should be selected according to the table, 7-1, 7-2, 7-3 and 7-4 located on page 7.
  • Page 5 Figure 5-1 HC-6100/6300 Installation Pitch Min. 1” Per 12” Back to Unit Hose Clamp Steam Hose or Copper Full Size Tee See Detail “A” Hose 2” Insulated Copper 2” Copper Tee “P” Trap Drain Every Soldered Joints 20’ of Piping or at Reducer Bottom of Vertical Run 1/2”...
  • Page 6 Installation HC-6100/6300 Mounting The HumidiClean models HC-6100/6300 are designed to be wall mounted. A wall mounting bracket and lag screws are provided for mounting on 410 mm (16”) centers. The operating weight of the unit is 106 kg (233 lbs). A clearance of 600 mm (23”) on the front and sides of the cabinet is required for servicing.
  • Page 7 Table 7-1. Recommended Branch Circuits Table 7-1. Recommended Branch Circuits Rating Amp 1-12 13-15 16-20 21-24 25-32 33-40 41-48 49-64 68-80 81-100 101-120 121-140 141-60 (AWG) Wire (mm2) Circuit Breaker Table 7-2. Steam Capacities and Rating Amperages Table 7-2. Steam Capacities and Rating Amperages HC6100/HC6100DI HC6300/HC6300DI 3 KW Unit...
  • Page 8 Duct Steam Distribution 1. The dispersion tube should be proper length. Verify correct size from Table 8-1. 2. Install dispersion tube(s) horizontally in duct so holes face upward. Air flow must be vertical up or horizontal. Do not restrict duct with a height of 200 mm (8”) or less. Installations over 10 m/s (2000 FPM) air velocity are not recommended.
  • Page 9 Area Steam Distribution The EHF-3 fan package (minimum of 2 required for HC-6500/6700) is designed to be hung on a wall to operate as a remote mounted, direct area discharge option. It incorporates a blower rated at 120v- 2.90 amps. CFM rating is 465 @ 1530 RPM. The fan package requires a separate 120 volt power sup- ply (optional step down transformer available).
  • Page 10 Figure 10-1 Standard Humidistat H200-XX-XX-XX Supply Main Stat/Sensor In Modulating High Limit Sensor A18609 or Outdoor Temperature Sensor A18610 0-10 Vdc Ground Stat (Standard) Class 2 Alarm A8581 High Limit/ High Limit Air Flow Switch Humidistat Ground A9023 Pressure Switch To Set Up: 1) S1-1, 3 Off, S1-2 On 2) S3-1 On, S3-2, 3, 4 Off...
  • Page 11 Figure 11-1 0-10 Vdc or 4-20mA Control Signal Supply Main Stat/Sensor In Modulating Control High Limit Sensor Signal Outdoor Temperature Sensor Ground S5079a,b,c 4-20ma Setup 10 vdc Setup 1) S3-1 On, 3-2, 3, 4 Off (Default) 2) S1-2 On, S1-1, 3 Off (Default) 3) S2-1 On, S2-2, 3 Off if 4-20ma S2-1, 2, 3 All Off If 0-10vdc 4) Select Corresponding Control Signal...
  • Page 12 High Limit Humidistat Remove the jumper tab from ground and in of high limit/pressure switch connections and wire the high limit stat between these terminals. Refer to Figure10-1 (the overall wiring diagram) for more inform ation. A duct mounted high limit humidistat is recommended to prevent over-saturation of the duct air. Use an on-off controller that opens on fault (high humidity).

  • Page 13: Display Menu

    Display Menu The menu can be accessed via the keypad below the LCD, on the front of electric cabinet. Use the UP or DOWN to change the menu in current level; press ESC to previous menu level; press ENTER to access the current menu.
  • Page 14 Operation Setup Operation Setup Enter Password 0000 (Default) Desired RH This menu is displayed when RH sensor is selected Desired RH: XX % Default: 50% Current RH: XX% LT RT move the cursor UP DN to increase/decrease value Steam Generation Steam Gen (Default) Manual Drain Manual Fill...
  • Page 15 Operation Setup - Continued Operation Setup - Continued Drain Frequency Default: 12 hours 12 (Default) No Drain Real Time Real Time Set 24 Hour Clock Drain Time 5 (Default) Load Default Reset all to Default? Confirm Cancel Signal Type 0-10 Vdc (Default) 0-5VDC 1.9V - 3.9V 4-20mA...
  • Page 16 Unit Configuration Enter Password ARMH Run Mode Run (Default) Test Contactor Count Control Type PWM (Default) On/Off Power Settings 1000 W 3000 W 5000 W 6650 W 8000 W Ionic Time Reset Clear Ionic Time Confirm Cancel Error Record Clear Clear Error List Confirm Cancel...
  • Page 17 Principle of Operation The HumidiClean humidifier converts ordinary tap water or purified water to steam for distribution to raise the relative humidity level. The demand for humidity is sensed by a humidistat or sensor which sends a control signal to the HumidiClean. The HumidiClean is connected to the power supply (208, 220/240, 380/400, 480 or 600 Vac) through a separate circuit breaker supplied by the customer.
  • Page 18 Completing a Service Life Cycle When 90% of the setting service time has accumulated, the "STATE" LED on the control panel will blink in yellow. (Refer to EOL settings, for bed life duration settings). If the HumidiClean is not serviced at this time;...

  • Page 19: Maintenance

    Restoring the Unit to Operation a) Turn power on at breaker. b) Unit should begin to fill. Maximum fill time is approximately 30-45 minutes before contactor(s) will be closed. c) If this does not take place, operate the menu, and change the status to "STEAM GEN."...
  • Page 20 Figure 20-1 HC-6100/6300 Steam Outlet Equalizing Connection to Top of Level Canister Cover Locating Pins Ionic Beds Equalizing Connection to Bottom of Level Canister Heating Elements Drain Oulet Connection Mounting Bolt Locations Figure 20-2 HC-6500/6700 Steam Outet Equalizing Connection to Top of Canister Cover Locating Pins...
  • Page 21 9. Operate the unit configuration menu “Ionic Time Reset”, to reset the ionic bed life. All the accumulated ionic bed time has been reset to zero. The unit should now be heard filling. NOTE: The accumulated ionic bed time can be reset to zero at anytime. However, the unit should not be reset without first inspecting the ionic beds.

  • Page 22: Troubleshooting

    Removing the Tank, HC-6100/6300 Only 1. Operate menu to "MANUAL DRAIN" and allow unit to complete a deep drain. (Caution: Tank will still be quite warm). 2. Turn off circuit breaker. 3. Unlock and open front and side doors. Remove left side panel. 4.
  • Page 23 8. If drain valve and fill valve are both energized and water is below the 1/3 full level in the electrode canister (float canister for DI units), make sure the status of Steam Generation in menu is "STEAM GEN.". Perform continuity check to be sure. 9.
  • Page 24 4. If fuses are OK, check voltage to contactor coil. (a) If voltage is 24-28VAC at contactor coil, check coil resistance. It should be 8Ω with wires disconnected. If resistance is OK, check voltage drops across the contactor. (b) If no voltage to contactor coil, check continuity of wires from PC board to contactor. If continuity is OK, PC board is likely defective.
  • Page 25 Humidifier runs continuously, %RH is well under set-point. 1. Verify humidistat/RH sensor is wired correctly and dip switches (S2 & S3, See Fig. 10-1, 11-1 and 11-1) on the PC board are set correctly for the humidistat signal. 2. Check humidistat demand signal at low voltage terminal strip. It should be close or at 100%. 3.
  • Page 26 Dispersion tube spits water or water is present in duct Hint: It is very helpful to cut a small observation window in the duct and cover it with Plexiglas so the steam discharge from the manifold can be observed. This way the problem can be narrowed down to piping/steam quality (steps 1 and 2) or a condensation problem (steps 3 and 4).
  • Page 27 2 WATER LEVEL DROPPED BELOW LOW LEVEL - - The low level switch has not closed after 5 minutes of fill valve on time. This is only after initial start-up fill and boil-down sequence. Check: debris in water switch canister, defective fill valve, no water flow or low water pressure, drain valve stuck open, defective low water level switch (electrodes need to be cleaned).
  • Page 28 HC6100-Wye Wiring layout...
  • Page 29 HC6100-Delta Wiring layout...
  • Page 30 HC6100-PAR Single Phase Wiring Layout...
  • Page 31 HC6300-Wye Wiring layout...
  • Page 32 HC6300-Delta Wiring layout...
  • Page 33 HC6500-Wye Wiring layout...
  • Page 34 HC6500-Delta Wiring layout...
  • Page 35 HC6500-WYE (2 contactors) Wiring Layout...
  • Page 36 HC6500-Delta (2 contactors) Wiring Layout...
  • Page 37 HC6700-Wye Wiring layout...
  • Page 38 HC-6000 Repair Parts Item No. Water Compartment Part No. Item No. Part No. Electrical Compartment and Front Panel Item No. Water Compartment Part No. Item No. Electrical Compartment and Front Panel Part No. — PVC Tubing 5/8" A7618A Label Front Panel With Keypad RDHC6000-014 —...
  • Page 39 HC-6100 HC-6100 3kW DI Voltage Without TC With TC Without TC With TC 2PCS/Unit 1PCS/Unit 2PCS/Unit 1PCS/Unit B5808-1 B5809-1 B5810-1 B5811-1 B5808-2 B5809-2 B5810-2 B5811-2 B5808-1 B5809-1 B5810-1 B5811-1 B5808-3 B5809-3 B5810-3 B5811-3 B5808-4 B5809-4 B5810-4 B5811-4 HC-6100 HC-6100 15kW Voltage Without TC With TC...
  • Page 40 Float Level Assy DI/RO C4560 — Float Switch DI/Ro B5139 Item Item Water Compartment Part No. Steam Generator Part No. S-assy Ionic Bed HC-6000 B5213 (14 required for Model HC-6500 and HC-6700) — Thermistor 5 KOHM With Wire (Aquastat) RDHC6000-006...
  • Page 41 HC-6000 Repair Parts Resistance Value of 6100/6300 Components Resistance Value of 6500-6700 Comoponents Component Voltage Resistance Component Voltage Resistance 18 Ω 8.8 Ω Fill Valve 24Vac Fill Valve 24Vac 10 Ω 4.1 Ω Drain Valve 24Vac Drain Valve 24Vac 7-9 Ω 0.51 Ω...
  • Page 42 HC-6000 Repair Parts HC6500/HC6700 30kW 33.5kW 40kW 45kW Voltage Without TC With TC Without TC With TC Without TC With TC Without TC With TC 5PCS/Unit 1PCS/Unit 5PCS/Unit 1PCS/Unit 5PCS/Unit 1PCS/Unit 8PCS/Unit 1PCS/Unit B5433-1 B5434-1 B5433-1 B5434-1 B5433-1 B5434-1 B5433-1 B5434-1 HC6500/HC6700 48kW...
  • Page 43 Procedure of HC6000 Version 7 Soft Refresh This section is used for HC6000 software reprogramming only. Please follow the instructions carefully, or pc board could become un-functional. 1. Install the driver program for Atmel MCU, SAM-BA on your computer first. The link for the Atmel program AT91-ISP.exe and the latest version of can be found at the following location: www.armstronginternational.com/hc6000refresh 2.
  • Page 44 Fig.2 Code Download Window d. Click the "open folder" button on the right of textbox "Send File Name" to open the latest code, please see figure 3 below. You will then have to locate the .bin file that you downloaded from the website and then hit open.
  • Page 45 e. Click the button "Send File" to send the latest code into board. You will be asked to unlock the involved lock regions (0 to 7), click the button "Yes" to begin send code into board. Please see figure 4 below. Fig.4 Message Unlock Involved Lock Regions Window When sending was finished, you will be asked to lock all locks that you have opened just now, click the button "Yes"...
  • Page 46 g. When operation has finished, close the "SAM-BA" window first, and then click the icon "remove the USB hardware" to disconnect the link between computer and board. After reminder by system, disconnect the power supply from breaker and pull out the USB cable. h.
  • Page 47 Table 46-1 Modbus Variable Lists For modbus function number data type attribute data address description 10001 Fill valve status 0:off 1:on 10002 Drain valve status 0:off 1:on 10003 contactor 1 status 0:off 1:on function 2 , read only MODBUS POLL: read only 10004 contactor 2 status 0:off 1:on READ DISCRETE INPUT...
  • Page 48 Table 47-1. BACnet Variable List Data BACnet Data Type Description Attribute Address Fill valve status 0:off 1:on Drain valve status 0:off 1:on contactor 1 status 0:off 1:on Binary Input Read Only contactor 2 status 0:off 1:on contactor 3 status 0:off 1:on contactor 4 status 0:off 1:on Network control 0:Local 1:Remote...
  • Page 49 Table 48-1. LonWorks Variable List Data Array Data Array Node SNVT Map Descriptor Name Lon Function Function SNVT Type Name Offset Name option oFILLSTATUS BITA NVPO Server Lon_1 SNVT_switch state oDRAINSTATUS BITA NVPO Server Lon_1 SNVT_switch state oCON1 BITA NVPO Server Lon_1 SNVT_switch...
  • Page 50 Physical Data, Capacities and Dimensional Drawings Figure 49-1. Models HC-6100 and HC-6300 1” Drain Electrical Supply Knock-Out for Humidistat Knock-Out for Humidistat Table 134-1. Physical Data HC-6500, HC-6700 HC-6100 and HC-6300 and HC-6700DI Inches Inches "A"-Width 21-15/16 "B"-Height 32-1/16 56-3/18 1428 "C"-Depth...
  • Page 51 Physical Data, Capacities and Dimensional Drawings Figure 135-1. Models HC-6500 and HC-6700 — Front, Side, Top Views Electrical Supply (Under Cabinet) Water Supply 1” Drain Port (Under (Under Cabinet) Cabinet) Knock-Out for Humidistat Knock-Out for Humidistat...

  • Page 52: Warranty

    Armstrong International, Inc. Limited Warranty and Remedy Armstrong International, Inc. ("Armstrong") warrants to the original user of those products supplied by it and used in the service and in the manner for which they are intended, that such products shall be free from defects in material and workmanship for a period of one (1) year from the date of installation, but not longer than 15 months from the date of shipment from the factory, [unless a Special Warranty Period applies, as listed below].
