- Page 1 Rack Gigabit Switch Layer 2 24 ports 10/100Mbps Ethernet Switch with 2 ports 1000BASE-T or 1000BASE-SX User’s Guide...
-
Page 2: Fcc Warning
The Atlantis Land logo is a registered trademark of Atlants Land SpA. All other names mentioned mat be trademarks or registered trademarks of their respective owners. Subject to change without notice. No liability for technical errors and/or omissions. FCC Warning... -
Page 3: Table Of Contents
ABLE OF ONTENTS ABOUT THIS GUIDE ........... II ..............ERMS SAGE INTRODUCTION ............1 ........1 THERNET ECHNOLOGY ........1 IGABIT THERNET ECHNOLOGY ..........3 WITCHING ECHNOLOGY ................ 4 EATURES UNPACKING AND INSTALLATION ......5 ..............5 NPACKING ..............6 NSTALLATION ............ -
Page 4: About This Guide
UIDE Congratulations on your purchase of the Management/Smart Gigabit & Fast Ethernet Switch (2×1000BASE plus 24×10/100BASE ports). In this guide, you will find about the following four models: 2×1000BASE-T plus 24×10/100BASE-TX Gigabit Switch 2×1000BASE-SX plus 24×10/100BASE-TX Gigabit Switch These four... -
Page 5: Introduction
NTRODUCTION This chapter describes the features of the Switch and some background information about Ethernet/Fast Ethernet/Gigabit Ethernet switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks. - Page 6 increase in theoretical throughput over 100-Mbps Fast Ethernet and a hundredfold increase over 10-Mbps Ethernet. Since it is compatible with all 10-Mbps and 100-Mbps Ethernet environments, Gigabit Ethernet provides a straightforward upgrade without wasting a company’s existing investment in hardware, software, and trained personnel.
-
Page 7: Switching Technology
Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or Fast Ethernet LAN segments. - Page 8 Features 24×10/100Mbps Auto-negotiation Ethernet ports and 2×10/100/1000Mbps Auto-negotiation Copper Gigabit Ethernet ports or 2×1000BASE-SX Fiber Gigabit Ethernet ports Auto MDI-X for all TX ports Full/half duplex transfer mode for each port Wire speed reception and transmission Store-and-Forward switching method Integrated address Look-Up Engine, supports 32K MAC addresses Supports 2Mbytes RAM for data buffering Supports port base VLAN / Trunking Supports IEEE 802.1p QoS...
-
Page 9: Unpacking And Installation
NPACKING AND NSTALLATION This chapter provides unpacking and installation information for the Switch. To avoid causing any damage to the Switch, we recommend that you read this chapter carefully before starting installation. Unpacking Open the shipping carton of the Switch and carefully unpack the items inside. - Page 10 Installation The site where you place the Switch may greatly affect its performance. When installing, take the following into your consideration: Install the Switch in a site free from strong electromagnetic field generators (such as motors), vibration, dust, and direct exposure to sunlight.
-
Page 11: Rack Mounting
Rack Mounting The Switch can be mounted in an EIA standard-size, 19-inch rack, which can be placed in a wiring closet with other equipments. Attach the mounting brackets to both sides of the Switch (one at each side), and secure them with the provided screws. Then, use screws provided with the equipment rack to mount the Switch in the rack. -
Page 12: Identifying External Components
Switch. Both the front and rear panels are shown below, with a description of each panel features. Front Panel POWER FAN FAULT CONS OLE MG M 2 ×1000BASE-T plus 24×10/100BASE-TX Gigabit Switch P OWER FAN FAULT CONSOLE MG M 2 ×1000BASE-SX plus 24×10/100BASE-TX Gigabit Switch LED Indicators Refer to the next chapter Understanding LED Indicators for detailed information on the meaning of each LED indicator. -
Page 13: Rear Panel
25 & P 1000BASE-T Twisted Pair Ports (RJ-45) or 1000BASE-SX Fiber-Optic Ports (SC) These two RJ-45 ports are auto MDI-X ports: The Switch is equipped with two Gigabit twisted pair ports, the ports will auto negotiate 10/100/1000Mbps. The Switch is equipped with two Gigabit fiber-optic ports, the SC ports can connect to fiber networks on the other end with the same connector. -
Page 14: Understanding Led Indicators
LED I NDERSTANDING NDICATORS The front panel LEDs provide instant status feedback, and, helps monitor and troubleshoot when needed. Power Indicator (green) : When the green light is on, the Switch is receiving power. : Power cut off or improper connection. FAN FAULT Fan Indicator (Amber) : Lights amber when the fan fails to work. -
Page 15: Led S
P OW E R FAN FAULT CONSOLE Ports 1~24 Status LEDs LINK/ACT Link/Activity (green; amber) : When the green light is on, the respective port is (Green) connected to a 100Mbps Fast Ethernet network. Blinking : When the green light is blinking, the port is transmitting (Green) or receiving data on the 100Mbps network. - Page 16 Port 25 & Port 26 Status LEDs 1000BASE-T 1000M LINK/ACT Link/Activity (green) : When the green light is on, the respective port is connected to a Gigabit Ethernet network. Blinking : When the green light is blinking, the port is transmitting or receiving data on the 1000Mbps network.
- Page 17 FDX/COL Collision/Full Duplex (green) : When the green light is on, the respective port is in full duplex (FDX) mode. Blinking : Collision occurs. : When the green light is off, the respective port is in half duplex mode. 1000BASE-SX LINK/ACT Link/Activity (green) : When the green light is on, the respective port is...
-
Page 18: Connecting The Switch
ONNECTING WITCH Referring to the cable specification below, use appropriate cables that meet your speed and cabling requirements when connecting the Switch to your network. The LAN card capabilities play an important role. If any status LED indicator is not shining after making a proper connection, check the PC LAN card, the cable, the Switch conditions and connections. -
Page 19: Cable Specification
RJ-45 10/20 Mbps 2-pair UTP/STP 100 m Cat. 3, 4, 5 100BASE-TX RJ-45 100/200 2-pair UTP/STP 100 m Mbps Cat. 5 1000BASE-T RJ-45 1000/2000 4-pair UTP/STP 100 m Mbps Cat. 5 (Cat. 5E is recommended) 1000BASE-SX 1000/2000 62.5/125µm 220 m... -
Page 20: Configuring The Switch
ONFIGURING WITCH This chapter explains how to configure the Switch to enable its smart functions. Port Speed & Duplex Mode By default, the Switch determines the transmission mode by auto- negotiation for any new twisted-pair or fiber connection after attaching the proper cable to a specific port. For 10/100/1000Mbps RJ-45 ports, if the attached device does not support auto-negotiation or has auto-negotiation disabled, an auto- sensing process is initiated to select speed (10Mbps or 100Mbps or... -
Page 21: Product Support
If you continue to have problems you should contact the dealer where you bought this product. If you have any other questions you can contact the Atlantis Land company directly at the following address: AtlantisLand spa Via Gandhi 5 Ing2,Scala A... -
Page 22: Technical Specifications
10BASET: 2-pair UTP/STP Cat. 3,4,5; up to 100m 100BASE-TX: 2-pair UTP/STP Cat. 5; up to 100m Network 1000BASE-T: 4-pair UTP/STP Cat. 5; up to 100m (Cat. 5E is recommended) Cables 1000BASE-SX: 62.5/125 micron multimode fiber optic, up to 220m 50/125 micron multimode fiber optic, up to 550m... -
Page 23: Physical And Environmental
Physical and Environmental AC inputs: 100 to 240 VAC, 50 or 60 Hz internal universal power supply Power 25 watts. (max.) Consumption: Temperature Operating: 0° ~ 50° C, Storage: -10° ~ 70° C Operating: 10% ~ 90%, Storage: 5% ~ 90% Humidity Dimensions: 440 x 200 x 44 mm (W x H x D)
