4/8 ports 10/100/1000Mbps
Gigabit Ethernet Desktop Switch Layer 2
USER'S GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A02-G4(8)/M2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Atlantis Land A02-G4(8)/M2

  • Page 1 4/8 ports 10/100/1000Mbps Gigabit Ethernet Desktop Switch Layer 2 USER’S GUIDE...
  • Page 2: Fcc Warning

    The Atlantis Land logo is a registered trademark of Atlants Land SpA. All other names mentioned mat be trademarks or registered trademarks of their respective owners. Subject to change without notice. No liability for technical errors and/or omissions. FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 3: Table Of Contents

    ABLE OF ONTENTS ABOUT THIS GUIDE ... 1 ERMS VERVIEW OF THIS INTRODUCTION IGABIT THERNET THERNET WITCHING ECHNOLOGY ... 5 EATURES Ports ... 5 Performance features UNPACKING AND SETUP ... 6 NPACKING ... 6 ETUP ESKTOP OR HELF NSTALLATION ONNECTING ETWORK ...
  • Page 4: About This Guide

    For simplicity, this documentation uses the terms “Switch” (first letter upper case) to refer to the 4(8)-port 10/100/1000Mbps Gigabit Ethernet Switch, and “switch” (first letter lower case) to refer to all Ethernet switches, including the 4(8)-port 10/100/1000Mbps Gigabit Ethernet Switch.
  • Page 5: Introduction

    NTRODUCTION This section describes the features of the 4(8)-port 10/100/1000Mbps Gigabit Ethernet Switch, as well as giving some background information about Gigabit Ethernet, Fast Ethernet and Switching technology. Gigabit Ethernet Technology Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the...
  • Page 6: Fast Ethernet Technology

    to perform 10 times the number of operations in the same amount of time. In addition, the phenomenal bandwidth delivered by Gigabit Ethernet is the most cost-effective method to take advantage of today and tomorrow’s rapidly improving switching and routing internetworking technologies.
  • Page 7: Switching Technology

    Ethernet or fast Ethernet LAN segments. Switching is a cost-effective way of increasing the total network capacity available to users on a local area network. A switch increases capacity and decreases network loading by making it possible for a local area network to be divided into different segments which don’t...
  • Page 8: Features

    Features The 4(8)-port 10/100/1000Mbps Gigabit Ethernet Switch was designed for easy installation and high performance in an environment where traffic on the network and the number of users increase continuously. Switch features include: Ports ♦ 4(8) 10/100/1000Mbps Gigabit Ethernet port Performance features ♦...
  • Page 9: Unpacking And Setup

    If any item is found missing or damaged, please contact your local reseller for replacement. Setup The setup of the Switch can be performed using the following steps: ♦ The surface must support at least 5 kg. ♦ The power outlet should be within 1.82 meters (6 feet) of the device.
  • Page 10: Desktop Or Shelf Installation

    Switch. Desktop or Shelf Installation When installing the Switch on a desktop or shelf, the rubber feet included with the device must be first attached. Attach these cushioning feet on the bottom at each corner of the device. Allow enough ventilation space between the device and the objects around it.
  • Page 11: Connecting Network Cable

    (one on each side) and secure them with the screws provided. Attaching the mounting brackets to the Switch Then, use the screws provided with the equipment rack to mount the Switch in the rack.
  • Page 12: Power On

    Power on The 4(8)-port Gigabit Ethernet Switch can be used with AC power sources 100~240V AC, 50~60 Hz. The power supply of the Switch will adjust to the local power source automatically and may be turned on without having any or all LAN segment cables connected.
  • Page 13: Front Panel

    Switch and status of the network. A description of these LED indicators follows (see LED Indicators). Rear Panel The rear panel of the Switch consists of an AC power connector. The following shows the rear panel of the Switch. Rear panel view of the 4-port 10/100/1000Mbps Gigabit Ethernet...
  • Page 14: Led Indicators

    LED Indicators The LED indicators of the Switch include Power, 1000Mbps and 100Mbps. The following shows the LED indicators for the Switch along with an explanation of each indicator. The 4-port 10/100/1000Mbps Gigabit Ethernet Switch LED ♦ POWER: This indicator lights green when the Switch is receiving power, otherwise, it is off.
  • Page 15: Product Support

    If you continue to have problems you should contact the dealer where you bought this product. If you have any other questions you can contact the Atlantis Land company directly at the following address: AtlantisLand spa Via Gandhi 5 Ing2,Scala A...
  • Page 16: Technical Specifications

    ECHNICAL IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet Standards: IEEE 802.3ab 1000BASE-T Gigabit Ethernet ANSI/IEEE 802.3 Auto-negotiation IEEE 802.3x Full duplex Flow Control Protocol: CSMA/CD Ethernet: 10Mbps (half-duplex), 20Mbps (full-duplex) Data Transfer Fast Ethernet: 100Mbps (half-duplex), 200Mbps (full-duplex) Rate: Gigabit Ethernet: 2000 Mbps (full-duplex) Topology...
  • Page 17: Physical And Environmental

    Physical and Environmental AC inputs: Power Consumption: Operating Temperature: Storage Temperature: Humidity: Dimensions: EMI: Safety: Transmission Method: RAM Buffer: Filtering Address Table: Packet Filtering / Forwarding Rate: MAC Address Learning: 100 – 240 VAC, 50/60 Hz 12 watts max(4 ports), 20 watts max (8 ports) 0 ~ 40 degrees Celsius -10 ~ 55 degree Celsius 5% ~ 95% RH, non-condensing...

This manual is also suitable for:

A02-g4/m2A02-g8/m2
