10. Mounting additional fans / optimized airflow Dear customer! Congratulations for purchasing this premium quality SHARKOON product. For a long life time and to take full advantage of this product we recommend you to read this manual completely. Enjoy our product! -
Page 3: Features
1x 120 mm or 1x 140 mm fan (optional) Rear panel 1x 80 mm, 92 mm or 120 mm fan (optional) • Dimensions: 465 x 185 x 440 mm (L x W x H) • Weight: ~5 kg VaYa EconomY... -
Page 4: Package Contents
2. Package contents • ATX case “Vaya” • Accessory kit 9x stand-offs for mainboard 25x screws for mainboard and 4x screws for PSU mounting drive mounting (3.5" and 5.25") 16x screws for HDD mounting 1x lock attachment and corresponding screw... -
Page 5: The Case At A Glance
D – behind the Mesh panel: 120 mm LED fan (pre-installed) E – Power button and LED F – Reset button and LED Side view (closed/left) A – Fan bracket (120 or 140 mm) B – Air inlet VaYa EconomY... - Page 6 D – Quick fasteners for hard disk drives Rear view A – Opening for I/O shield B – Openings for water cooling C – Fan bracket (80, 92 or 120 mm) D – Slot bezels E – PSU bracket F –Thumb screws VaYa EconomY...
- Page 7 E – Power LED – F – USB connector of the USB front hub G – Audio connectors (HD Audio and AC’97) Note: For further information on how to install the intended devices, refer to their respective user documentation. VaYa EconomY...
-
Page 8: Mounting A Mainboard
The mainboard contains special screw openings (fig. 2). fig. 2 Place the mainboard onto the mounting panel. You have to screw a stand-off into every drilling of the mounting panel you can see through the mainboard’s screw openings. VaYa EconomY... - Page 9 5. Place the mainboard back onto the stand-offs and attach it to the mainboard using the screws for mainboard mounting (fig. 4). (Screws for mainboard mounting) fig. 4 6. Connect the case's front I/O cables to the respective connectors of the mainboard (also refer to your mainboard’s manual for further information). VaYa EconomY...
-
Page 10: Mounting A Power Supply
1. Set up the case in front of you and put the PSU against the PSU bracket on the case’s rear side from the inside (fig. 5). fig. 5 2. Attach the PSU to the case from the outside using the included screws for PSU mounting (fig. 6). (Screws for PSU mounting) fig. 6 VaYa EconomY... -
Page 11: Mounting A Hard Disk Drive
9 Note: If you want to transport the case we recommend securing (additionally) the installed drives using the respective mounting screws: (Screws for HDD mounting) fig. 10 5. Connect the HDD to the PSU and the mainboard. VaYa EconomY... -
Page 12: Mounting An Optical Drive
(In case there is a metal bezel covering the mounting bay, remove it by using a gripper.) 3. Slide the optical drive into the mounting bay from the front until the drive is flush with the front panel (fig. 13). fig. 13 VaYa EconomY... -
Page 13: Vaya Economy
If you want to transport the case we recommend securing (additionally) the installed drives using the respective mounting screws (fig. 15). (Screws for drive mounting) fig. 15 5. Connect the optical drive to the PSU and the mainboard. (Replace the side panels to the case.) VaYa EconomY... -
Page 14: Mounting A 3.5" Device
3. Attach the installed device to the case from both sides using the included mounting screws (fig. 18). (Scews for drive mounting) fig. 18 4. Connect the 3.5" device as described in its user documentation. (Replace the side panels to the case.) VaYa EconomY... -
Page 15: Mounting An Add-On Card
Legal disclaimer: As a continuing policy of product improvement at SHARKOON, the design and specifications are subject to change without prior notice. National product specifications may vary. All rights reserved especially (also in extracts) for translation, reprinting, reproduction by copying or other technical means.
