Summary of Contents for Sharkoon Bandit
-
Page 2: Table Of Contents
3. Package contents Have a good time with our product! SHaRKOOn technologies • ATX-case “Bandit” (1x 120mm LED fan in the case front, 1x 180mm LED fan in the top panel and card reader pre-installed) • Accessory kit: Stand-offs for... -
Page 3: The Case At A Glance
180mm LED fan Note: If you are missing any of the items listed above, please contact customer service via e-mail at support@sharkoon.com or call + 49 (0) 6403 – 775 6100. 4. the case at a glance Front view Side view (closed/left) A –... - Page 4 – AC’97 C – Connectors for (f.l.t.r): Power Switch Reset Switch Power LED + HDD LED Power LED – D – USB connector of the USB front hub E – eSATA connector F – 3-pin and 4-pin fan connector bandit...
-
Page 5: Installation Of A Mainboard
The mainboard contains special screw openings (fig. 2). (Screws for mainboard mounting) fig. 2 Place the mainboard to the mounting panel. A stand-off must be screwed fig. 4 into every drilling of the mounting panel visible through the mainboard’s screw openings. bandit... -
Page 6: Installation Of A Psu
PSU bracket on the case’s back side (fig. 5). fig. 7 3. Remove the case’s front panel by gently dragging it towards you (fig. 8). fig. 5 2. Screw the PSU to the case from the outside (fig. 6). (Screws for PSU mounting) fig. 8 fig. 6 bandit... - Page 7 10 6. Slide the HDD into a mounting bay of the HDD cage and fixate it from both sides (fig. 11). (Screws for HDD mounting) fig. 13 8. Connect the HDD to the power supply and the mainboard. bandit...
-
Page 8: Installation Of An Optical Device
(Screws for 5.25" drive mounting) (Carefully take out an optionally present metal bezel covering the 3.5" drive bay by using a gripper.) 5. Connect the optical drive to the power supply and the mainboard. (Put the front bezel back onto the case.) bandit... -
Page 9: Installation Of An Additional 3.5" Device
20 fig. 21 (Carefully take out an optionally present metal bezel covering the drive bay by using a gripper.) fig. 23 fig. 24 Note: If you intend to transport the case we recommend securing (additionally) the installed drives. bandit... -
Page 10: Installation Of An Add-On Card
1. Place the fan against the respective bracket from the inside (e.g. the back side / fig. 27). fig. 25 2. Insert the add-on card into the mainboard’s respective slot and screw it to the case (fig. 26). (Screw with coarse thread) fig. 27 bandit... -
Page 11: The Docking Station For Sata Hdds In The Case's Top Panel
While installing fans make sure that (cool) air is taken in on the case’s front side/bottom and blown out on its back side/top. The PC components with the highest heat development should be placed directly within the airflow. fig. 30 fig. 31 bandit... - Page 12 As a continuing policy of product improvement at SHARKOON, the design and specifications are subject to change without prior notice. National specifications may vary. All rights reserved especially (also in extracts) for translation, reprinting, repro- duction by copying or other technical means. Infringements will lead to com- pensation.
