- Page 2 Let the colors flow: The RGB FLOW from Sharkoon presents itself as an elegant yet unobtrusive ATX midi tower with its tempered glass side panel and black chassis with clear lines. The minimalistic design is intersected by a stream of colors which flows through two integrated LED strips from the front panel to the side of the case, providing the built-in hardware with an atmospheric highlight.
- Page 3 WINDOW WITH RGB HIGHLIGHT The RGB FLOW has a side panel made of tempered glass, behind which the installed hardware is displayed. The side panel is without obvious fastening and is attached only to the back of the case with easily removable thumb screws.
-
Page 4: Manual Color Control
Pin Header MANUAL COLOR CONTROL The RGB FLOW also has a manual color control function for mainboards which do not have headers for addressable LED components. With this, the RGB controller is not connected to the mainboard, but rather connected to the power supply and the reset switch of the PC case. The switch’s reset function is then replaced with a new function which allows up to fourteen lighting modes to be cycled through and selected, or, if desired, the lighting can be turned off. - Page 5 Sharkoon products marked with the "ADDRESSABLE RGB" logo are compatible with mainboards which have headers for addressable RGB LED fans and strips. The headers should have the pin configuration 5V-D-coded-G or 5V-D-G.
- Page 6 COMPACT DESIGN WITH POWER SUPPLY TUNNEL 42.4 cm The RGB FLOW has a compact design that can cut a fine figure anywhere, without having to make compromises in terms of compatibility. 16.5 cm Max. Length Graphics Card: 35 cm Removable Dust Filters...
- Page 7 Despite the compact design, the RGB FLOW also has room for radiators (incl. fans): 6.4 cm is provided for this behind the front panel and 5.5 cm under the top panel.
- Page 8 ADAPTABLE HDD/SSD CAGE Removable HDD/SSD Cage Decoupled Mounting for Noise Reduction from Vibration If additional space is needed behind the front panel, the HDD/SSD cage can be quickly and easily repositioned using the extra-long thumbscrew slots on the bottom of the case. If the cage is not required, it can also be completely removed, and one 3.5"...
-
Page 9: Specifications
Up to 360 mm (Front Panel) ASRock Polychrome SYNC Up to 280 mm (Top Panel) RGB Pinout: 5V-D-G & 5V-D-coded-G Package Contents: I/O: RGB FLOW USB 3.0 (Top): Accessory Set USB 2.0 (Top): Manual ...
