O W N E R ' S M A N U A L
T O W C A R T
M OD E L :
H DC- 1 0 L B H
H DC- 1 6 L B H
Assembly
Installation
Operation
Repair Parts
For use with Riders
and Lawn/Garden Tractors
For the latest product updates and setup tips:
Visit us on the web!
www.brinly.com
HDC-16L Shown
Important: This manual contains information for the safety of
persons and property. Read it carefully before assembly and
operation of the equipment!
L-1783-BH-01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Brinly HDC-10L BH
Summary of Contents for Brinly HDC-10L BH
- Page 1 O W N E R ' S M A N U A L T O W C A R T M OD E L : H DC- 1 0 L B H H DC- 1 6 L B H Assembly Installation Operation Repair Parts...
-
Page 2: Table Of Contents
CONGRATULATIONS on your new Brinly-Hardy Cart! Your Cart has been designed, engineered and manufactured to Keep the vehicle and attachment in good operating give you the best possible dependablility and performance. condition and keep safety devices in place. Should you experience any problem you can not easily... -
Page 3: Hardware
HARDWARE REFERENCE Tools Required for Assembly: * Set of open-end wrenches (1) * Pliers * Flat Head Screwdriver * 3/16" Allen Wrench(1) * Adjustable Wrench (1) L-1764-BH-01... -
Page 4: Parts Reference
Parts Reference Parts List REF. PART NO. QTY. PART NO. QTY. DESCRIPTION HDC-10L HDC-16L Hex Lock Nut, 3/8" B-1675P B-1675P B-3034-10 B-3034-10 Clevis B-5363-10 B-5444-10 End Panel, F/R B-3301-10 B-3301-10 Lock Bar (Handle) B-3303 B-3303 Handle Spring B-3305 B-3305 Handle Spacer Gate Lock Bracket B-5455-01 B-5455-01... -
Page 5: Exploded Reference
EXPLODED REFERENCE L-1783-BH-01... - Page 6 Step 1. NOTE: HDC-16L Shown thoughout manual. Hex Bolt, 5/16" x 1/2" Qty. 3 Hex Nut Qty. 3 Step 2. Flat Head Screw, 5/16" x 3/4" Qty. 10 Hex Lock Nut Qty. 10 Special Washer Qty. 10 L-1783-BH-01...
- Page 7 Step 3. Flat Head Screw, 5/16" x 3/4" Qty. 8 Hex Lock Nut Qty. 8 5/8" Flat Washer Qty. 8 Step 4. Round Head Screw, 5/16" x 1" Qty. 2 Round Head Screw, 5/16" x 1/2" Qty. 6 5/16", Lock Washer Hex Lock Nut Qty.
- Page 8 Step 5. Step 6. Machine Bushing Qty. 4 E-Ring Qty. 2 L-1783-BH-01...
- Page 9 Step 7. Hex Head Bolt, 3/8" x 3-1/2" Qty. 1 Hex Lock Nut, 3/8" Qty. 1 Handle Spacer Qty. 2 Step 8. Truss Head Screw, 5/16" x 3/4" Qty. 2 Hex Lock Nut Qty. 2 Hairpin Cotter, 1/8" Qty. 1 Drawbar pin, 1/2"...
-
Page 10: Maintenance
Step 9. Round Head Screw, 1/4" x 1/2" Qty. 4 Hex Lock Nut Qty. 4 Hex Lock Nut Gate Lock Retainer Qty. 2 Qty. 1 MAINTENANCE SAFETY TIPS: The key to years of trouble-free service is to keep your Avoid tipping and skidding. Cart clean and dry. -
Page 11: Warranty
L imi te d Wa rr ant y Br in l y- H ar dy C omp a n y wa r r an ts on ly t o the o r igin al r et ail pur chas e r t h a t th i s p r od u c t w i l l r e m a i n fr e e of de f e ct s i n w or k m an sh ip an d m a te r ials un de r n or ma l u se an d s er vi ce f or a p e ri o d o f t wo ( 2 ) y e ar s ( NO TE : n i n et y ( 9 0 ) d a y s f or com m e rc i al or r en ta l u se ) co mme nc ing wit h the d a te of pur chase .
