OWNER'S MANUAL
P U S H S P I K E A E R A T O R
MODEL:
P S A - 1 8 B H
P S A - 1 8 B H - A
• Assembly
• Installation
• Operation
• Repair Parts
Visit us on the web!
www.brinly.com
English Manual
Call Customer Service, Toll-Free: 877-728-8224
Important: This manual contains information for the safety
of persons and property. Read it carefully before
assembly and operation of the equipment!
1
English, Spanish &
French Manual
1020202-B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSA-18BH and is the answer not in the manual?

Questions and answers

Related Manuals for Brinly PSA-18BH

Summary of Contents for Brinly PSA-18BH

  • Page 1 • Operation • Repair Parts Call Customer Service, Toll-Free: 877-728-8224 Important: This manual contains information for the safety Visit us on the web! of persons and property. Read it carefully before www.brinly.com assembly and operation of the equipment! English Manual 1020202-B...

  • Page 2: Table Of Contents

    INTRODUCTION ================================================================================================== CONGRATULATIONS on your new Brinly-Hardy purchase! This accessory has been designed, engineered and manufactured to give you the best possible dependability and performance. Should you experience any problem you cannot easily remedy, please do not hesitate to contact our knowledgeable customer service department toll-free at 1-877-728-8224.

  • Page 3: Safety

    SAFETY ================================================================================================== SAFE OPERATION CAUTION • Tines have SHARP points. This symbol will help point out important safety precautions Wear gloves and handle with care. used throughout this manual. It means: ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED. • Do not stand on the aerator. •...

  • Page 4: Parts

    1020200 Hardware Bag ** 1020363 Bearing Bag ** ** Contents on pg 5 Installation Questions? DON’T GO BACK TO THE STORE! STOP Missing Parts? Please call our Customer Service Department, Replacement Parts? Toll Free: 877-728-8224 or customerservice@brinly.com English Manual 1020202-B...
  • Page 5 PARTS ================================================================================================== DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS. Illustrations on this page Please Call: 1 (877) 728-8224 are to scale for faster identification of hardware during assembly. Bolt; Hex Head, M6 x 1.00 x 30 (x4) ....... . M06H10030P05 Bolt;...

  • Page 6: Assembly

    The hardware packs are individually bagged and labeled to pair with each assembly step. Additional info and videos are available on our website: brinly.com This QR code links directly to the product page: Step 1 Align the side plates (1) & (2) with the tray (3) as illustrated.
  • Page 7 ASSEMBLY ================================================================================================== CAUTION: Gloves are required while handling aerator tines. Tines have extremely sharp points. Use caution when handling. Step 2-A Slide axle (4) through the first side Add five sets of the bearings (23) and tines (5) plate (1). See illustration below. on the axle (4) in the orientation shown: NOTE: The Bearings (23) have two small openings and extensions.
  • Page 8 ASSEMBLY ================================================================================================== NOTE: view from above: There are 3 different tubes on this Step 3 assembly. Please be sure to add Align the lower handle tubes (6) the correct as illustrated and attach to the tubes on Steps 3-5. side plates (1 & 2) using: - x4 M8 x 1.25 x 50 Hex Head Bolts (15) - x6 M8 Nylon Locknuts (18)
  • Page 9 ASSEMBLY ================================================================================================== Tools: M10 Wrench (x2) Step 4-B Step 5 Tools: M10 Wrench (x2) Bolt upper handle Bolt middle handle tubes (8) to the middle tubes (7) together using: handle tubes (7) using: - x1 M6 x 1.00 x 50, - x2 M6 x 1.00 x 55, Hex Head Bolt (13) Hex Head Bolts (24)

  • Page 10: Use And Care

    USE AND CARE ================================================================================================== MODEL: P S A - 1 8 B H P S A - 1 8 B H - A U S E & C A R E S E C T I O N SPECIFICATIONS WHEN TO USE Your Aerator-Spreader should not be used when lawn conditions are too wet or too dry.

  • Page 11: Maintenance

    Aerator tray, that is the maximum In North America and Canada call 35 lbs weight capacity. Toll-Free: 877-728-8224 • Weight can be added to the tray Chat online: www.brinly.com and should be secured by rope, straps, or other suitable means. Email: customerservice@brinly.com ONLINE...

  • Page 12: Warranty

    MANUFACTURER’S LIMITED WARRANTY AERATORS The limited warranty set forth below is given by Brinly-Hardy Company with respect to new merchandise purchased and used in the United States (its possessions and territories) and Canada. Brinly-Hardy Company warrants the products listed below against to use this product.
