OWNER'S MANUAL

4 2 "

P L U G A E R A T O R

MODEL:

PA - 4 2 B H

PA - 4 2 B H - A

• Assembly

• Installation

• Operation

• Repair Parts

Visit us on the web!

www.brinly.com

English Manual

Call Customer Service, Toll-Free: 877-728-8224

Important: This manual contains information for the safety

of persons and property. Read it carefully before

assembly and operation of the equipment!

English, Spanish &

French Manual

For use with Riders

and Lawn/Garden Tractors

1020142-A

Table of Contents

Need help?

Do you have a question about the PA-42BH and is the answer not in the manual?

Questions and answers

Summary of Contents for Brinly PA-42BH

Page 1 For use with Riders and Lawn/Garden Tractors Call Customer Service, Toll-Free: 877-728-8224 Important: This manual contains information for the safety Visit us on the web! of persons and property. Read it carefully before www.brinly.com assembly and operation of the equipment! English Manual 1020142-A...
Page 2: Table Of Contents
INTRODUCTION ================================================================================================ CONGRATULATIONS on your new Brinly-Hardy purchase! This accessory has been designed, engineered and manufactured to give you the best possible dependability and performance. Should you experience any problem you cannot easily remedy, please do not hesitate to contact our knowledgeable customer service department toll-free at 1-877-728-8224.
Page 3: Safety
SAFETY ================================================================================================ GENERAL NOTES (Operation) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Caution should be taken when towing and/or using any attachment.
Page 4: Specifications
SPECIFICATIONS ================================================================================================ • Follow the tow vehicle manufacture’s recommendations for weight limits for towed equipment and towing on slopes. Use counterweights or wheel weights as described in the towing vehicle operator’s manual. • Do not shift to neutral and coast downhill. •...
Page 5: Hardware Identifier
HARDWARE IDENTIFIER ================================================================================================ DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS. Illustrations on this page Please Call: 1 (877) 728-8224 are to scale for faster identification of hardware during assembly. Bolt: Hex Head, 5/16 x 3/4” (x37)....2M1012P Bolt: Hex Head, 5/16 x 1”...
Page 6 PART EXPLOSION ================================================================================================ PA-42BH & PA-42BH-A SPOON ASSEMBLY English Manual 1020142-A...
Page 7: Parts List
Bearing Bag - x2 Bushing, 0.765 ID x 0.250 (26) B-4866 Bearing, Nyliner-3/4” Installation Questions? DON’T GO BACK TO THE STORE! STOP Missing Parts? Please call our Customer Service Department, Replacement Parts? Toll Free: 877-728-8224 or customerservice@brinly.com English Manual 1020142-A...
Page 8: Assembly
Please contact our Customer Service department: Call, Toll-Free: 877-728-8224 Chat online: brinly.com Email: customerservice@brinly.com Additional info and videos are available on our website: brinly.com Step 1-A Align the Side Plates (2) with theTray (1) as illustrated here.
Page 9 Start to add Nylon Lock Nuts (15) to the end of each hex bolt, however, DO NOT tighten fully (yet). IMPORTANT: Side of the tray (1) with our Brinly logo faces out, away from the Step 2 extended tow bar arms (6).
Page 10 ASSEMBLY ================================================================================================ Step 3 A. Align the clevis (32) to the B. Next, secure the tow bars (6) as shown. tow bars (6) in place with: Hold in place with: - x1 Hex Head Bolt - x2 Carriage Bolts 5/16” x 1.25” (19) 5/16”...
Page 11 ASSEMBLY ================================================================================================ IMPORTANT: Rounded part of spoon fits against the tube to lock in place. Step 5 Find this hardware: - x24 Hex Head Bolts (13) - 5/16 x 0.75” - x24 Lock Nuts (14) - 5/16” Align Plugging Spoons (12) to each welded plate (side opposite welds) of all the Tube Assemblies (8 and 9) as shown.
Page 12 ASSEMBLY ================================================================================================ Step 6 START WITH: Add a Machinery Bushing to the Axle. Insert the Axle Assembly (10) through the right side plate as illustrated above. TIP: SPOTTING CONTINUE ADDING TO THE AXLE IN THE FOLLOWING ORDER: THE DIFFERENCES BETWEEN TUBES End Tube Assembly - Face short end toward the side plate (2).
Page 13 ASSEMBLY ================================================================================================ Step 7 FLIP THE AERATOR OVER: A. Push the Axle Assembly (10) through the left side plate NOTE: Make sure the Axle Assembly Flat as far as possible and rotate so the hole in the flat plate Plate (10) and Lift Handle Weldment (3) faces to the rear as shown.
Page 14 ASSEMBLY ================================================================================================ Step 8 Combine: - x1 Hex Bolt (21) - 5/8” x 4” - x1 Flat Washer (24) - 5/8” Slide the bolt assembly through one wheel (11) (wheel hub pointing toward the threads of the bolt) and add: - x1 Flat Washer (24) - 5/8”...
Page 15: Operation, Maintenance And Service
ASSEMBLY ================================================================================================ Step 10 Adjustment Bolts Adjustment Bolts Adjust this NOTE: Surface to Level The adjustment is made with the aerator attached to the rider or lawn/garden tractor with the wheels in transport position. To Tractor LEVELING The final step is to level Tray (1) using adjustment bolts as shown here and installed in Step 1-B.
Page 16 Your Aerator should NOT be used when lawn conditions are too wet or too dry. (OR scan the QR codes below) TO DETERMINE LAWN CONDITION: PA-42BH PA-42BH-A Dig a small amount of your soil (about three inches deep). Roll it into a small ball in the palm of your hand.
Page 17 USE AND CARE ================================================================================================ OPERATION MOUNTING AND TRANSPORTING CAUTION : - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
Page 18 - Diameter: 1/2” 2. In North America and Canada, call - Pin Length: 3” 1-877-728-8224 and provide product serial number and model number. NOTE: Additional accesories are also available in our Parts Store online: shop.brinly.com English Manual 1020142-A...
Page 19: Limited Warranty
MANUFACTURER’S LIMITED WARRANTY AERATORS The limited warranty set forth below is given by Brinly-Hardy Company with respect to new merchandise purchased and used in the United States (its possessions and territories) and Canada. Brinly-Hardy Company warrants the products listed below against to use this product.

This manual is also suitable for:

Pa-42bh-a
