CCTV | AutoDome 800 Series HD PTZ Camera System
AutoDome 800 Series HD PTZ Camera
System
The AutoDome 800 Series is an easy to install, outdoor
PTZ camera system with superb HDTV 1080p30 quality
video. The camera features day/night functionality for high
definition quality images in low light conditions. This
discrete, high-speed dome camera has an IP66 rating
ensuring reliable uncompromised functionality even in
dusty and potentially wet environments.
The AutoDome 800 Series provides direct network
connection using H.264 and JPEG compression and
bandwidth throttling to efficiently manage bandwidth and
storage requirements while delivering outstanding image
quality. The AutoDome 800 Series provides complete
network-based control of all dome functionality including
pan/tilt/zoom operation, presets, tours and alarms as well
as web-based configuration of all dome settings.
The AutoDome 800 Series conforms to the ONVIF (Open
Network Video Interface Forum) specification
guaranteeing interoperability between network video
products regardless of manufacturer.
AutoDome 800 Series highlights
The AutoDome 800 Series delivers state-of-the-art
technology and features that far exceed other PTZ
cameras. The camera streams high-definition video with
20x optical zoom in a field-proven outdoor housing.
▶ HD 1080p resolution at 30 images per second (ips)
▶ 200x zoom (20x optical, 10x digital)
▶ Quad video streaming generates simultaneous
H.264, M-JPEG, and JPEG video streams
▶ ONVIF conformant; provides interoperability with
other conformant systems
▶ Embedded Intelligent Video Analytics (IVA) for
reliable detection, tracking, analysis, and search
capabilities
▶ High-impact, heavy-duty, tamper resistant aluminum
housing with the protection of a rugged acrylic
bubble
▶ High-speed 360-degree continuous pan
▶ Preset tour and AutoPan modes
720p resolution at 60 images per second provides
smooth, detailed video of fast moving objects. 1080p
resolution at 30 images per second delivers six times the
detail level of standard definition cameras, ensuring crisp
video even when zooming in digitally to extend the
camera's range. In addition, the 16:9 aspect ratio
increases situational awareness by maximizing the field of
view without compromising image clarity.
Its variable pan and tilt speeds and AutoPivot ensure
optimal camera control and viewing at all zoom levels. The
high-performance 200x (20x optical/10x digital) zoom
autofocus camera incorporates the latest digital imaging
technology with excellent sensitivity and resolution. With
99 user-defined presets as well as tour and AutoPan
modes, The AutoDome 800 Series is not small on features.
The AutoDome 800 Series maximizes your security
investment by integrating with Bosch video products
including the Bosch Video Client and the Bosch Recording
Station, as well as the full range of Bosch video over IP
products.
And, the AutoDome 800 Series is simple to install and use;
available with wall, corner, mast, and pipe mount options.
www.boschsecurity.com
