    AUTODOME 5000 PTZ Camera Installation Guide...

  • Page 3: Table Of Contents

    AUTODOME 5000 PTZ Camera Table of Contents | en Table of contents Safety About this Manual Conventions in this Manual Legal Information Important Safety Instructions Description Unpacking Installing a Recessed Mount Parts List Installing the Recessed Mount Installing a Pipe Mount...

  • Page 4: Safety

    Legal Information Copyright This manual is the intellectual property of Bosch Security Systems, Inc. and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.

  • Page 5

    AUTODOME 5000 PTZ Camera Safety | en – Only use accessories that have been recommended by the manufacturer or are delivered with the device. – Fit the device according to the manufacturer's instructions. – Exercise extreme caution when transporting the device on a trolley. Abrupt stopping, extreme force effects and uneven surfaces may cause the device and the trolley to tip over.

  • Page 6: Description

    VEZ-A5-IC In-ceiling (Recessed) Mount. This mount allows you to recess the AUTODOME 5000 into an indoor drop-ceiling. This manual provides instructions for mounting a AUTODOME 5000 PTZ Dome to the VEZ-A5- PP Pipe Mount. This mount allows you to mount the AUTODOME 5000 to an indoor or to an outdoor high ceiling.

  • Page 7: Installing A Recessed Mount

    AUTODOME 5000 PTZ Camera Installing a Recessed Mount | en Installing a Recessed Mount Use this chapter to install the indoor dome camera into an indoor ceiling space. Parts List Quantity Item Ceiling Bracket Rubber Gasket Housing Frame Trim Ring...

  • Page 8: Installing The Recessed Mount

    | Installing a Recessed Mount AUTODOME 5000 PTZ Camera Installing the Recessed Mount The illustration below shows the required parts for the recessed mount. Refer to the steps that follow for instructions. Ceiling Bracket Housing Frame M4x10 Screws (3 pieces)

  • Page 9

    AUTODOME 5000 PTZ Camera Installing a Recessed Mount | en Recessed Mount Installation Instructions Find a secure location on the ceiling and apply the ceiling guide pattern the ceiling tile or drywall. Use the pattern as a template to cut the proper circle in the ceiling.

  • Page 10: Installing A Pipe Mount

    | Installing a Pipe Mount AUTODOME 5000 PTZ Camera Installing a Pipe Mount Use this chapter to install and indoor or outdoor dome camera to a pipe. Parts List Quantity Item Pipe Mount Base with Safety Tether 300 mm (11.81 in.) Pipe Extension 200 mm (7.87 in.) Pipe Extension...

  • Page 11: Installing The Pipe Mount

    AUTODOME 5000 PTZ Camera Installing a Pipe Mount | en Installing the Pipe Mount The illustration below shows the required parts for the pipe mount. Refer to the steps that follow for instructions. Pipe Mount Base M38 to M33 Pipe Connector...

  • Page 12

    | Installing a Pipe Mount AUTODOME 5000 PTZ Camera Pipe Mount Installation Instructions Caution! Strength of Mounting Surface The fasteners and mounting surface must be capable of supporting a maximum load of 12 kg (26.4 pounds). Locate a secure position to secure the Pipe Mount Base (1). Ensure there is an adequate opening in the ceiling or mounting structure for the wires to pass through.

  • Page 13

    AUTODOME 5000 PTZ Camera Installing a Pipe Mount | en 14. Place the top of the Dome Camera (9) inside the Adaptor (8) and turn clockwise until the Dome Camera latches to the Adaptor. 15. Fasten the M5x8L screw using the T20 Security Torx wrench (shipped with the camera) to secure the Dome Camera to the Adaptor.

  • Page 14: Installing A Wall Mount

    | Installing a Wall Mount AUTODOME 5000 PTZ Camera Installing a Wall Mount Use this chapter to install and indoor or outdoor dome camera to a wall. Parts List Quantity Item Wall Mount with Safety Tether 3/4 x 260 in. Roll Teflon Tape...

  • Page 15: Installing The Wall Mount

    AUTODOME 5000 PTZ Camera Installing a Wall Mount | en Installing the Wall Mount The illustration below shows the required parts for the wall mount. Refer to the steps that follow for instructions. Wall Mount Base Safety Tether Washers (4 pieces)

  • Page 16

    | Installing a Wall Mount AUTODOME 5000 PTZ Camera Wall Mount Installation Instructions Caution! Strength of Mounting Surface The fasteners and mounting surface must be capable of supporting a maximum load of 12 kg (26.4 pounds). Locate a secure position to secure the Wall Mount Base (1). Ensure there is an adequate opening in the wall for the wires to pass through.

  • Page 17: Replacing The Bubble

    AUTODOME 5000 PTZ Camera Replacing the Bubble | en Replacing the Bubble This section provides instructions for replacing a bubble on an AUTODOME 5000 camera. Parts List Quantity Item Tinted Bubble with Trim Ring (with two (2) M3x23L Torx screws attached)

  • Page 18: Installing The Replacement Bubble

    | Replacing the Bubble AUTODOME 5000 PTZ Camera Installing the Replacement Bubble Use the illustration below as a guide for replacing the bubble. Safety Tab with M3x5 Screw Bubble Assembly M3x23L Screw (2 pieces) 2013.07 | 1.3 | Installation Guide...

  • Page 19

    AUTODOME 5000 PTZ Camera Replacing the Bubble | en Bubble Replacement Instructions Loosen the two M3x23L screws (3) from the bubble on the camera. Detach the Bubble Assembly (2) from the camera. Remove the screw that secures the Safety Tether to the Bubble. Keep the screw to secure the bubble replacement.

  • Page 20: Technical Data

    | Technical data AUTODOME 5000 PTZ Camera Technical data Camera Dimensions (7.36) (in.) (8.19) Figure 7.1: AUTODOME 5000 Indoor/Outdoor Dimensions 1 Diameter without sunshield (indoor models) 2 Diameter with sunshield (outdoor models) 2013.07 | 1.3 | Installation Guide Bosch Security Systems, Inc.

  • Page 22
