Quantum 3U Quick Start Manual page 8

LTO-5 Full-Height Tape Drive
Figure 8 Installing the New
Tape Drive
Figure 9 Connecting the SAS
and Power Cables
8
7 Secure the tape drive tray by tightening the thumbscrew.
Continue with Connecting the Tape Drive Cables
Connecting the Tape Drive Cables
To connect the tape drive cables:
1 Connect the following cables to the back of the tape drive (see
a Connect the SAS cable to the tape drive SAS connector.
b Connect a power cable to the SAS cable.
on page 8.
Power cable
SAS cable
Installing a Second Tape Drive or Replacing a Tape Drive
Figure 9).
