Summary of Contents for Seagate ST15230N

  • Page 1 ............ST15230N/ND .
  • Page 3 ............ST15230N/ND .
  • Page 4 Inc. Other product names are registered trademarks or trademarks of their owners. Seagate reserves the right to change, without notice, product offerings or specifications. No part of this publication may be reproduced in any form without written permission of Seagate Technology, Inc.
  • Page 5 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ Revision status summary sheet Revision Authority Date Writer/Eng. Sheets Affected A Issue 09/01/94 D. Ashby v thru viii, 1 thru 60. Brent Douglas PLD: 87088 11/02/94 D. Ashby v, 12, 13, 38 - 40 Brent Douglas PLD: 87187...
  • Page 6: Table Of Contents

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ Table of contents Scope ............................1 Applicable standards and reference documentation .............. 2 Standards ........................2 Electromagnetic Compliance for the European Union ............. 2 Applicable reference documents ..................2 General description ........................
  • Page 7 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ Table of contents Physical/electrical specifications ..................... 18 AC power requirements ....................18 DC power requirements ....................18 7.2.1 Conducted noise immunity ................. 19 7.2.2 Power sequencing ....................19 7.2.3 12 V - current profile ...................
  • Page 8 viii Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ Table of contents 12.0 Options ............................56 12.1 Front panel ........................56 12.2 Single unit shipping pack ....................56 12.3 Installation Guide ......................56 13.0 Accessories ..........................57 13.1 Front panel kit .........................
  • Page 9: Scope

    This specification describes the Seagate Technology, Inc. Hawk 4 Family Disc Drive. This high capacity, high performance member of the Seagate 3.5 inch rigid disc family is a companion product to the ST12400 drive family. It has an embedded SCSI controller. Performance information is given in Section 5. The Hawk 4 Family interface is defined for functional compatibility to a subset of the Seagate SCSI Interface Specification 77738479, and the ANSI SCSI-2 and SCSI-3 standards.
  • Page 10: Applicable Standards And Reference Documentation

    Standards The Hawk 4 Family complies with Seagate standards as noted in the appropriate sections of this specification and the Seagate SCSI Interface Specification, P/N 77738479 (Vol.2, Version 2). The Hawk 4 Family is a UL Recognized component per UL 1950 and a CSA Certified component per CAN/ CSA-C22.2 No.
  • Page 11: General Description

    Hawk 4 Family of drives, and the SCSI Interface Product Manual P/N 77738479 (Vol. 2, Version 2) which describes the general interface characteristics of this and other families of Seagate 3.5-inch drives. The drive interface supports multiple initiators, disconnect/reconnect, self configuring host software and au- tomatic features that relieve the host from the necessity of knowing the physical characteristics of the targets (logical block addressing is used).
  • Page 12 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Figure 3.0-1. Hawk 4 family drive...
  • Page 13: Standards Features

    • Vertical, horizontal, or top down mounting • Dynamic spindle brake • 512 K byte data buffer • Permanently mounted terminators (for model ST15230N only), enabled by installation of a jumper plug. Performance • Programmable multi-segmentable cache buffer • 5411 r/min Spindle. Average latency = 5.54 ms •...
  • Page 14: Unformatted And Formatted Capacities

    The standard OEM model is as follows: Formatted Data Block Size* Unformatted 512 Byte/Sector ST15230N/ND 4294 MB 5170 MB *Twelve spare sectors per cylinder (all twelve spare sectors are on one track), two spare cylinders/unit. Drives are shipped with an Installation Guide P/N 77767474 unless otherwise specified.
  • Page 15: Installation

    • If the drive is the only device on the bus, attach it to the end of the SCSI bus cable. Permanently installed terminators must be enabled on the drive for ST15230N models using a jumper plug (see Figure 10.1-1), For the ST15230ND model, terminators must be installed external to the drive.
  • Page 16: Performance Characteristics

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Performance characteristics Internal drive characteristics (transparent to user) Drive Capacity 5170 MByte (UNF) Read/Write Heads Bytes/Track 68155 Bytes (UNF, Avg) Bytes/Surface Mbytes (UNF) Tracks/Surface, Total 3992 Tracks (user accessible) Tracks/Inch 4200 Servo Heads...
  • Page 17: Format Drive Command Execution Time

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ 5.2.2 Format drive command execution time (minutes) [1] Maximum (with verify) 70 Min. Maximum (no verify) 45 Min 5.2.3 Read data command execution time [4] (512 byte sector size, without disconnect and with read look ahead cache disabled.) Latency time is included.
  • Page 18: Generalized Performance Characteristics

    Min. [4] 3.64 MByte/sec divided by (Interleave Factor) Avg. [4] 5.16 MByte/sec divided by (Interleave Factor) Max. [4] 6.41 Mbyte/sec divided by (Interleave Factor) SCSI Interface Data Transfer Rate (Asynchronous) [5] ST15230N ST15230ND -Maximum Instantaneous 5.2 MBytes/sec [9]* 3.3 MBytes/sec -Maximum Average 3.1 MBytes/sec [11]...
  • Page 19: Notes For Sections 5.2 And 5.3

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ 5.3.1 Notes for sections 5.2 and 5.3. [1] Execution time measured from receipt of the last Byte of the Command Descriptor Block (CDB) to the request for a Status Byte Transfer to the Initiator (excluding connect/disconnect). [2] Maximum times are specified over the worst case conditions of temperature, voltage margins and drive orientation.
  • Page 20: Start/Stop Time

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Start/stop time After DC power has been applied, the drive becomes ready within 25 seconds if the Motor Start Option is disabled (i.e. the motor starts as soon as the power has been applied). During this time the drive responds to some commands over the SCSI interface* in less than 3 seconds.
  • Page 21: Prefetch Operation

    Product Manual - ST15230 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Case B - A Read command requests data, the first LB of which is not in any segment of the cache: 1. The drive fetches the requested LB’s from the disc and transfers them into a segment, and from there to the host in accordance with the disconnect/reconnect specification referred to in case A.
  • Page 22: Caching Write Data

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Caching write data Write caching is a write operation by the drive that makes use of a drive buffer storage area where the data to be written to the medium is stored in one or more segments while the drive performs the write command. Write caching is enabled along with read caching.
  • Page 23: Reliability Specifications

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Reliability specifications The following reliability specifications assume correct host/drive operational interface, including all interface timings, power supply voltages, and environmental requirements. Seek Errors Less than 1 in 10 seeks Read Error Rates [1] Unrecovered Data...
  • Page 24: Write Errors

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ 6.1.3 Write errors Write errors can occur as a result of media defects, environmental interference, or equipment malfunction. Therefore, write errors are not predictable as a function of the number of bits passed. If an unrecoverable write error occurs because of an equipment malfunction in the drive, the error is classified as a failure affecting MTBF.
  • Page 25: Service Philosophy

    6.2.7 Product Warranty Beginning on the date of shipment to customer and continuing for a period of 5 years, Seagate warrants that each product (including components and subassemblies) or spare part that fails to function properly under normal use due to defect in materials on workmanship or due to non conformance to the applicable specifica- tions will be repaired or replaced, at Seagate’s option and at no charge to customer, if returned by customer...
  • Page 26: Physical/Electrical Specifications

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Physical/electrical specifications AC power requirements: None DC Power requirements The voltage and current requirements for a single drive are shown in the following table. Values indicated apply at the drive power connector. Table 7.2-1.
  • Page 27: Conducted Noise Immunity

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _______________________________________________________________________________________ 7.2.1 Conducted noise immunity Noise is specified as a periodic and random distribution of frequencies covering a band from DC to 10 mHz. Maximum allowed noise values given below are peak to peak measurements and apply at the drive power connector.
  • Page 28: Heat/Power Dissipation

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Note. All times and currents are typical. See Table 7.2-1 for maximum current requirements. Power Save Cut-in Current (amps) CH1 GND Current (amps) Channel 1 2 s .5 Amps Channel 2 2 s .5 Amps CH2 GND...
  • Page 29: Temperature

    Non-Operating -40° to 158°F (-40° to 70°C) package ambient with a maximum gradient of 45°F (25°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with the drive.
  • Page 30 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ Model ST15230ND Model ST15230N Differential I/O PCB Single Ended I/O PCB U2Ø U2Ø U1Ø U1Ø Bottom side of PCB. Figure 7.4.1-1. Locations of components listed in Table 7.4.1-1...
  • Page 31: Relative Humidity

    Disc drives shipped as loose load (not palletized) general freight will be packaged to withstand drops from heights as defined in the table below. For additional package requirements refer to Seagate speci- fications 30190-001 (under 100 lbs) or 30191-001 (over 100 lbs).
  • Page 32 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Figure 7.4.4-1. Recommended mounting...
  • Page 33: Air Cleanliness

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ 7.4.4.2 Vibration a. Operating The drive, as installed for normal operation, shall operate error free while subjected to continuous vibra- tion not exceeding 5-22 Hz @ 0.02 inches (0.51 mm) displacement 22-400 Hz @ 0.5 g Vibration may be applied in the X, Y, or Z axis.
  • Page 34: Mechanical Specifications

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Mechanical specifications The following nominal dimensions are exclusive of the decorative front panel accessory. Refer to Figure 7.6- 1 for detailed mounting configuration dimensions. See section 7.6.3, Drive mounting. Height: 1.62 in 41.1...
  • Page 35: Drive Orientation

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ 7.6.1 Drive Orientation The balanced rotary arm actuator design of the drive allows it to be mounted in any orientation. All drive performance characterization, however, has been done with the drive in horizontal (discs level) and vertical (drive on its side) orientations, and these are the two preferred mounting orientations.
  • Page 36: Media Characteristics

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Media characteristics Media description The media used on the drive has a diameter of approximately 95 mm (approximately 3.7 inches). The alumi- num substrate is coated with a thin film magnetic material, overcoated with a proprietary protective layer for improved durability and environmental protection.
  • Page 37: Defect And Error Management

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ Defect and error management The drive, as delivered, complies with this specification. The read error rate and specified storage capacity are not dependent upon use of defect management routines by the host (initiator). Defect and error management in the SCSI system involves the drive internal defect/error management and SCSI systems error considerations (errors in communications between Initiator and the drive).
  • Page 38: Option/Configuration Headers

    Reserved Term. Power to SCSI Bus Remote Term. Power from SCSI Bus Shipped with cover installed. Position A Do not remove. Do not install jumpers CATH on these four positions. Figure 10.1-1a. ST15230N/ND family drive ID and option select header...
  • Page 39 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ Notes for Figure 10.1-1: [1] Notes explaining the functions of the various jumpers on jumper header connectors J2, J5 and J6 are given below in left to right order of jumper position. The term “default” means as standard OEM units are configured when shipped from factory.
  • Page 40: Grounding

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ continued from previous page TP Position A (Applies to "N" models only) This horizontally positioned jumper across the two TP positions nearest PCB edge, connects terminator power from SCSI bus I/O pin 26 to the drive’s internal terminators (for single-ended I/O only).
  • Page 41: Interface Requirement

    This section partially describes the interface requirements as implemented on the drives. The major portion of the interface requirements/implementation is described in the Seagate SCSI Interface Product Manual, P/N 77738479. This section has tables that give the ST15230 Family drives version of the SCSI implementa- tion described in the 77738479 document.
  • Page 42: Scsi Interface Commands Supported

    SCSI-3 modes of the drive. ST15230 Family drives can be changed back and forth between SCSI-1, SCSI- 2 and SCSI-3 modes using the Change Definition Command. OEM standard drives are shipped set to oper- ate in SCSI-2/SCSI-3 mode. Table 11.3-1. Commands supported by ST15230N/ND family drives Com’d Supported by:...
  • Page 43 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ continued from previous page Com’d Supported by: Code SCSI-1 SCSI-2 Command Name Start unit/stop unit (spindle ceases rotating) Receive diagnostic results Supported diagnostics pages Translate page Send diagnostics page Supported diagnostics pages Translate page Read capacity...
  • Page 44: Inquiry Data

    Eight ASCII digits representing the eight digits of the product serial number. Four ASCII digits representing the firmware distribution diskette serial number. Bytes 18 through 24 will reflect model of drive. Shown here are hex values for ST15230N. Codes for the “ND” model drive add 44.
  • Page 45: Mode Sense Data

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ 11.3.2 Mode Sense data The Mode Sense command provides a means for the drive to report its operating parameters to the initiator. The drive maintains four sets of Mode parameters, Default values, Saved values, Current values and Change- able values.
  • Page 46 Select command. Changeable bits; indicates current and saved values are changeable. Table 11.3.2-1. Mode sense data, ST15230N/ND default values (SCSI-1 implementation) Bytes 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23...
  • Page 47 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ Table 11.3.2-2. Mode sense data, ST15230N/ND default values (SCSI-2 implementation) Bytes 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23...
  • Page 48: Scsi Bus Conditions And Miscellaneous Features Supported

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ 11.4 SCSI Bus Conditions and Miscellaneous Features Supported Asynchronous SCSI bus conditions supported by the drive are listed in Table 11.4-1. These conditions cause the SCSI device to perform certain actions and can alter the phase sequence. Other miscellaneous operating features supported are also listed here.
  • Page 49: Synchronous Data Transfer

    D.C. power connector, the SCSI interface connector, the I/O line terminators, and the drive select and option select header. Details of the physical, electrical and logical characteristics are given in paragraphs following, while the SCSI operational aspects of Seagate drive interfaces are given in the Seagate SCSI Interface Product Manual, P/N 77738479. __________...
  • Page 50 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ Power +12V +12V ret + 5V ret + 5V 3 2 1 DC Power Connector Pin 1 I/O Terminator Module ("N" models only) (not removable) Pin 1 SCSI I/O Connector Pin 1 End Figure 11.6-1.
  • Page 51: Dc Cable And Connector

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ 11.6.1 DC cable and connector The drives receive DC power through a 4 pin connector mounted at the rear of the main PCB (see Figure 11.6-1). Recommended part numbers of the mating connector are listed below, but equivalent parts may be used (see Table 11.6-1).
  • Page 52 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ 11.6.2.1 Physical description The drives may be daisy-chained together or with other compatible SCSI devices using a common cable. Both ends of the cable must be terminated. The model "N" drive implements single ended drivers and receiv- ers.
  • Page 53: Connector Requirements

    100 mils apart. The connector is keyed (see Figure 11.6.3-1). 11.6.3.2 J2 Jumper plug part number Option select header connector J2 on the PCB (see Figure 10.1-1b) uses an unusual type of jumper plug, so its part number is given here for reference: Molex 52747-0211 (Seagate P/N 77670952).
  • Page 54 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ .370 ± .010 (9.398) (15.24) (10.67) (5.08) .065 x 45° chamfer typ (1.65) Pin 1 .037 ref typ (.94) (6.60) .335 ± .010 (8.50) .100 (2.54) +.001 .025 .083 –.002 (.64) Square Contact...
  • Page 55 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ SCSI Device Host Adapter/Initiator * * * 1 thru 8 SCSI Devices Disc Drive or Disc Drive or Disc Drive or Other SCSI Other SCSI Other SCSI Device Device Device View B (T indicates termination required)
  • Page 56 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _______________________________________________________________________________________ Table 11.6.3-1b. Differential cable pin assignments (Nonshielded connector) +Signal Name* Pin Number -Signal Name* SHIELD GND GROUND +DB(0) -DB(0) +DB(1) -DB(1) +DB(2) -DB(2) +DB(3) -DB(3) +DB(4) -DB(4) +DB(5) -DB(5) +DB(6) -DB(6)
  • Page 57: Electrical Description

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ 11.6.4 Electrical description Model "N" uses single ended interface signals. These signals must be terminated with 110 ohm active termi- nation circuits at each end of the total cable. The terminators are enabled (or disabled) by installing (or removing) jumper plug TE.
  • Page 58 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _______________________________________________________________________________________ Line Driver Line Receiver Transmitter Receiver (or transceiver) Flat Cable Pair [1] Part of active terminator circuits. Permanently mounted LSI terminators enabled in the drive ("N" only) when it is first or last in the daisy-chain. See jumper header Figure 10.1-1 for terminator enabling jumper [2] ANSI SCSI compatible circuits [3] Total interface cable length should not exceed that specified in paragraph 11.6.2.2.1.
  • Page 59 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ 11.6.4.2 Differential drivers/receivers Typical differential driver and receiver circuits used by the model "ND" are shown in Figure 11.6.4-2. The drive has no provisions for terminator circuits on differential I/O drives. Differential signals All differential interface signals consist of two lines denoted +SIGNAL and -SIGNAL.
  • Page 60 See section 11.6.4.2 for signal characteristics. I/O Line terminators. If SCSI device is a Seagate disc drive, terminators and a place to plug them in must be provided external to the drive by user, systems integrator or host equipment manufacturer where needed.
  • Page 61 11.6.4.3 Terminator requirements Internal disc drive I/O termination (provided only in single ended I/O model ST15230N drives) consists of active circuits in an LSI module that is permanently mounted on the PCB. All single initiator/single target (nondaisychain) applications require that the Initiator and disc drive be terminated. Daisy-chain applications require that only the units at each end of the daisy-chain be terminated.
  • Page 62: Disc Drive Timing

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ 11.7 Disc drive SCSI timing Table 11.7-1. Disc drive SCSI timing* Waveform Waveform Description Symbol [1] Table [1] Typical Target Select Time (no Arbitration) <1 µs Target Select Time (with Arbitration) 4.5-1,2 2.34 µs Target Select to Command...
  • Page 63 Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F ______________________________________________________________________________________ continued from previous page Waveform Waveform Description Symbol [1] Table [1] Typical Asynchronous Data Transfer Characteristics: (continued) Next CDB Byte Access (Byte 2 of 10) T23.10.2 4.5-4 0.51 µs Next CDB Byte Access (Byte 3 of 10) T23.10.3 4.5-4...
  • Page 64: Options

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ 12.0 Options All options are incorporated or packaged at the manufacturing facility. 12.1 Front panel The normal front panel available is black plastic. Other panel colors may be special ordered. Each panel has a single rectangular green LED indicator lens which, when glowing, indicates the drive is selected.
  • Page 65: Accessories

    Product Manual - Hawk 4 Family SCSI-2 (Volume 1), Rev. F _____________________________________________________________________________________ 13.0 Accessories All accessories are designed for implementation by the customer. 13.1 Front panel kit Same as 12.1 but includes all mounting hardware to support field installation. 13.2 Additional Installation Guide copies This manual (P/N 77767474) is usually included with each drive shipped, but extra copies may be ordered.
  • Page 66: Technical Support Services

    8:00 AM to 5:00 PM PST, Monday through Friday. SeaBoard: The Seagate Technical Support Bulletin Board System (BBS) is available 24 hours a day, 7 days a week. A modem is required to access this service. The communications software must be set for eight data bits, no parity and one stop bit (8N1).
  • Page 68 Seagate Technology, Inc. 920 Disc Drive, Scotts Valley, California 95066-4544, USA Publication Number: 77767472, Revision F Printed in USA...
