Product Manual
Pipeline HD
ST2000VM002
ST1500VM002
100633414
Rev. B
January 2011
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PIPELINE HD ST1500VM002 and is the answer not in the manual?

Questions and answers

Related Manuals for Seagate PIPELINE HD ST1500VM002

Summary of Contents for Seagate PIPELINE HD ST1500VM002

  • Page 1 Product Manual ® Pipeline HD ST2000VM002 ST1500VM002 100633414 Rev. B January 2011...

  • Page 2: Document Revision History

    In addition, some of the listed capacity is used for formatting and other functions, and thus will not be available for data storage. Seagate reserves the right to change, without notice, product offerings or specifications.

  • Page 3: Table Of Contents

    Seagate Technology Support Services ........
  • Page 4 Pipeline HD SATA Product Manual, Rev. B...
  • Page 5 Figure 1 Typical Current Profiles (5V) ..........16 Figure 2 Typical Current Profiles (12V) .
  • Page 6 Pipeline HD SATA Product Manual, Rev. B...

  • Page 7: Seagate Technology Support Services

    • Authorized Service Centers For information regarding Warranty Support, visit http://www.seagate.com/www/en-us/support/warranty_&_returns_assistance For information regarding data recovery services, visit For Seagate OEM and Distribution partner portal, visit For Seagate reseller portal, visit http://spp.seagate.com Pipeline HD SATA Product Manual, Rev. B http://www.seagate.com/www/en-us/about/contact_us/ http://www.i365.com...
  • Page 8 Pipeline HD SATA Product Manual, Rev. B...

  • Page 9: Introduction

    1.0 Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate ® Pipeline HD SATA model drives: ST2000VM002 ST1500VM002 These drives provide the following key features: • 5900 RPM spindle speed • High instantaneous (burst) data-transfer rates with a default of 3Gb/s. Limit settings to 1.5Gb/s are available via S.M.A.R.T.
  • Page 10 Serial ATA devices behave like Device 0 devices. For additional information about how Serial ATA emulates parallel ATA, refer to the “Serial ATA International Organization: Serial ATA Revision 3.0”. The specification can be downloaded from www.sata-io.org. www.seagate.com Pipeline HD SATA Product Manual, Rev. B...

  • Page 11: Drive Specifications

    2.0 Drive Specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate the following drive models: ST2000VM002 ST1500VM002 2.1 Specification summary tables The specifications listed in the following tables are for quick reference.
  • Page 12 To determine the warranty for a specific drive, use a web browser to access the following web page: support.seagate.com/customer/warranty_validation.jsp From this page, click on the “Verify Your Warranty” link. You will be asked to provide the drive serial number, model number (or part number) and country of purchase.

  • Page 13: Formatted Capacity

    2.2 Formatted capacity Formatted Model capacity* 2000GB ST2000VM002 1500GB ST1500VM002 *One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. 2.2.1 LBA mode When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed sectors as defined above.

  • Page 14: Physical Characteristics

    2000 and 1500GB models <17.0s <17.0s 10.0s . Typical power measurements are based on an Table 2 on page 15 www.seagate.com 26.1mm / 1.028 in 101.6mm / 4.0 in (± 0.010 in) 147.00mm / 5.78 in 635g / 1.39 lb 64MB (65,536kb) Figure 3 Pipeline HD SATA Product Manual, Rev.
  • Page 15 • Spinup power Spinup power is measured from the time of power-on to the time that the drive spindle reaches operating speed. • Read/write power and current Read/write power is measured with the heads on track, based on a 16-sector write followed by a 32-ms delay, then a 16-sector read followed by a 32-ms delay.

  • Page 16: Figure 1 Typical Current Profiles (5V)

    Drive Specifications www.seagate.com Figure 1 Typical Current Profiles (5V) Figure 2 Typical Current Profiles (12V) Pipeline HD SATA Product Manual, Rev. B...

  • Page 17: Conducted Noise

    2.8.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 80-ohm resistive load on the +12V line or an equivalent 15-ohm resistive load on the +5V line. • Using 12V power, the drive is expected to operate with a maximum of 120 mV peak-to-peak square-wave injected noise at up to 10MHz.

  • Page 18: Environmental Specifications

    (30% per hour max) 5% to 95% noncondensing (30% per hour max) 37.7°C (99.9°F max) 40°C (104°F max) –304.8m to 3048m (–1000 ft. to 10,000+ ft.) –304.8m to 12,192m (–1000 ft. to 40,000+ ft.) Pipeline HD SATA Product Manual, Rev. B www.seagate.com...

  • Page 19: Vibration

    2000GB and 1500GB models The nonoperating shock level that the drive can experience without incurring physical damage or degradation in performance when subsequently put into operation is 300 Gs based on a nonrepetitive half-sine shock pulse of 2ms duration.

  • Page 20: Acoustics

    Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389- 7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards.

  • Page 21: Warranty

    As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure,disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.

  • Page 22: Environmental Protection

    Superintendent of Documents, U.S. Government Printing Office, Washington, DC 20402. Refer to publication number 004-000-00345-4. 2.14 Environmental protection Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting certain chemical substances. 2.14.1 European Union Restriction of Hazardous Substances (RoHS) Directive...

  • Page 23: Corrosive Environment

    The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%.
  • Page 24 Drive Specifications www.seagate.com Pipeline HD SATA Product Manual, Rev. B...

  • Page 25: Configuring And Mounting The Drive

    3.0 Configuring and Mounting the Drive This section contains the specifications and instructions for configuring and mounting the drive. 3.1 Handling and static-discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. Observe the following standard handling and static-discharge precautions: Caution: •...

  • Page 26: Drive Mounting

    Configuring and Mounting the Drive www.seagate.com Figure 3 Attaching SATA cabling Signal connector Power connector Signal cable Power cable Each cable is keyed to ensure correct orientation. Pipeline HD drives support latching SATA connectors. 3.4 Drive mounting You can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom-mounting holes.

  • Page 27: Figure 4 Mounting Dimensions (2000 And 1500Gb Models)

    Figure 4 Mounting dimensions (2000 and 1500GB models) Recommended case temperature measurement location Pipeline HD SATA Product Manual, Rev. B Configuring and Mounting the Drive...
  • Page 28 Configuring and Mounting the Drive www.seagate.com Pipeline HD SATA Product Manual, Rev. B...

  • Page 29: Serial Ata Interface

    4.0 Serial ATA Interface These drives use the industry-standard Serial ATA (SATA) interface that supports FIS data transfers. It supports ATA programmed input/output (PIO) modes 0 to 4; multiword DMA modes 0 to 2, and Ultra DMA modes 0 to 6. For detailed information about the Serial ATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment”...

  • Page 30: Supported Ata Commands

    2nd mate 2nd mate 5V power, pre-charge, 2nd mate 5V power 5V power 2nd mate 1st mate. 12V power, pre-charge, 2nd mate 12V power 12V power Command code (in hex) / C1 Pipeline HD SATA Product Manual, Rev. B www.seagate.com...
  • Page 31 Table 6 Supported ATA commands (Continued) Command name Device Configuration Identify Device Configuration Restore Device Configuration Set Device Reset Download Microcode Execute Device Diagnostics Flush Cache Flush Cache Extended Format Track Identify Device Idle Idle Immediate Initialize Device Parameters...
  • Page 32 Write Log Extended Command code (in hex) Address: Password: Lock: Unlock: Freeze Lock: / D9 / D2 / D8 / D4 / D1 / D0 / D5 / DA / D3 / D6 Pipeline HD SATA Product Manual, Rev. B www.seagate.com...

  • Page 33: Identify Device Command

    Table 6 Supported ATA commands (Continued) Command name Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Stream DMA Extended Write Stream Extended Write Uncorrectable 4.3.1 Identify Device command The Identify Device command (command code EC power up.
  • Page 34 Minimum PIO cycle time with IORDY flow control (120 nsec) 69–74 ATA-reserved Queue depth Serial ATA capabilities Reserved for future Serial ATA definition Serial ATA features supported Serial ATA features enabled Major version number www.seagate.com Value 8010 0000 2F00 4000 0200 0200 0007...
  • Page 35 Table 7 Identify Device commands (Continued) Word Description Minor version number Command sets supported Command sets supported Command sets support extension (see note following this table) Command sets enabled Command sets enabled Command sets enable extension Ultra DMA support and current mode (see note following this...
  • Page 36 Ultra DMA mode 2 is supported. Ultra DMA mode 3 is supported. Ultra DMA mode 4 is supported. Ultra DMA mode 5 is supported. Ultra DMA mode 6 is supported. Ultra DMA mode 0 is currently active. www.seagate.com Pipeline HD SATA Product Manual, Rev. B...

  • Page 37: Set Features Command

    Table 8 Bit Descriptions (Continued) Ultra DMA mode 1 is currently active. Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active.

  • Page 38: Commands

    SeaTools diagnostic software activates a built-in drive self-test (DST S.M.A.R.T. command for D4 unnecessary drive returns. The diagnostic software ships with all new drives and is also available at: http://seatools.seagate.com. This drive is shipped with S.M.A.R.T. features disabled. You must have a recent BIOS or software package that supports S.M.A.R.T.
