Model Da91 Actuator Parts (Replacement Only); Tow Dolly Parts List And Breakdown - Demco TOW-IT TI110 TOW DOLLY Operator's Manual

4
7
5
16
16
2
2
REF.
NO.
-
-
1. SB24636-30 1
2.
3.
4.
5.
6.
-
7.
8.
9.
-
10.
11. SB10961-95 1
12.
13.
14.
15.
-
16.
17.
18.
19.
10î BRAKE CLUSTER PARTS LIST
1
6
8
10" BRAKE CLUSTER PARTS LIST
PART QTY.
NO. REQíD. DESCRIPTION
SB23715 - Left Hand Cluster (shown above)
SB23714 - Right Hand Cluster
Back Plate Assembly
SB9254 2 Cover Plate - Adjusting Hole
SB10954 1 Brake Shoe Kit (includes 2 Primary & 2 Secondary)
04305 2 5/16"-18UNC-Gr5 x 1/2" Hex Hd Bolt
05424 2 5/16" External Tooth Washer
SB9776 1 Wheel Cylinder Assembly - Right
SB9777 1 Wheel Cylinder Assembly - Left
05431 1 Bleeder - replacement
SB9783 1 Push Rod
SB24047 1 Adjusting Screw Assembly - "R" (for LEFT cluster)
SB24048 1 Adjusting Screw Assembly - "L" (for RIGHT cluster)
SB10958 2 Spring - Shoe
Shoe Guide
SB23937 1 Cable
SB23936 1 Cable Guide
SB23724 1 Spring Adjusting Screw
05414-95 1 Lever - Left
05415-91 1 Lever - Right
SB10959 2 Pin - Shoe Hold Down
SB9789 4 Cup Shoe Hold Down
05983 2 Spring - Shoe Hold Down
03880 1 Spring - Adjusting Screw Retainer
- SB15845 1 Wheel Cylinder Repair Kit (w/ spring, cup, & boot)
- SB15545A 10î Hub/Drum (w/ bearings, seals, nuts, & dust cap)
- SB15545 4 10" Brake Drum
Please order replacement parts by PART NO. and DESCRIPTION.
Brake shoe kit can be ordered for one complete axle only.
Left Side Breakdown
3
11
13
12
19
9
15
17
Page 16
10
18
10
17
17
14
18
17
