Familiarization Guide
This guide is for experienced technicians who have already
completed the HP Vectra computer family training course.
In particular, it assumes that the reader is already familiar
with the HP Vectra XU 6/xxx PC, upon which the
HP Vectra XW PC Workstations are based.
This document serves as a self-paced training guide,
designed to train you for repair of the computer, and only
contains repair-specific information. For information on the
installation of accessories, see the User's Guide and the
online documents that are supplied with the computer.
HP Vectra XW PC Workstation Family
HP Vectra XW
