PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included. If a part is missing, please call 1-888-533-1333.
M8 Washer
(17)––3
M8 Locknut
(19)––7
M8 Large
Washer (14)––2
M8 Acorn
Nut (65)––2
M8 x 40mm
Bolt (31)––4
M10 Black
Washer (12)––2
M4 x 15mm
Screw (3)––6
M8 x 60mm
Carriage Bolt (64)––2
5
Wave Washer
(37)––2
M8 x 20mm
Screw (11)––9
