Technical Specifications - HP Smart Array P400 Quickspecs

QuickSpecs

Technical Specifications

Dimensions (not
including bracket)
Disk Drive and
Enclosure Interface
SAS Connectors
Cache Memory Speed DDR2-533MHz with 40 or 72-bit wide bus provides up to 4.2 GB/s maximum bandwidth.
Server Interface
SAS Speed
Cache Memory
Logical Drives
Supported
Maximum Logical Drive
Capacity
Host Memory
Addressing
RAID Support
Upgradeable Firmware Upgradeable Firmware with recovery ROM feature
© Copyright 2006 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. Microsoft and Windows are registered trademarks or
trademarks of Microsoft Corporation in the U.S. and/or other countries. The only warranties for HP products and services are
set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed
as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
For hard drives, 1 GB = 1 billion bytes. Actual formatted capacity is less.
Low Profile PCIe Form Factor
6.61 in x 2.75 in x 0.7 in (16.8 cm x 7.0 cm x 1.8 cm)
3G SAS (Serial Attached SCSI)
1.5G SATA (Serial ATA)
2 internal (SFF8484) x4 wide port connectors
x8 2.5G PCIe provides 2GB/s maximum bandwidth.
x8 3G SAS provides 2.4GB/s maximum bandwidth.
40-bit 256MB ECC protected cache (72-bit 512MB module upgrades available); transportable with
battery-backed upgrade
Up to 32 logical drives
2TB
64-bit, supporting greater than 4GB server memory space
RAID 6 with ADG (Advanced Data Guarding) requires Battery Backed Write Cache Upgrade
RAID 5 (Distributed Data Guarding)
RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping)
DA - 12400 Worldwide QuickSpecs — Version 5 — 10/3/2006
HP Smart Array P400 Controller
Page 9
