OWNER'S MANUAL
200W 2-Channel Amplifier
Thank you for purchasing a JL Audio amplifier for
your automotive sound system.
Your amplifier has been designed and manufactured to exacting
standards in order to ensure years of musical enjoyment in your vehicle.
For maximum performance, we highly recommend that you have
your new amplifier installed by an authorized JL Audio dealer. Your
authorized dealer has the training, expertise and installation equipment
to ensure optimum performance from this product. Should you
decide to install the amplifier yourself, please take the time
to read this manual thoroughly so as to familiarize yourself
with its installation requirements and setup procedures.
If you have any questions regarding the instructions in this
manual or any aspect of your amplifier's operation, please contact your
authorized JL Audio dealer for assistance. If you need further assistance,
please call the JL Audio Technical Support Department
at (954) 443-1100 during business hours.
Advertisement
Table of Contents
Related Manuals for JL Audio XD200
Summary of Contents for JL Audio XD200
- Page 1 OWNER’S MANUAL 200W 2-Channel Amplifier Thank you for purchasing a JL Audio amplifier for your automotive sound system. Your amplifier has been designed and manufactured to exacting standards in order to ensure years of musical enjoyment in your vehicle. For maximum performance, we highly recommend that you have your new amplifier installed by an authorized JL Audio dealer.
-
Page 2: Protect Your Hearing
Status Filter Mode Frequency Selector Selection (pg. 11) (pg. 8) (pg. 9) Input Turn-On Ch. 1 & 2 Input Voltage Mode Sensitivity Control (pg. 7) (pg. 6) (pg. 8) 2 Channel Amplifier 2 | JL Audio - XD200/2v2 Owner’s Manual... -
Page 3: Planning Your Installation
PLANNING YOUR INSTALLATION Mounting the amplifier upside down is It is important that you take the time to read this manual and that you plan out your strongly discouraged. If mounting the amplifier under a seat, make sure there is at least 1 inch installation carefully. -
Page 4: Product Description
(use of the JL Audio ECS master The XD200/2v2 can be operated with a wide ground lug, XB-MGLU is recommended). Use variety of source units and system configurations. -
Page 5: Power Connections
XD200/2v2 with 8 or 4 AWG power wire. fused within 18 inches (45 cm) of the positive JL Audio ECS fused distribution blocks are battery post connection. -
Page 6: Turn-On Options
DC offset sensing. Of course, If a source unit does not have a dedicated the XD200/2v2 must be the first amplifier in the remote turn-on output, consider one of the signal path for this to function properly. -
Page 7: Input Section
The XD200/2v2’s input section allows you to Line output converters are usually not needed send signals to the amplifier section through the with the XD200/2v2. If you find that the output use of two differential-balanced inputs. cannot be reduced sufficiently with a direct... -
Page 8: Input Sensitivity Control
XD200/2v2 for maximum clean ear. For this reason, most speaker systems are output. Rotating the control clockwise will result... -
Page 9: Remote Level Control (Optional)
With the addition of the optional Remote Level to the XD200/2v2 in a bi-amplified system. Control (HD-RLC), you can control the volume of the XD200/2v2 from the front of the vehicle. 2) “Filter Freq. (Hz)” The filter frequency This is useful for subwoofer level control, rear... -
Page 10: Bridging Considerations
The preamp output delivers the same signal that is connected to the Amplifier Inputs. This power output. can be useful for feeding a subwoofer amplifier when the XD200/2v2 is being used to drive front BRIDGING CONSIDERATIONS speaker systems. Bridging is the practice of combining the... - Page 11 This option is used when deploying a very short in duration, it may manifest itself pair of the XD200/2v2’s channels to drive left as an audible, repetitive ticking or thumping channel speakers only and the other pair of the noise in the output.
- Page 12 6) Verify that you have disconnected the speakers before proceeding. Play a track with an appropriate sine wave (within the frequency range to be amplified by the XD200/2v2) at 3/4 source unit volume. 7) Connect the AC voltmeter to the speaker output connectors of the amplifier.
-
Page 13: General Specifications
08 ... “60” ... .57 Amplifier Topology: NexD™ Ultra-High Speed Class D 09 ......59 Power Supply: Unregulated MOSFET switching type 10 . -
Page 14: Appendix D: Troubleshooting
Check the input connectors to ensure that they all are making good contact with the input jacks on the amplifier. 14 | JL Audio - XD200/2v2 Owner’s Manual... - Page 15 “My amplifier shuts off once in a while, usually at higher volumes.” Check Check your voltage source and grounding point. The power supply of the XD200/2v2 will operate with charging system voltages down to 10V. Shutdown problems at higher volume levels can occur when the charging system voltage (or remote turn-on voltage) drops below 10V.
- Page 16 Miramar, FL 33025 (do not send product for repair to this address) International Warranties: Products purchased outside the United States of America are covered only by that country’s distributor and not by JL Audio, Inc. Printed in China XD200/2v2 MAN-09-2013...
