MX852UST/MW853UST
Digital Projector
User Manual

Advertisement

Table of Contents
loading

Summary of Contents for BenQ MX852UST

  • Page 1 MX852UST/MW853UST Digital Projector User Manual...
  • Page 2: Table Of Contents

    Table of contents Important safety Hiding the image ........38 Locking control keys......38 instructions ....3 Operating in a high altitude Introduction....7 environment..........39 Adjusting the sound ....... 39 Projector features........7 Using the test pattern......40 Shipping contents ........8 Using the teaching templates ....
  • Page 3: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before In some countries, the line voltage is...
  • Page 4 Safety Instructions (Continued) The lamp becomes extremely hot Do not place this product on an during operation. Allow the unstable cart, stand, or table. The projector to cool for approximately product may fall, sustaining serious 45 minutes prior to removing the damage.
  • Page 5 Safety Instructions (Continued) Do not place this projector in any of Do not block the ventilation holes. the following environments. - Do not place this projector on a blanket, bedding or any other soft surface. - Space that is poorly ventilated or - Do not cover this projector with a cloth confined.
  • Page 6 You can purchase a BenQ projector wall socket and call BenQ to have the wall mount kit from the place you projector serviced. purchased your BenQ projector.
  • Page 7: Introduction

    3D Function supported Various 3D formats make the 3D function more flexible. By presenting the depth of the images, you can wear BenQ 3D glasses to enjoy the 3D movies, videos and sporting events in a more realistic way. •...
  • Page 8: Shipping Contents

    Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated. Projector with wall mount plate Remote control with battery Power cord...
  • Page 9: Projector Exterior View

    Projector exterior view PointWriter dummy cover (PointWriter kit) Front/upper side Mirror Lamp compartment cover Focus ring External control panel (See "Projector" on page 11 details.) Vent (cool air intake) Projection lens Front adjuster foot Front IR remote sensor COMPUTRR-2 input jack COMPUTER-1 input jack Rear/lower side RS-232 control port...
  • Page 10: Bottom Side

    Wall mount plate Bottom side Introduction...
  • Page 11: Controls And Functions

    Controls and functions Projector POWER indicator light Lights up or flashes when the projector is under operation. See "Indicators" on page 60 for details. AUTO Automatically determines the best picture timings for the displayed image. "Auto-adjusting the image" on page for details.
  • Page 12: Remote Control

    Remote Control LASER (No available in Japan region) Emits visible laser pointer light for presentation purposes. ZOOM+/ZOOM- Magnifies or reduces the projected picture size. ASPECT Selects the display aspect ratio. 10. FREEZE Freezes the projected image. 11. NETWORK SETTING Displays the Network Settings OSD menu.
  • Page 13 Operating the LASER pointer 20. MUTE Toggles projector audio between on and The Laser Pointer is a off. presentation aid for professionals. It emits a 21. SMART ECO beam of red light when you Switch the lamp mode between Eco/ press it.
  • Page 14: Remote Control Effective Range

    Remote control effective range Infra-Red (IR) remote control sensor is located on the front of the projector. The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensor to function correctly. The distance between the remote control and the sensor should not exceed 8 meters (~ 26 feet).
  • Page 15: Replacing The Remote Control Battery

    Replacing the remote control battery To open the battery cover, turn the remote control over to view its back, push on the finger grip on the cover and slide it up in the direction of the arrow as illustrated. The cover will slide off. Remove any existing batteries (if necessary) and install two AAA batteries observing the battery polarities as indicated in the base of the battery compartment.
  • Page 16: Positioning Your Projector

    Note that a special rear projection screen portability. and the BenQ Projector Wall Mounting *Set Front Table in the SYSTEM Kit are required for this installation SETUP: Basic > Projector location.
  • Page 17: Obtaining A Preferred Projected Image Size

    Projection dimensions Refer to "Dimensions" on page 19 for the center of lens dimensions of this projector before calculating the appropriate position. MX852UST The screen aspect ratio is 4:3 and the projected picture is 4:3. Screen size Screen Screen Projection...
  • Page 18 17.55 445.8 13.26 336.9 311.6 There is 5% tolerance among these numbers due to optical component variations. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector before you permanently install it, so as to make allowance for this projector's optical characteristics.
  • Page 19: Dimensions

    Dimensions 287.5 mm (W) x 201 mm (H) x 373.3 mm (D) 373.3 130.2 227.9 287.5 Wall Mount Installation 287.50 OPTICAL AXIS Unit: mm 43.25 149.25 206.25 255.25 Regulating Range 0~40 Regulating Range 0~30 360~665 Positioning your projector...
  • Page 20: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...
  • Page 21: Connecting Video Source Devices

    Connecting video source devices You need only connect the projector to a video source device using just one of the connecting methods, however each provides a different level of video quality. The method you choose will most likely depend upon the availability of matching terminals on both the projector and the video source device as described below: Terminal name Terminal appearance...
  • Page 22: Playing Sound Through The Projector

    Playing sound through the projector You can make use of the projector (mixed mono) speaker in your presentations, and also connect separate amplified speakers to the AUDIO OUT socket of the projector. If you have a separate sound system, you will most likely want to connect the audio output of your Video source device to that sound system, instead of to the mono audio projector.
  • Page 23: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted). Check that the POWER indicator light on the projector lights orange after power has been applied. Please use the original accessories (e.g.
  • Page 24: Using The Quick Install

    Using the quick install The projector provides a hot key to set Projector Installation, Test Pattern, and Keystone quickly. Press Quick Install on the remote control and press ▲/▼ to select: QUICK INSTALL Projector Installation Test Pattern Keystone Exit MENU •...
  • Page 25: Correcting Keystone

    Fine-tuning the image size and clarity Sharpen the image by rotating the FOCUS ring. Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. To correct this, besides adjusting the height of the projector, you can use Auto Keystone or Keystone manually correct it following one of these steps.
  • Page 26: Using The Menus

    Phase H. Size Menu Settings Digital Zoom Operation Settings Panel Key Lock Background Color Blue Teaching Template Splash Screen BenQ S-VIDEO MENU Exit S-VIDEO MENU Exit Use ◄/► to highlight the System Setup: Press MODE/ENTER twice* on Basic menu. the projector or remote control to leave and save the settings.
  • Page 27: Securing The Projector

    Securing the projector Using a security cable lock The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as a Kensington lock, to secure the projector. You can locate a Kensington lock slot on the left side of the projector.
  • Page 28: If You Forget The Password

    BenQ the screen. Customer Center. Write down the number and turn off your projector. Seek help from the local BenQ service Recall code: 12345678 center to decode the number. You may be required to provide proof of purchase...
  • Page 29: Disabling The Password Function

    You have successfully assigned a new password to the projector. Remember to enter the new Password Changed password next time the projector is started. To leave the OSD menu, press MENU/EXIT. Disabling the password function To disable password protection, go back to the System Setup: Advanced > Security Settings >...
  • Page 30: Switching Input Signal

    Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. Be sure the Quick Auto Search function in the Source menu is On (which is the default of this projector) if you want the projector to automatically search for the signals.
  • Page 31: Magnifying And Searching For Details

    Magnifying and searching for details If you need to find the details on the projected picture, magnify the picture. Use the direction arrow keys for navigating the picture. • Using the remote control Press Digital Zoom+/- to display the Zoom bar. Press Digital Zoom+ to magnify the center of the picture.
  • Page 32 About the aspect ratio In the pictures below, the black portions are inactive areas and the white portions are active areas. OSD menus can be displayed on those unused black areas. Auto: Scales an image 4:3: Scales an image so that it is proportionally to fit the projector's displayed in the center of the screen native resolution in its horizontal...
  • Page 33: Optimizing The Image

    Optimizing the image Using Wall Color In the situation where you are projecting onto a colored surface such as a painted wall which may not be white, the Wall Color feature can help correct the projected picture’s color to prevent possible color difference between the source and projected pictures. To use this function, go to the Display >...
  • Page 34: Adjusting Brightness

    Press ▼ to select a sub-menu item to be changed and adjust the value with ◄/►. "Fine-tuning the image quality in user modes" below for details. Fine-tuning the image quality in user modes According to the detected signal type, and selected picture mode, some of the functions listed below may not be available.
  • Page 35: Setting A Preferred Color Temperature

    Setting a preferred color temperature To set a preferred color temperature: Highlight Color Temperature and select Warm, Normal or Cool by pressing ◄/► on the projector or remote control. Press ▼ to highlight Color Temperature Fine Tuning and press MODE/ ENTER.
  • Page 36: Setting The Presentation Timer

    Please refer to the illustration to the right for how the colors relate to each other. For example, if you select Red and set its Yellow range at 0, only pure red in the projected GREEN picture will be selected. Increasing its range will include red close to yellow and red close to magenta.
  • Page 37: Remote Paging Operations

    Press ▼ to highlight Timer Display and choose if you want the timer to show up on the screen by pressing ◄/►. Selection Description Always Displays the timer on screen throughout the presentation time. 3 min/2 min/1 min Displays the timer on screen in the last 3/2/1 minute(s). Never Hides the timer throughout the presentation time.
  • Page 38: Freezing The Image

    Freezing the image Press FREEZE on the remote control to freeze the image. The word 'FREEZE' will appear on the screen. To release the function, press any key on the projector or remote control. If your remote control has the following keys, please note that they cannot be pressed to release the function: LASER, #2, #5, PAGE +/PAGE -.
  • Page 39: Operating In A High Altitude Environment

    Operating in a high altitude environment We recommend you use the High Altitude Mode when your environment is between 1500 m –3000 m above sea level, and temperature is between 0°C–30°C. Do not use the High Altitude Mode if your altitude is between 0 m and 1500 m and temperature is between 0°C and 35°C.
  • Page 40: Using The Test Pattern

    Adjusting the sound level To adjust the sound level, • Using the remote control Press to select a desired sound level. • Using the OSD menu Repeat steps 1-2 above. Press ▼ to highlight Volume and press ◄/► to select a desired sound level. Turning off the Power on/off ring tone Repeat steps 1-2 above.
  • Page 41: Using The Teaching Templates

    Using the teaching templates The projector provides several preset patterns for various teaching purposes. To activate the pattern: Open the OSD menu and go to the Display > Teaching Template and press ▲/▼ to select Blackboard or Whiteboard. Press ◄/► to choose the pattern you need. Press MODE/ENTER to activate the pattern.
  • Page 42: Shutting Down The Projector

    Shutting down the projector Press POWER or OFF and a confirmation message will appear prompting you. If you don't respond in a few seconds, the message will disappear. Press POWER or OFF a second time. The POWER indicator light flashes orange, the projection lamp shuts down, and the fans will continue to run for approximately 90 seconds to cool down the projector.
  • Page 43: Menu Operation

    Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. Main menu Sub-menu Options Off/Light Yellow/Pink/Light Green/ Wall color Blue/Blackboard Aspect Ratio Auto/Real/4:3/16:9/16:10 Keystone Position Phase H.size Digital zoom PC:1.0X~2.0X; Video: 1.0X~1.8X Auto/Off/Frame sequential/Frame 3D mode packing/Top bottom/Side by side...
  • Page 44 Main menu Sub-menu Options Dynamic/Presentation/sRGB/ Picture Mode Cinema/3D/User 1/User 2 Dynamic/Presentation/sRGB/ Reference Mode Cinema/3D Brightness Contrast Color Tint Sharpness Brilliant Color On/Off Color Picture Cool/Normal/Warm Temperature Color R Gain/G Gain/B Gain/R Offset/ Temperature Fine G Offset/B Offset Tuning Primary Color R/G/B/C/M/Y 3D Color Management...
  • Page 45 On/Off Disable/5 mins/10 mins/15 mins/ Blank Timer 20 mins/25 mins/30 mins Disable/30 mins/1 hr/2 hrs/3hrs/ Sleep Timer 4hrs/8 hrs/12hrs Panel Key Lock On/Off Background Color BenQ / Black / Blue / Purple Splash Screen BenQ / Black / Blue Operation...
  • Page 46: System Setup

    Main menu Sub-menu Options High Altitude On/Off Mode Mute On/Off Audio Settings Volume Power on/off Ring On/Off Lamp Mode Normal/Economic/SmartEco Reset Lamp Timer Reset / Cancel Lamp Settings Equivalent Lamp Hour Change Passward Security Setting Change Security Power On Lock/Web Control Settings Lock 2400/4800/9600/14400/19200/...
  • Page 47: Description Of Each Menu

    Description of each menu FUNCTION DESCRIPTION Corrects the projected picture’s color when the projection surface is Wall color not white. See "Using Wall Color" on page 33 for details. There are several options to set the image's aspect ratio depending Aspect Ratio on your input signal source.
  • Page 48 FUNCTION DESCRIPTION This projector features a 3D function which enables you to enjoy the 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images. You need to wear a pair of 3D glasses to view the 3D images.
  • Page 49 FUNCTION DESCRIPTION Pre-defined picture modes are provided so you can optimize your Picture Mode projector image set-up to suit your program type. "Selecting a picture mode" on page 33 for details. Selects a picture mode that most suits your need for the image Reference quality and further fine-tune the image based on the selections listed on the same page below.
  • Page 50: Menu Display Time

    FUNCTION DESCRIPTION Presentation Reminds the presenter to finish the presentation within a certain time frame. See "Setting the presentation timer" on page 36 for details. Timer Sets the language for the On-Screen Display (OSD) menus. Language "Using the menus" on page 26 for details.
  • Page 51: Lamp Mode

    When Power On Lock is activated, you will be asked to enter the current password before powering on the projector. If you enter incorrect password 5 times in succession, the projector will automatically shut down in a short time. Web Control Lock BenQ Network Projector Operation Guide for details. Operation...
  • Page 52: Monitor Out

    FUNCTION DESCRIPTION Selects a baud rate that is identical with your computer’s so that you can connect the projector using a suitable RS-232 cable and update Baud Rate or download the projector’s firmware. This function is intended for qualified service personnel. Selecting On enables the function and the projector displays the grid Test Pattern test pattern.
  • Page 53: Picture Mode

    FUNCTION DESCRIPTION Source Shows the current signal source. Picture Mode Shows the selected mode in the Picture menu. Resolution Shows the native resolution of the input signal. Lamp Mode Current Shows the current lamp mode. System 3D Format Status Shows the current 3D mode. Color System Shows input system format, NTSC, PAL, SECAM, YUV or RGB.
  • Page 54: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.
  • Page 55: Lamp Information

    Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. The method of calculating the equivalent lamp hour is as follows: "Setting Lamp mode as Economic or SmartEco" below for more information on Economic mode.
  • Page 56: Timing Of Replacing The Lamp

    SmartEco" on page 55), you may continue to Lamp >XXXX Hours operate the projector until the next lamp warning appears. Order a new lamp at lamp.benq.com Press MODE/ENTER to dismiss the message. Notice Replace Lamp soon Lamp > XXXX Hours It is strongly recommended that you replace the Order a new lamp at lamp.benq.com...
  • Page 57: Replacing The Lamp

    This lamp contains mercury. Consult your local hazardous waste regulations to dispose of this lamp in a proper manner. • To assure optimal performance from the projector, it is recommended that you purchase a BenQ projector lamp for lamp replacement. •...
  • Page 58: The Projector

    Loosen the two captive screws that secure the lamp. • Do not turn the power on with the lamp cover removed. • Do not insert your fingers between the lamp and the projector. The sharp edges inside the projector may cause injuries. Lift the handle so that it stands up.
  • Page 59: Resetting The Lamp Timer

    Replace the lamp compartment cover on the projector and tighten the screw. Restart the projector. Do not turn the power on with the lamp cover removed. Resetting the lamp timer After the startup logo, open the On-Screen Display (OSD) menu. Go to the SYSTEM SETUP: Advanced >...
  • Page 60 Indicators Light Status & Description Power Temp Lamp Power events Orange Stand-by mode Green Powering up Flashing Green Normal operation Orange Projector is cooling. Flashing Lamp events Orange The lamp ignition is not lit up. Flashing The projector needs 90 seconds to cool down. Or Please contact your dealer for assistance.
  • Page 61: Troubleshooting

    Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC inlet on the projector, and plug the power cord into the There is no power from the power cable. power outlet. If the power outlet has a switch, make sure that it is switched on.
  • Page 62: Specifications

    Specifications Projector specifications All specifications are subject to change without notice. Optical Control Resolution MX852UST Type-B 1024 x 768 XGA Mini USB (available for PointWriter kit) MW853UST RS-232 serial control 1280 x 800 WXGA 9 pin x 1 Display system IR receiver x 1 Single-chip DLP™...
  • Page 63: Timing Chart

    XGA_85 84.997 68.667 94.5 XGA_120** 119.989 97.551 115.5 (Reduce Blanking) 1152 x 864 1152 x 864_75 67.5 BenQ Notebook 1024 x 576 35.82 46.966 Timing BenQ Notebook 1024 x 600 64.995 41.467 51.419 Timing 1280 x 720 1280 x 720_60* 74.25...
  • Page 64 Resolution Format Refresh rate H- frequency Pixel Frequency (MHz) (Hz) (kHz) 1280 x 960_60*** 1280 x 960 1280 x 960_85 85.002 85.938 148.5 1360 x 768 1360 x 768_60*** 60.015 47.712 85.5 1440 x 900 WXGA+_60*** 59.887 55.935 106.5 1400 x 1050 SXGA+_60*** 59.978 65.317...
  • Page 65 XGA_85 84.997 68.667 94.5 XGA_120** 119.989 97.551 115.5 (Reduce Blanking) 1152 x 864 1152 x 864_75 67.5 BenQ Notebook 1024 x 576 35.82 46.996 Timing BenQ Notebook 1024 x 600 64.995 41.467 51.419 Timing 1280 x 720 1280 x 720_60* 74.25...
  • Page 66 Resolution Format Refresh rate H- frequency Pixel Frequency (MHz) (Hz) (kHz) 1280 x 768 1280 x 768_60* 59.87 47.776 79.5 WXGA_60* 59.81 49.702 83.5 WXGA_75 74.934 62.795 106.5 1280 x 800 WXGA_85 84.88 71.554 122.5 WXGA_120** 119.909 101.563 146.25 (Reduce Blanking) SXGA_60*** 60.02 63.981...
  • Page 67 Supporting timing for HDMI Video input Format Resolution Refresh rate H- frequency Pixel Frequency (MHz) (Hz) (kHz) 480i*** 720 (1440) x 480 59.94 15.73 480p*** 720 x 480 59.94 31.47 576i 720 (1440) x 576 15.63 576p 720 x 576 31.25 720/50p** 1280 x 720...
  • Page 68: Warranty And Copyright Information

    Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.
