Summary of Contents for Energer ENB475MSW
- Page 1 SAFETY AND OPERATING MANUAL Original Instructions V1.0 1400W MITRE SAW ENB475MSW...
- Page 2 Read all safety warnings and all instructions before use. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. 1400W MITRE SAW ENB475MSW...
-
Page 3: General Safety Instructions
- Use face or dust mask if working operations create dust. 10. Connect dust extraction equipment. - If the tool is provided for the connection of dust extraction and collecting equipment, ensure these are connected and properly used. 1400W MITRE SAW ENB475MSW... - Page 4 - Have defective switches replaced by an authorised service centre. - Do not use the tool if the switch does not turn it on and off. 21. Warning. - The use of any accessory or attachment other than one recommended in this instruction 1400W MITRE SAW ENB475MSW...
-
Page 5: Special Safety Instructions
18. Ensure that irregular or round piece to be cut off has sufficient room to move or twist so that they cannot pinch the blade. 1400W MITRE SAW ENB475MSW... - Page 6 42. When cutting long pieces which extend well over the table width, ensure that the ends are adequately supported at the same height as the saw table top. Supports should be positioned in such a way to ensure that the workpiece does not fall to the ground once the 1400W MITRE SAW ENB475MSW...
-
Page 7: Noise Information
The declared vibration emission been measured in accordance with a standardised test stated aboveand may be used to compare one tool with another tool.The declared vibration emission value may also be used in a preliminary assessment of exposure. 1400W MITRE SAW ENB475MSW... - Page 8 6.Plan your work schedule to spread any high vibration tool use across a number of days. Emergency Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety directions and follow them to the letter. This will help to prevent risks and hazards. 1400W MITRE SAW ENB475MSW...
- Page 9 The machine is intended as a stationary machine for making straight lengthways and crossways cuts in wood. Horizontal mitre angles of -45° to +45° as well as vertical bevel angles of 0° to +45° are possible. 1400W MITRE SAW ENB475MSW...
- Page 10 Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.Check with your Local Authority or retailer for recycling advice. yyWxx Manufacturing date code:Year of manufacturing (20yy) and week of manufacturing (Wxx); 1400W MITRE SAW ENB475MSW...
-
Page 11: Components And Controls
8 Mitre scale 21 0°Bevel adjustment screw 9 Table insert 22 Spindle lock button 10 Mitre table 23 Dust bag 11 Fence 24 Hex key 12 Saw arm 25 Support stand 13 Release knob 26 Fence locking screw 1400W MITRE SAW ENB475MSW... -
Page 12: Technical Data
Wear ear protection when sound pressure is over 80dB(A) ACCESSORIES This COMPOUND MITRE SAW comes with the following accessories: • 24 Teeth blade (fitted) • Dust bag • Workpiece clamp • Support stand • 6mm Hex key 1400W MITRE SAW ENB475MSW... - Page 13 Fig.2,3 & 4. WARNING:Always assemble the support stand when using the product. 3. MOUNTING HOLES (Fig. 5) Before use, the saw can be fixed to a firm, level surface with the 4 mounting bolts (Not supplied). Fig.5 1400W MITRE SAW ENB475MSW...
-
Page 14: Operation
5) Continue to move the saw head down smoothly and make the cut exerting only gentle pressure on the downward stroke, letting the saw do the work. Fig.9 1400W MITRE SAW ENB475MSW... -
Page 15: Maintenance
Cutting Head is lowered. MAINTENANCE WARNING: Remove the plug from the socket before carrying out any adjustment, servicing or maintenance. When all the adjustments, settings or maintenance have been done, make sure that all keys and 1400W MITRE SAW ENB475MSW... - Page 16 The 45° bevel tilt should also be adjusted use a 45° set square or mitre gauge (d , not supplied), to check the 45° angle, adjust the set screw (g1) for 45° to set the correct stop position, then tighten Fig.17 1400W MITRE SAW ENB475MSW...
- Page 17 1. When transporting the saw with fixed locations, make sure that the saw head is locked in the lower position. 2. The rotary table locking knob, the bevel lock knob must all be securely tightened. Fig.22 1400W MITRE SAW ENB475MSW...
-
Page 18: Environmental Protection
Directive 2012/19/EU. It will then be recycled or dismantled to minimise impacts on the environment, electrical and electronic products are potentially hazardous to the environment and human health due to the presence of hazardous substances. 1400W MITRE SAW ENB475MSW... - Page 19 GUARANTEE This ENERGER product carries a guarantee of 12 months. If your product develops a fault within this period, you should, in the first instance contact the retailer where the item was purchased. This guarantee specifically excludes losses caused due to:...
-
Page 20: Declaration Of Conformity
EN61029-1: 2009 EN61029-2-9: 2002 EN55014-1: 2006+A1 EN55014-2: 1997+A1+A2 EN61000-3-2: 2006+A1+A2 EN61000-3-3: 2008 Authorised Signatory and technical file holder Date: 20/09/12 Signature: Name: Peter Harries Powersmith Ltd. Trade House , Mead Avenue ,BA22 8RT Quality Manager 2012 1400W MITRE SAW ENB475MSW...
