1. Connections

1
2
Figure 1
1) USB input. Connect directly to the USB 3.0 or 2.0 or 1.1* port of a PC, Mac or Linux-
based computer, or use an USB extender (A male to A female). In the latter, the extender
must be compliant with USB 2.0 and less than 3m, otherwise the bus performance will
decrease and the correct operation of the interface will not be guaranteed. USB type A
male connector
2) Stereo analog output. Connect to the amplifier or preamplifier input with a 3.5mm jack-
to-RCA interconnect or to a medium- or high-impedance headphones. 3.5mm stereo jack
female connector.
* hiFace DAC performance on USB 1.1 are limited to 96kHz. Please note that 1.0 ports
won't work.
