LevelOne GEU-2429 Technical Specifications

24 GE + 4 GE SFP Switch
H/W Version: 1
Easily boost your networking throughput
The GEU-2429 24 Gigabit ports that lead you to a real
Gigabit connection. Users are now able to transfer
large and high bandwidth-needed files faster and
hence get a real efficiency improvement. In addition
to the cooper ports, 4 of those ports support fiber
connection with the equipped SFP ports for obtaining
long-distance communication.
Offers users with fast and reliable network
The store-and-forward architecture filters errors and
forwards packets in a non-blocking environment. Flow
1
Key Features
- Complies with IEEE802.3, IEEE 802.3u, IEEE 802.3ab
and IEEE 802.3az standards.
- 24 x 10/100/1000 Mbps RJ-45 Nway ports
- 4 x SFP ports for optional fiber optical
communication
- Supports NWay protocol for speed
(10/100/1000Mbps) and duplex mode (Half/Full)
auto-detection
- Support auto-detection for SFP module inset
- Supports MDI/MDI-X auto crossover
- Supports full and half duplex operation on all copper
ports
- Supports back-pressure (half duplex) and flow
control (IEEE 802.3x)
- Wire-speed packet filtering and forwarding rate
- Store-and-forward architecture filters fragment &
CRC error packets
- Supports 9K bytes Jumbo frame.
- Supports 16K MAC address entries in whole system
- 340K bytes buffer memory
2
2 3
control ensures the correctness of data transmitting.
The 802.3x and backpressure flow control mechanisms
work respectively for full and half duplex modes.
Eeasy installation and maintenance
It supports Nway auto-negotiation protocol that
detects the networking speed (10/100/1000 Mbps)
and the duplex modes (Full/Half ) automatically.
Auto-MDI/MDI-X function alleviates the effort to
use crossover cables. Also, rich diagnostic LEDs are
provided for users to get real-time information of the
connection status.
4
Works Well With
GNC-0105T
32-bit Gigabit Ethernet PCI Card
USB-0401
USB Gigabit Ethernet Adapter
GEU-2429
1. LED Indicators
2. 10/100/1000Mbps
RJ-45 Ports
3. SFP Slot
4. Internal Power Socket
