VID-TRANS12KN
2.4GHz AUDIO/VIDEO SYSTEM
TRANSMITTER & RECEIVER
MANUAL
ENGLISH

Advertisement

loading
Need help?

Need help?

Do you have a question about the VID-TRANS12KN and is the answer not in the manual?

Questions and answers

Related Manuals for Konig VID-TRANS12KN

Summary of Contents for Konig VID-TRANS12KN

  • Page 1 VID-TRANS12KN 2.4GHz AUDIO/VIDEO SYSTEM TRANSMITTER & RECEIVER MANUAL ENGLISH...
  • Page 2 Important safety precautions: This equipment generates and uses radio frequency energy and if not installed and used properly, that is in strict accordance with the manufactures instructions, it might cause interference to radio and television reception. It has been tested and found to comply with the provisions of the 1999/5/EC R&TTE directive, which are designed to provide reasonable protection against such interference in a residential installation.
  • Page 3 Description transmitter: Power LED Power switch IR-T AV IN 7.5V DC input IR cable in AV input Antenna Channel switch Description receiver: Power switch Power LED IR sensor IR antenna 7.5V DC input AV output Antenna Channel switch...

  • Page 4: Operation

    Operation: Connect the transmitter with the AV cable with the output of VCR, DVD or SAT. Connect the receiver with the AV cable with the input of TV, LCD screen or PLASMA. Connect the plug of the 7.5V DC adapter into the transmitter and the receiver and connect the power plug into a 230 Volt wall outlet.

  • Page 5: Specifications

    Specifications: Transmitter: Operating Frequency Band 2.400GHz~2.4835GHz Maximum Output Level 10dBm (CE) Modulation FM (video and audio) Channels (4) PLL frequency synthesizer Video Input Level 1V p-p @ 75 ohm Audio Input Level 1V p-p @ 600 ohm (STEREO) Input Port 3.5mm plug Antenna Omni-directional...

  • Page 6: Declaration Of Confirmity

    DECLARATION OF CONFIRMITY Nedis B.V. De Tweeling 28 5215MC ’s-Hertogenbosch The Netherlands Tel.: 0031 73 599 1055 Fax.: 0031 73 599 9699 Email: info@nedis.com Internet: www.nedis.com Declare under our responsibility that the product; Brandname: KONIG Model: VID-TRANS12 KN Description: 2.4GHz wireless transmission system Is in confirmity with the following standards;...
