Konig DVB-TFT A10 Manual

Konig DVB-TFT A10 Manual

Terrestrial
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DVB-T FT A10
DIGITAL TERRESTRIAL RECEIVER
MANUAL
E N G L I S H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVB-TFT A10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Konig DVB-TFT A10

Summary of Contents for Konig DVB-TFT A10

  • Page 1 DVB-T FT A10 DIGITAL TERRESTRIAL RECEIVER MANUAL E N G L I S H...

  • Page 2: Important Safety Instructions

    IMPOR TANT-SAFETY PRECAUTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a damp cloth. 7. Do not block any of the ventilation openings.Install in accordance with the manufacturer=s instructions.
  • Page 3 The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”within the products enclosure that may be of sufficient magnitude to consititute a risk of electric shock to a person. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying...

  • Page 4: Table Of Contents

    CONTENTS Important safety Instructions 1.Before You Begin 1.1 Main Features 1.2 Accessories 2.Controls and Functions 2.1 Front Panel 2.2 Rear Panel 2.3 Remote Control Unit 3.Connections 4.Settings and Operations 4.1 Installation Wizard 4.2 Basic Settings 4.3 Edit 4.4 Setup 4.5 Tools 4.6 Hot keys 4.7 Teletext Menu Map...

  • Page 5: Before You Begin

    1.1 MAIN FEATURES Easy Graphic MENU Interface RS232C Port for Updating Control Software and Additional Service Multi-language Function Last channel Memor y 256 Color Graphic User Interface Front Panel Buttons & IR Remote Control User Interface Editing Functions (TV or Radio, Group, Channel Name, Sort) EPG for On Screen Channel Information 1.2 ACCESSORIES Remote Control Unit...

  • Page 6: Controls And Functions

    CONTROLS AND FUNCTIONS 2.1 FRONT PANEL 1. Power Button Turns the receiver On/Off. 2. Remote Sensor Detects infrared signal from Remote Control Unit. 3. Display (4-digit/7-Segment) The 4-digit displays channel information. In STANDBY mode, the 7-segment displays local time. 4.Up/Down Button Changes channels in the No-menu State and moves the cursor up/down in the Menu state.

  • Page 7: Rear Panel

    2.2 REAR PANEL 1.Antenna Out Connect to other STB to TV. 2.Antenna In Connect to Terrestrial ANT. 3. SCART TV,VCR Connect TV/VCR of TV/VCR to TV/VCR with SCART cables. 4.RS-232C Connect a PC . RS-232C transfers data to a personal computer (BAUD. rate 115200) 5.

  • Page 8: Remote Control Unit

    2.3 REMOTE CONTROL UNIT (RCU) You can start the receiver, operate on-screen menu, and use a variety of key function. 1. STANDBY Turns the receiver On/Off. 2. MUTE Mutes audio output. 3.LEFT/RIGHT ( 1. If you press Left/Right button while watching channel, you can adjust Volume level.
  • Page 9 11.CH / CH Select CH. 12.Pg / Pg Move Up/Down a page in the channel list. 13.VOL / VOL Adjust volume level. 14.INFO INFO Shows the information of the current program.If you press the button,the channel info box will be shown continuously even though the preset time for channel info box INFO EXIT elapsed.

  • Page 10: Connections

    CONNECTIONS The following figure shows cable connections required for terrestrial Ant,TV and etc. As many different equipment configurations are possible. If you need any assistance for specific equipment connection,please contact your local distributor.

  • Page 11: Settings And Operations

    SETTINGS AND OPERATIONS 4.1 INSTALLATION WIZARD (FIRST TIME INSTALLATION) Turn on your TV and receiver. If it is the first time to use a receiver, you should set parameters for system configuration. Press the MENU button. Refer to the following section for detailed information about system configuration 1.
  • Page 12 3.Time Setting Enter your local time . How to use the icon 1.Search Channel 2.Edit 3.Setup 4. Tools...

  • Page 13: Basic Settings

    4.2 BASIC SETTINGS 1. Search Channel In order to install the receiver properly you have to perform Basic Settings. When you have finished the setup procedure, you can watchTV or listen to Radio. During the basic settings, a short information is displayed at the bottom of the menu screen.

  • Page 14: Edit

    1-2.Automatic Search Automatic Search is for easier search. <OK> :Search Start 4.3 EDIT Select Edit menu.Edit screen will be shown,as below. 1.Edit Channel Edit channels by creating,locking,moving,and deleting.

  • Page 15: Setup

    4.4 SETUP This helps set additional function such as language, OSD, Output,Time , Lock control. Language Setting OSD setting Output Setting Time Setting Lock Control 1.Language Setting Selects language for menu,Audio and Subtitle. Select “Language setting”with and press the OK button. Select a desired language like English or others.If you press exit key, the window will disappear.
  • Page 16 2.OSD Setting Changes wanted mode such as Info bar hide-out time, Background, Sound effect, OSD Transparency or Load default. A.Infobar Hide-Out 1. Select “OSD Setting”with key. 2.Select duration time by using the Key (1Sec, 3Sec, 5Sec, 10Sec, Continue) B. Background Color 1.Select “Background color”...
  • Page 17 Aspect ratio conversions Here is a description of how the aspect ratio conversion will be done depending on the selected display aspect ratio conversion mode chosen,the received stream and the user’s television set aspect ratios. 4:3 Stream on a 4:3 TV 16:9 Stream on a 16:9 TV whatever the mode whatever the mode...
  • Page 18 4.Time Setting Set time for current time, wake up time, and sleep time . A. Current Time 1. Press key to select “Current Time” 2. Input the local time by pressing number button. B. Wakeup Timer 1. Press key to select “Wakeup Timer” 2.
  • Page 19 5. Lock Control This menu helps prevent the receiver from wrong use. Use Age limit,menu lock,and password. A.Age Lock “Age Lock” 1. Press key to select “Yes” 2. To block certain channels by viewer=s age, select by using the keys. B.Age Limit “Age Limit”...

  • Page 20: Tools

    4.5 TOOLS This menu helps see information of receiver and make FACTORY SETTING on receiver. 1. Information Shows H/W, S/W and DB version. 2.Signal Level Shows signal strength and quality.

  • Page 21: Hot Keys

    3.Factory Setting This menu helps receiver make the state of first-time usage. 4.Game You can play games Tetris or Block Out. 4.6 HOT KEY S This section explains the general information while watching TV or listening to Radio. 1.“INFO” Key Whenever you change the channel(or volume) by pressing the CH£+/CH-( program information window will appear for a few seconds.You can also select how long the information will be shown in the tools menu.
  • Page 22 2.“OK” Key While watching TV or listening to Radio you can get the channel list by pressing the button on the remote control. The Channel list can be sorted by name, free channel,and date. EXIT And if you want to return to the previous mode, press button.

  • Page 23: Teletext

    5.Audio Information Select “AUDIO” button to change audio Stereo, Mono, Left,Right Press the “AUDIO” button on the remote control, you can select the Audio language and Mode. The Language Information window shows the input audio language and you can select the Audio language.

  • Page 24: Menu Map

    MENU MAP Search Channel Manual Search Frequency Network Search FTA Only Search Star t Automatic Search Edit Channel Edit Menu Language Audio Language Subtitle Subtitle Language Language setting Setup OSD setting Infobar Hide-Out Output setting Background Time setting Sound Effect Lock Control OSD Transparency Load Default...

  • Page 25: Additional Information

    ADDITIONAL INFORMATIONS A.1 TROUBLE SHOOTING There may be various reasons for the abnormal operation of the receiver. Check the receiver according to the procedures shown below. If the receiver does not work properly after checking it,please contact the dealer. Don’t open the receiver. It may cause a dangerous situation. Cause Remedy Symptom...

  • Page 26: Technical Specifications

    A.2 TECHNICAL SPECIFICATIONS 1.Tuner & Demodulator RF input Connector IEC type, Female RF output connector IEC type, Male RF Frequency Range 47MHz to 862MHz` Input Impedance 75Ω Unbalanced Input Signal Level -78 dBm to -20dBm IF Frequency 36.167 MHz IF bandwidth 7/8MHz Demodulation COFDM...

  • Page 27: Glossary Of Terms

    6.Environment Operating Temperature +5°C ~ +50°C Storage Temperature -40°C ~ +65°C 7. Physical Specification Size (W x D x H) 300 x 213 x 37mm Weight (Net) 1.2kg A.3 GLOSSARY OF TERMS Electronic Program Guide . A software that enables viewers to navigate easily among the large number of channels provided by digital technology, in order to select the service they desire.
