Elo TouchSystems 3239L Specifications page 2

3239L 32" Open-Frame Wide-Aspect LCD Touchmonitor
Case/Bezel Color
Display Type
Display Size
Useful Screen Area
Monitor Dimensions
Native Resolution
Optimal (Pre-Set) Resolution
Other Supported
Resolutions
Colors
Brightness (typical)
Response Time
Viewing Angle (typical)
Contrast Ratio
Input Video Format
Input Sync Format
Input Video Signal Connector
Scanning Frequency Ranges
Power Consumption
Power Supply – Internal
Temperature
Humidity (non-condensing)
Monitor MTBF (excluding lamps) 50,000 hours demonstrated
Backlight Lamp Life
Weight (approx.)
Other Features
Warranty
Touch Interface
Agency Certification
To find out more about Elo's extensive range of touch solutions, go to www.elotouch.com, or call the office nearest you.
North America
Elo TouchSystems
301 Constitution Drive
Menlo Park, CA 94025-1110
Tyco Electronics reserves the right to change or update, without notice, any information contained herein; to change,
without notice, the design, construction, materials, processing or specifications of any products; and to discontinue or
limit production or distribution of any products.
AccuTouch, Acoustic Pulse Recognition, Elo TouchSystems, IntelliTouch, TE Logo, and Tyco Electronics are trademarks.
Copyright 2008 Tyco Electronics Corporation 8/12/08
Dark gray
Active matrix TFT LCD
32.0" diagonal
Horizontal: 697.7 mm
Vertical: 392.3 mm
Width: 784 mm
Height: 474 mm
Depth: 110 mm
1366 x 768
1360 x 768 @ 60 Hz and 1366 x 768 @ 60 Hz
640 x 480 @ 60 Hz, 800 x 600 @ 56 Hz, 800 x 600 @ 60 Hz, 1024 x 768 @ 60 Hz,
1280 x 960 @ 60 Hz, 1280 x 1024 @ 60 Hz, 1360 x 768 @ 60 Hz, 1366 x 768 @ 60 Hz,
1600 x 1200 @ 60 Hz, 1680 x 1050 @ 60 Hz
16.7 million colors
LCD Panel: 500 cd/m 2
with IntellTouch: 450 cd/m
2
with APR: 450 cd/m
Typical Rise Time 8 msec
Typical Fall Time 8 msec
Horizontal: 89° (looking left) / 89° (looking right) at a CR>10
Vertical: 89°(looking down) / 89° (looking up) at a CR>10
1500:1 (typical)
1. RGB Analog Video
2. DVI Video (not available on 3239L-xxEx models)
Separate H & V sync, Composite Sync, and Sync-On-Green
1. 15-pin female D-sub for Analog Video
2. Female DVI-D for Digital Video
Horizontal: 30 - 75 kHz
Vertical: 48 - 63 Hz
145W typical, 190W maximum (at 110V/60Hz input)
Monitor Input Voltage: 100~240 VAC, 50/60Hz
Operating: 0°C to 40°C
Storage: -20°C to 60°C
20% to 80% humidity (non-condensing)
10% to 90% humidity (non-condensing)
50,000 hours minimum
Actual: 17.3 kg; Shipping: 21.6 kg
100mm VESA mount; Digital on-screen display (OSD); User's control: OSD buttons: menu,
up, down, select; OSD: automatic adjustment, contrast, brightness, H/V position, clock,
phase, color temperature, input video select, OSD H/V position, OSD timeout, language
(English, French, Italian, German, Spanish, Japanese, Traditional Chinese, Simplified
Chinese), recall color, recall defaults, sharpness, display information; OSD locking/
unlocking and power locking/unlocking
TouchMonitor: 3 years
USB and Serial (IntelliTouch, Surface Capacitive)
UL (US), cUL (Canada), GS Mark (Germany), FCC (US), CE (EU), NOM (Mexico), PCT
(Russia), CCC/RoHS (China), eK/Mic (Korea), BSMI (Taiwan), Singapore, VCCI (Japan),
C-Tick (Australia) and S-mark (Argentina), WEEE, IMERC.
