LevelOne GTL-5280 Brochure & Specs

L2 Plus Managed Switch -
48 GE with 4 Combo SFP
+ 4 10GE SFP Plus
H/W Version: 1
LevelOne GTL-5280 is a Layer 2-Plus Managed switch,
provides 48 x 1000Base-T ports associated with 4 x
SFP (Small Form Factor Pluggable) and 4 x 10 Gigabit
SFP Plus slots. Despite its affordable pricing, the GTL-
5280 is equipped with advanced features such as
Single IP Management which allows users to manage
up to 32 switches under the same web interface,
Easy Configuration Port (ECP), IPv6, IEEE 802.1D/w/
s Spanning Tree, IEEE 802.1X Access Control, IEEE
802.3az Green Ethernet and more. An ideal network
solution for workgroups and edge deployments, or
anyone looking for an affordable and efficient way to
expand their network.
IP Clustered Stacking Solution
With the design and implementation of SIP (Single IP
Management), network administrators are allowed
to virtually stack GEL-1072, GTL-2880, GTP-2880,
and GTL-5280 together and manage them as one
logical unit through a single IP address regardless of
geographical locations of those switches. Comparing
to traditional stacking, IP clustering eliminates the
use of costly cables and connectors. Furthermore, it
minimizes the impact of any single point of failure.
LevelOne Easy Configuration Port (ECP)
Technology
Each switch port can now be fully optimized through
a predefined role and settings which are based on the
type of a device such as an IP camera or a VoIP phone
1 2
1. LED Indicators
2. Mode Button
3. 10/100/1000Mbps RJ-45 LAN Ports
4. SFP (Mini-GBIC) Slot
2
3 4 4
to be connected to. For instance, even if a surveillance
system integrator who lacks of IT administration skills,
can still easily enables the role and applies settings
like VLAN, QoS, port security and spanning tree to
all connected IP cameras on a single Web UI within a
few minutes. Hence, simplifying network deployment
and ensuring consistent configurations across the
network.
Enhanced Security Measures
We are always committed to providing the highest
level of protection for your network resources against
intrusion attacks and unauthorized access. Delivering
robust access control, each Access Control List
(ACL) consists of up to 512 entries, allowing you to
configure a fine-grained restriction policy based on
frame type, TCP/UDP ports, MAC address and VLAN
ID in order to get deep inspection on your network
traffic. In addition, with the implementation of port-
based authentication (IEEE 802.1X), messages can
be encrypted, therefore preventing intruders from
getting authentication credentials.
5
5. RS-232 Port
6. Power Socket
GTL-5280
6
