- Page 1 Owner's Manual Monitors GML-2230M 54.6 cm (21.5") LCD/TFT Monitor LED Backlight GML-2430M 61 cm (23.6") LCD/TFT Monitor LED Backlight GML-2230M.69.1.29.06.2012 © ASP AG...
-
Page 3: Table Of Contents
Content: 1. Important Safety Instructions 2. Installation 3. Package Contents 4. Rear View with Connections 5. Turning the Monitor Off/On 6. Switching the Monitor Source 7. OSD Menu Configurations 1. Picture Menu 2. Sound Menu 3. Setting Menu 4. PIP/POP Setup Menu 8. -
Page 4: Installation
Do NOT use cleaning fluids based on alcohol, methylated spirit or ammonia. The glass plate has a hard surface coating to prevent scratches. However, the use of strong chemical cleaning agents may damage this coating. Use only a mild soap or detergent and water or specially formulated cleaners made for cleaning glass panels. -
Page 5: Package Contents
100-240 V AC, 50/60 Hz, 2.0 A (minimum). Check the monitor specification carefully. This GRUNDIG monitor has a 1280 x 1024 resolution and works with both PAL and NTSC signal modes. This GRUNDIG monitor is for 24/7 security purposes; therefore, the environmental specifications such as the operating temperature and the voltage needed have to be maintained at all times. -
Page 6: Turning The Monitor Off/On
AV2 Input: Connect a video source with coaxial cable (with Composite Video Signal) to the BNC connector for AV2 mode. AV2 Output: Here you can pick off the signal of the AV1 input and make it available for other devices. If no cable is connected, the monitor automatically sets a 75 Ω resistance. PLEASE NOTE: The audio inputs only work if the appropriate video mode is enabled. -
Page 7: Picture Menu
7.1. Picture Menu AV1 / AV2 Mode VGA / HDMI Mode Picture Mode: Press - or + to select the picture mode ("User, Standard, Movie, Vivid"). Contrast: This is used to set the brightness of the screen. Press - or + to adjust the parameter. Brightness: This is used to adjust the image contrast. -
Page 8: Sound Menu
7.2. Sound Menu Volume: Press – or + to adjust the volume level. Mute: Press – or + to turn the sound “Off, On”. 7.3. Setting Menu VGA Mode AV1 / AV2 / HDMI Mode Language: Press – or + to select the language. H Position: Move the display picture to the left or right. -
Page 9: Pip/Pop Setup Menu
Pixel Clock: Press – or + to adjust the parameter. Phase: Press – or + to adjust the parameter. Scale Mode: Adjust the V-size of the display picture. Press – or + to set it the V-size to “Full” or “16:9”. Reset: Press –... -
Page 10: Frequently Asked Questions
Swap: Press – or + to to swap the windows of the Main and Sub Source. NOTE: 1. In PIP / POP mode, AV1 or AV2 and HDMI or VGA can be displayed at the same time on one monitor. 2. - Page 11 No sound coming from the audio speakers: - The audio cable should be connected to the line-out on the audio card and the line-in on the monitor. Ensure that the audio cable is properly connected. - Inspect the audio cable for any apparent damage. Double-check by switching to another audio cable to see if the audio works.
- Page 12 Specifications GML-2230M LCD Panel size 21,5" Diagonal AM-TFT LED Backlight Pixels - Total 1920(H) x 1080(V) Pixel Pitch 0.248 mm(H) x 0.248 mm(V) Aspect Ratio 16 : 9 Video Standard PAL/NTSC Video Inputs 2 CH Composite, BNC, Looped 1 HDMI, 1 CH VGA...
- Page 13 Dimensions English...
-
Page 14: Ec Declaration Of Conformity
EC Declaration of Conformity GML-2230M 54.6 cm (21.5") LCD/TFT Monitor LED Backlight GML-2430M 61 cm (23.6") LCD/TFT Monitor LED Backlight It is hereby certified that the products meet the standards in the following relevant provisions: EC EMC Directive 2004/108/EC Low Voltage Directive 2006/95/EC...
